- Page 1 GB IE ZL POWERED RESPIRATOR POWERED RESPIRATOR PROTECTIVE SUIT PROTECTIVE SUIT PRPS PRPS Respirex™ RJS Respiratory and Chemical INSTRUCTIONS FOR USE Protective Suits. BS065/G/2024...
-
Page 2: Table Of Contents
Contents Approvals..................1 General Information ..............1 Warnings and Limitations .............1 Indicator Lights and Alarming ..........3 Operating Conditions ............... 5 Preparation for Use ..............5 Donning procedure ..............8 Doffing procedure (use of Hazbag optional) ......12 Emergency self doffing procedure ........13 Filter and Cartridges ............. -
Page 3: Approvals
2016/425 on personal protective equipment as amended to apply in GB. The specification for a full facemask has been replaced by that for a visor. Note: the total mass of the PRPS exceeds that stipulated for a normal EN 12941:1998 filtering device. The Malina Safety CleanAIR® Chemical 2F Plus, when used in conjunction with the Respirex™... - Page 4 If the alarm sounds (see page 3) PRPS use in the ‘power-off’ state is not normal. Little or no protection is provided and a build up of carbon dioxide and depletion of oxygen within the suit may occur.
-
Page 5: Indicator Lights And Alarming
The Remote Display Device (RDD) is connected to the AFU unit and is positioned in the hood of the PRPS suit for the wearer to identify the operational status of the AFU unit. - Page 6 If the visor is damaged, or vision obscured in any way, exit the contaminated area and doff the apparatus following the user instruction. For the PRPS: the attached Kemblok™ gloves and visor offer a high level of chemical protection, refer to the Technical Specification for further information on permeation resistance of gloves and the visor.
-
Page 7: Operating Conditions
2. Check the suit is free from contamination both externally and internally. The CleanAIR® Chemical 2F Plus AFU unit must only be used with the Respirex™ PRPS suit, and within the 1. Visually inspect the suit for any damage that may reduce the level of Operating Conditions: -5°C to +40°C when using the single use battery;... - Page 8 Ensure that a pair of identical filters are fitted. Double Filter Splash Covers (Respirex part number: F02032) must be fitted over the filters (Fig. 6 and Fig. 7). Ensure that the opening of the Double Filter Splash Cover is facing away from the suit.
- Page 9 Remove hand from the outlet. The red light will go out, all three lights cycle for a short time then the green light will remain illuminated. Do not don the PRPS(T) suit until a green light is achieved. Fig. 8...
-
Page 10: Donning Procedure
Donning procedure Donning procedure Make sure the suit has been visually inspected and is suitable for the intended use. Make sure the suit has been visually inspected and is suitable for the intended use. Underclothing should Underclothing should be worn beneath the suit. As a minimum, a short sleeve shirt be worn beneath the suit. - Page 11 (fig. 23). NB NEVER attempt to wear a PRPS(T) (Fig. 17). NB NEVER attempt to wear a PRPS(T) suit without switching on the AFU and ensuring the green air is supplied to the wearer (fig. 23). NB NEVER attempt to wear a PRPS(T) suit without switching on the AFU and ensuring the green light is permanently light is permanently illuminated (see indicator lights and warnings).
- Page 12 helmet after this stage. Ensure that the knitted neck seal sits evenly around the 8. The wearer should duck forwards and the assistant should pull the hood of the 8. The wearer should duck forwards and the assistant should pull the hood of the wearer's neck.
- Page 13 11. When fully donned the suit should appear as in figs.29 & 30. 11). When fully donned the suit should appear as in Fig. 23 Fig.30 Fig.29 Fig. 23...
-
Page 14: Doffing Procedure (Use Of Hazbag Optional)
preparation for doffing (fig. 31). should break the velcro seal on the outer zip flaps and fully open the gas-tight zip across the chest (fig. 32). 2. With the wearer’s arms in an outstretched position the dressing assistant Doffing procedure (use of Hazbag optional) should break the velcro seal on the outer zip flaps and fully open the gas-tight 3. -
Page 15: Emergency Self Doffing Procedure
EN 12941 with the classification of this device when used with this filter. Cleaning Instructions Respirex do not recommend laundering the PRPS suit. When the suit becomes dirty it should be wiped with a sponge using warm water and Citikleen*, rinsed and allowed to dry naturally. The inner surfaces of the suit should be sanitized using Synodor*. -
Page 16: Disposal
The Respirex™ range of PRPS Suits are designed for single exposure only and should not be reused after exposure to hazardous environments. Contaminated products should be disposed as hazardous waste in accordance with local health and safety and environmental regulations. -
Page 17: Product Labelling
TEL +44 (0)1737 778600 info@respirex.co.uk Wilthener Straße 32 / Gebäude 4a, D-02625, Bautzen, Germany TEL +49 (0)3591-5311290 info@respirex.de MODEL No: PRPS STYLE/STYLE No: SAMPLE SERIAL NO: MATERIAL: TYCHEM TK A00097 SALES ORDER No: SAMPLE CUSTOMER NAME: SAMPLE DATE OF MANUFACTURE:March 2023... -
Page 18: Storage And Transportation
Before initial use, always check that the product is within the stated shelf life (use by date). Do not store the PRPS Suits, the AFU unit (Chemical 2F Plus) or the batteries outside the temperature range -10°C to +50°C or with the humidity above 90%. -
Page 19: Sizing
e following pictograms designate the range of height & chest sizes suitable for specifi c sizes of PRPS suit, check your body measurements and select the correct size of suit. Body measure- Sizing ments in cm (inch). Warning: Incorrect size selection could lead to a reduced level of protection. -
Page 20: Permeation Performance
Permeation Performance The following test results indicate resistance to permeation against each of the 15 liquid chemicals in the standardised test battery EN 943-2:2019. All tests carried out under laboratory conditions by independent accredited laboratories in accordance with ISO 6529: 2013. Table shows average breakthrough times in minutes. -
Page 21: Physical Properties Of Tychem® Tk Material
Physical Properties Of Tychem® TK Material The samples submitted were tested in accordance with Table 1 of EN 943-2:2019. Minimum Performance Performance Property value of Property Test Method class of Class Required Tychem® TK Tychem® TK EN 943-2:2019 Basis Weight ISO 6529:2013 380 g/m Thickness... -
Page 22: Replacing The Exhalation Valve Diaphragm
Replacing the Exhalation Valve Diaphragm 1. Using a torque driver with a ‘T8’ Torx bit, loosen and remove the screw from the centre of the exhalation valve, then remove the cap. 2. Carefully slide the diaphragm up the central spigot and remove from the exhalation valve body. 3. - Page 24 RESPIREX INTERNATIONAL LTD, RESPIREX GmbH, Unit F Kingsfield Business Centre, Wilthener Straße 32 Philanthropic Road, Gebäude 4a, Redhill, D-02625, Surrey RH1 4DP Bautzen United Kingdom DEUTSCHLAND Tel. +44 (0)1737 778 600 Tel.: +49 (0)3591-5311290 Fax.+44 (0)1737 779 441 Fax: +49 (0)3591-5311292 www.respirex.com...
