INSTRUCTION MANUAL
N/NT/NL/NLT
Closed Center Power Chuck
・This  instruction  manual  is  for  production  engineers  and
maintenance personnel in charge of operation of this product.
When  a  beginner  uses  this  product,  receive  instructions  from
experienced personnel, the distributor or our company.
・Before  installing,  operating  or  maintaining  this  equipment,
carefully  read  this  manual  and  the  safety  labels  attached  to
the equipment. Failure to follow these instructions and safety
precautions  could  result  in  serious  injury,  death,  or  property
damage.
・Store this manual near equipment for future reference.
・If  any  questions  related  to  safety  arise  about  this  manual,
please confirm them with the distributor or our company.
Kitagawa Corporation
77-1,Motomachi,Fuchu-shi,Hiroshima,726-8610,Japan
Te l . +81-847-40-0561
Fax. +81-847-45-8911
Version 1.09 (2019.09.03)
Original instructions
type

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Kitagawa N Series

  • Page 1 ・Before  installing,  operating  or  maintaining  this  equipment,  carefully  read  this  manual  and  the  safety  labels  attached  to  the equipment. Failure to follow these instructions and safety  precautions  could  result  in  serious  injury,  death,  or  property  damage. ・Store this manual near equipment for future reference. ・If  any  questions  related  to  safety  arise  about  this  manual,  please confirm them with the distributor or our company. Kitagawa Corporation 77-1,Motomachi,Fuchu-shi,Hiroshima,726-8610,Japan Te l . +81-847-40-0561 Fax. +81-847-45-8911...
  • Page 2: Guarantee And Limitation Of Liability

    The  chuck  and  cylinder  from  Kitagawa  Corporation  should  be  used  together.  If  you  must  use  a  part  not  made  by  Kitagawa,  check  with  us  or  our  distributor  to  be  sure  it  is  safe  to  do  so.    We  will  not  be  responsible  for  injury,  death, ...
  • Page 3: Table Of Contents

    Table of Contents 1. Structural Drawing and Parts List ………………………………………………………………  3    1-1. Type display    1-2. Structural drawing    1-3. Scope of product    1-4. Parts list    Important Safety Precautions  …………………………………………………………  6 3. Specifications ……………………………………………………………………………………  12    3-1. Specifications    3-2. Relationship between gripping force and rotation speed    3-3. Relationship between gripping part center height, static griping force and input force /              Relationship between top jaw mass moment and gripping force loss 4. Forming Soft Jaw ……………………………………………………………………………… 26    4-1. Attachment of soft jaw    4-2. Forming soft jaw with outside diameter gripping    4-3. Forming soft jaw with inside diameter gripping    4-4. Forming method when you use forming jig 5. Usage  ……………………………………………………………………………………………  30    5-1. Precautions during gripping work with chuck    5-2. Precautions during gripping work in irregular shape    5-3. Precautions related to usage of jaw    5-4. Precautions related to processing    5-5. Attachment of locator and jig 6. Maintenance and Inspection  …………………………………………………………………  33    6-1. Periodic Inspection    6-2. Grease lubrication    6-3. Disassembling 7. Malfunction and Countermeasures  ……………………………………………………………  36    7-1. In the case of malfunction    7-2. Where to contact in the case of malfunction For Machine Tool Manufacturers (Chapter 8)  8. Attachment  ………………………………………………………………………………………  37    8-1. Outline drawing of attachment    8-2. In the case that the back plate must be manufactured    8-3. In the case of with back plate...
  • Page 4: Structural Drawing And Parts List

     1 . Structural Drawing and Parts List 1−1 Type display Type display as shown below N -   0 6   A 0 6   9 9 9 Design No. Attachment  shape Straight  spigot  joint :− −5          :A05 −6          :A06 −8          :A08 −11        :A11 −15(Former JIS) :A15 Chuck  nominal  diameter −15(New JIS)  :C15 (inch) Type N-   :  3 JAW NT  :  2 JAW NL  :  3 JAW(Long Stroke) N L T   0 6   A 6   9 9 9 Design No.
  • Page 5: Scope Of Product

