4-WAY PLATE ANCHOR
Part # 00691
Instruction Manual
Do not throw instructions away.
Read and understand instructions before
using this equipment.
2
Product Specific Applications
2
Applicable Safety Standards
2
2
3
3
3
Maintenance, Cleaning, Storage
4
Components, Specifications
5-6
7
8
9
10-11
Product Capacity
Worker Classifications
Compatibility
Limitations
Installation and Use
HLL Use
Safety Information
Labels
Inspection
85092 Rev. J
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Guardian 00691
Summary of Contents for Guardian 00691
- Page 1 4-WAY PLATE ANCHOR Part # 00691 Instruction Manual Product Specific Applications Applicable Safety Standards Product Capacity Worker Classifications Compatibility Limitations Maintenance, Cleaning, Storage Components, Specifications Installation and Use HLL Use Safety Information Labels 10-11 Inspection Do not throw instructions away.
-
Page 2: Product Specific Applications
English Product Specific Applications Product Capacity Fall Arrest: May be used to support Maximum user weight (including all a MAXIMUM ONE (1) Personal Fall Arrest clothing, tools, and equipment) is: System (PFAS) for use in Fall Arrest 100-420 lb (45-190 kg) applications only when used in combination with an energy absorbing device rated to reduce fall arrest forces to no greater than 1,800 lb (8 kN). -
Page 3: Maintenance, Cleaning, And Storage
When calculating fall clearance, account for free fall, maximum arrest distance, harness stretch, a minimum 2 ft (0,6 m) safety factor, swing fall, and all other applicable factors. See Guardian Fall Clearance Calculator: https://guardianfall.com/digital-resources/ fall-clearance-calculator Swing Falls: Prior to installation or use, make considerations for eliminating or minimising all swing fall hazards. -
Page 4: Specifications
English Components Connection to PFAS (4) ½ in Concrete Fastener (20) Wood/Metal Fastener installation locations installation locations Loading Directions Specifications Minimum Breaking Strength: WARNING! Prior to installation ensure 5,000 lb (22,2 kN) installation location will satisfy intended work application(s). Minimum permitted service temperature: ... -
Page 5: Installation And Use
Installation and Use Wood Install: Step 1 Prior to installation, plan your system: Use (20) #14-10 wood screws, or fasteners Selected installation location must deemed compatible by a Competent Person, at MINIMUM 6 ft from leading edge of fall all wood/metal fastener installation locations hazard(s). - Page 6 Use (4) ½ in concrete fastener installation Step 1 locations (see image on pg. 4). Guardian Use (20) #14-10, 2 in metal screws, or fasteners recommends using ½ in x 3 ½ in threaded rod deemed compatible by a Competent Person, at assemblies.
- Page 7 Horizontal Lifeline Use All stages of design, installation, and use of HLL MUST be done under the supervision of a Qualified Person. HLLs MUST be used in combination with complete and compatible PFAS, and achieve a 2:1 safety factor. When HLL is attached to connection point on 4-Way Plate Anchor, no other connections to the same ...
-
Page 8: Safety Information
English Safety Information Harnesses and connectors selected must be compliant with manufacturer’s instructions, and WARNING! Failure to understand and must be of compatible size and configuration. comply with safety regulations may result Snap hooks, carabiners, and other connectors in serious injury or death. Regulations must be selected and applied in a compatible included herein are not all-inclusive, are fashion. - Page 9 English 3.5 in 3.5 in Labels 4-Way Plate Anchor Part #: 00691 DOM: SERIAL #: LOT #: Prior to use, read and understand all manufacturer’s instructions provided with guardianfall.com guardianfall.com equipment. 4-Way Plate Anchor 4-Way Plate Anchor Compliant with: OSHA 1926.502 and OSHA...
- Page 10 English Inspection Diagram A - Connections Prior to EACH use, inspect 4-Way Plate Anchor for deficiencies, including, but not limited to, corrosion, deformation, pits, burrs, rough surfaces, sharp edges, cracking, rust, paint build-up, excessive heating, alteration, broken stitching, fraying, and missing or illegible labels.
-
Page 11: Inspection Log
English Inspection Log Serial No: Date of First Use: Model #: User: Date: Inspected By: Results/Condition: Next Inspection Date:... - Page 12 This warranty is not transferable to any other Guardian service and does not apply to product that is resold after having been put into service. No other person, firm, entity, or the like is authorized to assume or assign for Guardian any other liability in connection with the sale or use of Guardian’s products.
