Summary of Contents for Guardian 00215
-
Page 1: Table Of Contents
85096 Rev. G BEAMER TROLLEY ANCHOR Part # 00215 Instruction Manual Contents 2 Product Specific Applications 2 Applicable Safety Standards 2 For All Product Applications 2 Worker Qualifications 3 Compatibility 3 Limitations 3 Maintenance, Cleaning, and Storage 4 Specifications and Materials... -
Page 2: Product Specific Applications
English Product Specific Applications Applicable Safety Standards May be used to support a MAXIMUM 1 Meets or exceeds: direct Personal Fall Arrest System ANSI Z359.18-2017 (PFAS) for use in Fall Arrest applications only when used in combination with an energy OSHA 1910.140 ... -
Page 3: Compatibility
MINIMUM 2 ft (0,6 m) safety factor, deceleration distance, user height, length of lanyard/SRL, harness stretch, free fall, and all other applicable factors. See Guardian Fall Clearance Calculator: https://guardianfall.com/digital-resources/ fall-clearance-calculator Swing Falls: Prior to installation or use, make considerations for eliminating or minimising all swing fall hazards. -
Page 4: Specifications And Materials
Type A Anchorage Connector Materials Minimum Breaking Strength: Aluminum, stainless steel, nickel 5,000 lb (22,2 kN) plated steel and polyester.. Permitted Service Temperature Range: -300 to 1300 F (-340 C to 540 C) Part # Description 00215 Beamer Trolley Anchor... -
Page 5: Installation And Use
Installation and Use Installation: Step 1 Minimum Concrete Substrate Requirements: Unscrew Safety Locks and open Beamer Compatible beam flange width: 3” - 10” . Trolley Anchor to its maximum adjustment. Maximum beam flange thickness: 9/10” . Step 2 ... - Page 6 Examples: WARNING! Example beams shown ONLY. WARNING! Beam MUST incorporate an obstruction at beam ends that eliminates all possibility for Beamer Trolley Anchor to disconnect from beam.
-
Page 7: Safety Information
English Safety Information Harnesses and connectors selected must be compliant with manufacturer’s instructions, and WARNING! Failure to understand and must be of compatible size and configuration. comply with safety regulations may result Snap hooks, carabiners, and other connectors in serious injury or death. Regulations must be selected and applied in a compatible included herein are not all-inclusive, are fashion. -
Page 8: Labels
English Labels Gaurdian 90083 Rev. E - 1 90083 Rev. E - 2 Beamer Trolley Anchor Part# 00215 Serial # DOM: Lot. Prior to use, read and understand all manufactuerer's Beamer Trolley Anchor INSPECTION GRID Part # Serial #: instructions provided with equipment at time of User must inspect prior to EACH use. -
Page 9: Inspection
Inspection Diagram A - Connections Prior to EACH use, inspect Beamer Trolley Anchor for deficiencies, including, but not limited to, corrosion, deformation, pits, burrs, rough surfaces, sharp edges, cracking, rust, paint buildup, excessive heating, alteration, and missing or illegible labels. IMMEDIATELY remove Beamer Trolley Anchor from service if defects or damage are found, or if exposed to forces of fall arrest. -
Page 10: Inspection Log
Inspection Log Serial No: Date of first issue: Model #: User: Date: Results/Condition: Inspected by: Next Inspection Date:... - Page 11 Notes...
- Page 12 Guardian +1 (800) 466 6385 customer.service@guardianfall.com 607 East Sam Houston Parkway South, Suite 800 Pasadena, TX 77503 guardianfall.com Guardian® and its logo are registered trademarks of Pure Safety Group Inc. dba Guardian Fall in the US and other countries.