    4"、5" 6"〜15" 4"、5" 6"〜24" NT、NLT type N、NL type Fig.2 1−3 Scope of product This instruction manual is for the chuck part. Cylinder Chuck Drain  hose Flexible  hose Pressure  adjusting Pressure  Hydraulic screw gauge pump Manual switching  valve SOL. Line  Filter Solenoid valve Tank Fig.3 WARNING ・To  prevent  the  work  from  flying,  safe  design,  maintenance  and  erroneous  action  prevention  of  the  hydraulic  system ...
  • Page 6 1−4 Parts list Fig.4 Table 1 Quantity Part name Quantity Part name Body Set screw Wedge plunger Set screw 2or3 Master jaw 2or3 Grease nipple Soft jaw 2or3 Steel ball 2or3 * T nut Handle Cover Hex key Draw screw Hex key Draw tube Hex key Draw nut Hex key Spring Hex key Lead ball Hex key Stop bolt 2or3 Hex key Chuck attaching bolt Socket head cap screw Back plate 3or4 * Machine screw Socket head cap screw...
  • Page 7: Important Safety Precautions

     2 .   Important Safety Precautions Important  safety  precautions  are  summarized  below.  Please  read  this  section  before  first  starting to use this product. DANGER Failure to follow the safety precautions below will result in  serious injury or death. Turn off main power supply before attaching, inspecting or replacing chuck,  and before adding oil. For All Users ・The  chuck  may  start  rotation  suddenly,  and a part of the body or clothing may be  Main power supply caught. Lathe Close door before rotating spindle. For All Users ・If  the  door  is  not  closed,  you  may  touch  the rotating chuck or the work may fly out, ...
  • Page 8 DANGER Failure to follow the safety precautions below will result in  serious injury or death. Do not allow the rotation speed of the chuck to exceed the maximum allowable  speed limit. (Refer to pages 16-25) For All Users ・If the rotation speed of the chuck exceeds  the  rotation  speed  limit,  this  is  very  Fly out dangerous  as  the  chuck  and  work  will  fly  out. Work The input force of the chuck (piston thrust, pulling force of the draw bar)  must not exceed the allowable maximum input force.  For All Users (Refer to pages 16-25) ・Input  must  match  the  specification  of  Cylinder the chuck. Draw  bar ・Adjust  the  hydraulic  pressure  to  the  cylinder so that the input force, which ...
  • Page 9 Important Safety Precautions DANGER Failure to follow the safety precautions below will result in  serious injury or death. When the protrusion of the work is long, support it with  the steady rest or center. For All Users ・If the protrusion is long, the tip of the work can turn and the work fly out. Tail  stock Center Determine the gripping force required for processing by the machine tool manufacturer or user,  and check that the required gripping force is provided before processing. For All Users (Refer to pages 16-25 and cylinder manual) ・Adjust  the  hydraulic  pressure  to  the  cylinder  to  obtain  the  required  gripping  Fly out force.  If  the  gripping  force  is  insufficient,  this is dangerous as the work will fly out. Work Use of a chuck and cylinder that cannot be used together safely may cause  the cylinder to break at high pressure resulting in the chuck  For All Users and work flying out. ・Check that the chuck and the cylinder are in the ...
  • Page 10 DANGER Failure to follow the safety precautions below will result in  serious injury or death. In the case of processing a significant unbalanced work,  lower the rotation speed. For All Users ・Unbalanced  work  generates  dangerous  Unbalanced  work centrifugal  forces  and  the  work  could  fly  out. Fly out Always tighten the bolts at the specified torque. If the torque is insufficient or excessive, the  bolt will break, which is dangerous as the chuck or work will fly out. Use the For All Users  bolts attached to the chuck, and do not use bolts other than these. ・If the torque is insufficient or excessive, the bolt will break, which  Specified torque for  socket head cap screw is dangerous as the chuck or work will fly out. Bolt size Tightening torque ・Fix  the  lathe  spindle  or  the  chuck  when  you  tighten  bolts.  Your    13 N ・...
  • Page 11 Important Safety Precautions DANGER Failure to follow the safety precautions below will result in  serious injury or death. Provide sufficient strength for the draw bar (Refer to pages 38-39). Provide sufficient screw depth for the draw bar. For Machine Tool Manufactures Firmly tighten the draw bar. ・If  the  draw  bar  break,  the  gripping  force  is  instantly lost and this is dangerous as work will   fly out. ・If  the  screw  depth  of  the  draw  bar  is  insufficient,  the  screw  will  break  and  the  Cylinder adapter Draw bar Chuck gripping  force  will  be  lost  instantly,  and  this  is  Cylinder dangerous as work will fly out.
  • Page 12 Important Safety Precautions WARNING Failure to follow the safety precautions below could result in  serious injury or death. Do not modify the chuck in a way not permitted  by the manufacturer. For All Users ・It  may  not  only  break  the  chuck  but  the  chuck and the work may fly out, which is  dangerous. ・If  you  attach  a  locator  or  jig  on  the  chuck  body  surface,  only  process  work  in  an  acceptable range (Refer to page 31). Periodically supply adequate grease (Refer to page 33). Turn off power before  adding grease. For All Users ・Insufficient  grease  supply  lowers  the  gripping force, causes operation failure due ...
  • Page 13: Specifications

