hp-z VESA adapter
Assembly
instructions
The VESA adapter is compatible with the following monitors from
hp
(hp.com):
Z24f G3, Z24m G3, Z24n G3, Z24q G3, Z24u G3, Z25xs G3, Z27k G3, Z27q
G3, Z27xs G3, Z32k, Z34c G3, Z40c G3
The VESA adapter allows you to conveniently mount your HP brand monitor to a
monitor arm with a VESA hole pattern (75 x 75mm). Use the included screws and
nuts.
If you want to mount your VESA adapter directly to the wall, use suitable screws
and dowels (not included).
