3idee hp34c-om Assembly Instructions Manual

Vesa adapter
Hide thumbs Also See for hp34c-om:
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

hp34c-om VESA adapter
Assembly
instructions
The VESA adapter is compatible with the following products from
hp
OMEN
(omen.com):
OMEN 34c
With the VESA adapter, you can easily attach your HP monitor to a monitor arm
with a VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for this.
Direct wall mounting is NOT possible, as the VESA adapter already contains metric
threads through which no screws can be inserted for mounting to the wall.
support@3idee.eu | +352 661 26 72 76 | help.3idee.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the hp34c-om and is the answer not in the manual?

Questions and answers

Related Manuals for 3idee hp34c-om

Summary of Contents for 3idee hp34c-om

  • Page 1 VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for this. Direct wall mounting is NOT possible, as the VESA adapter already contains metric threads through which no screws can be inserted for mounting to the wall. support@3idee.eu | +352 661 26 72 76 | help.3idee.eu...

  • Page 2: Technical Specifications

    Assembly instructions Technical Specifications Maximum monitor weight: 7 kg / 15.4 lbs VESA standard compatibility: 75x75 mm Material: plastic Pivot angle: compatible (90°) Maximum operating temperature: 35°C / 95°F Maximum ambient temperature: 35°C / 95°F ⚠ WARNING Exceeding the maximum load capacity, operating temperature or ambient temperature can lead to serious injury or damage.

  • Page 3: Important Safeguards

    Assembly instructions Important Safeguards Please read this manual carefully and keep it for future reference. If you pass the product on to third parties, this manual should always be included. Ignoring these instructions may result in injuries or damage to people and products, for which we cannot accept any liability.
  • Page 4 For the disposal of this product we recommend to contact the responsible local authorities or disposal services. They can provide you with detailed information on available disposal options and recycling centers in your area. 4. Manufacturer Information 3idee S.à r.l. 19 Rue de Bitbourg L-1273 Luxembourg Luxembourg mail: info@3idee.eu...

  • Page 5: Scope Of Delivery Accessories

    Assembly instructions Scope of Delivery Accessories 4x M4x14 Screw with cross recess (SP2)

  • Page 6: Horizontal Mounting

    Assembly instructions Horizontal / Vertical Alignment ⚠ NOTE: Not all VESA adapters and monitors are designed for a vertical (portrait) orientation. This limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information, as the load limit of the adapter can be quickly exceeded if not mounted properly.
  • Page 7 Assembly instructions Video assembly instructions...

  • Page 8: Assembly Instruction

    Assembly instructions Assembly Instruction Step 1 Place your OMEN monitor on a soft, secure surface. Please remove the base of your monitor if it is already attached by pressing the "button" on the bottom to pull out the base. Step 2 Attach the VESA adapter to the bracket on the back of your monitor as shown in the illustration.
  • Page 9 Assembly instructions ATTENTION: Make sure you use the right screws! (Figure 3) Step 5 Now check that you have tightened all screws properly. (Figure 4) Figure 4...