     3 . Specifications 3−1 Specifications Table 2-1 ・ N type Type N-04 N-05 N-06 N-08 N-10 Plunger stroke Jaw stroke (in diameter) Allowable maximum input force (kgf) (836) (836) (1835) (2549) (2957) 22.8 25.2 52.5 Maximum static gripping force (2325) (2570) (5353) (7648) (11013) (kgf) Allowable maximum 6000 5500 5270 4760 4010 rotation speed Standard soft jaw height (Z axis)  Gripping range φ6〜110 φ15〜165 φ23〜210...
  • Page 14 ・ N-A type Table 3-1 Type N-06A05 N-08A06 N-10A06  N-10A08  N-12A06  N-12A08  N-15A08  N-15A11 Plunger stroke Jaw stroke (in diameter) 10.5 Allowable maximum input force (kgf) (1835) (2549) (2957) (4181) (8362) 52.5 Maximum static gripping force (5353) (7648) (11013) (15907) (25391) (kgf) Allowable maximum 5270 4010 3380 3040 4760 rotation speed Standard soft jaw height (Z axis)  Gripping range φ15〜165 φ24〜254 φ26〜304...
  • Page 15 ・ NT type Table 4 NT04 NT05 NT15 Type Plunger stroke Jaw stroke (in diameter) 54.7 Allowable maximum input force (540) (540) (5578) (kgf) 15.2 16.8 Maximum static gripping force (1550) (1713) (16927) (kgf) Allowable maximum 6000 5500 3040 rotation speed Standard soft jaw height (Z axis)  Gripping range φ7〜110 φ20〜135 φ80〜381 (outside diameter gripping)  Mass (standard soft jaw included) Moment of inertia  0.007 0.013 1.79 kg・m Y0715R Y0715R...
  • Page 16 ・ NLT type Table 6 NLT06 NLT08 NLT10 NLT12 Type Plunger stroke Jaw stroke (in diameter) 16.2 18.1 19.4 Allowable maximum input force (kgf) (1427) (2039) (2753) (3671) Maximum static gripping force (2651) (4078) (5506) (7546) (kgf) Allowable maximum 4300 3600 3100 2500 rotation speed Standard soft jaw height (Z axis)  Gripping range φ25〜165 φ26〜210 φ30〜254 φ36〜304 (outside diameter gripping)  Mass 12.5 35.5 60.5...
  • Page 17 1.Maximum static gripping force The static gripping force is the gripping force when the chuck is at a stop. The power chuck has a mechanism to convert input force (piston thrust force, draw bar drawing force) from the cylinder  to gripping force. Therefore, the gripping force when the allowable maximum input force becomes the maximum static  gripping force. However, the gripping force is different depending on the state of grease lubrication, grease in use, height of the jaw,  etc. The maximum static gripping force specified in the  standard soft jaw specification is the value under the following conditions: ・The Kitagawa standard soft jaw is used as the jaw. ・The  attaching  bolts  of  the  soft  jaw  are  tightened  at  the specified torque. (Refer to page 9) ・The numerical values are obtained with the Kitagawa  Allowable  gripping  force  meter  .  The  gripping  position  of  the  maximum gripping force meter is at a position 1/2 of the height  input force of  the  soft  jaw  top  surface  (height  from  the  chuck ...
  • Page 18: Relationship Between Gripping Force And Rotation Speed

    As  the  rotation  speed  becomes  higher,  the  centrifugal  force  of  the  jaw  increases  and  the  gripping  force  lowers.  The  curves displayed in Fig. 6〜9 shows relationships between the rotation speed and the centrifugal force when using the  standard  soft  jaw.  The  centrifugal  force  differs  significantly  depending  on  the  size  and  shape  of  the  top  jaw  and  the  attaching  position,  therefore,  when  the  rotation  speed  is  high,  actual  measurement  using  a  Kitagawa  gripping  force  meter is required. Fig.6 N type N-05 Input  ...
  • Page 19 Fig.7 NT type NT04 NT05 Input   force 15.2 Input   force 16.8 5500 Limit Limit 1000 2000 3000 4000 5000 6000 1000 2000 3000 4000 5000 : m i n − 1 (r.p.m) : m i n − 1 (r.p.m) Rotation Speed Rotation Speed NT15 Input  ...
  • Page 20: Relationship Between Gripping Part Center Height, Static Griping Force And Input Force / Relationship Between Top Jaw Mass Moment And Gripping Force Loss

    Fig.9  NLT type NLT08 Input   force NLT06 Input   force 4300 Limit 1000 2000 3000 4000 1000 2000 3000 3600 ー 1 ー 1 Rotation Speed : m i n Rotation Speed : m i n (r.p.m) (r.p.m) NLT12 NLT10 Input   force Input   force 3100 Limit Limit 1000...
  • Page 21 DANGER ・Keep the height of the top jaw within the range of the gripping force limit table. (Refer to Fig.11-14) ・If  a  top  jaw  is  taller  than  the  standard  soft  jaw,  use  it  at  the  input  force  (piston  thrust  force,  draw  bar  drawing  force) specified in the gripping force limit table. If it is used without lowering the input, the chuck will break and  this is dangerous as the chuck and work will fly out. Fig.11 N type Input   force 15.2 22.8 Limit N-04 14.5 Standard soft top jaw Standard soft top jaw Mass moment of top jaw Gripping part center height H (㎜) m×r×3 (...
  • Page 22 Input   force N-10 Limit  80  60  40  20  0 Standard soft top jaw Standard soft top jaw Gripping part center height H (㎜) Mass moment of top jaw m×r×3 ( ㎏ ・㎜) Input   force N-12 Limit  80  60  40  20 46.5  0 1000 1200 Standard soft top jaw Standard soft top jaw Mass moment of top jaw Gripping part center height H (㎜) m×r×3 ( ㎏ ・㎜) Input   force N-15 Limit  50...
  • Page 23 Input   force Limit N-24  50  0 1000 2000 3000 4000 5000 6000 7000 Standard soft top jaw Standard soft top jaw Mass moment of top jaw Gripping part center height H (㎜) m×r×3 ( ㎏ ・㎜) Fig.12 NT type Input   force NT04 15.2 10.1 Limit  5 14.5 Standard soft top jaw Standard soft top jaw Mass moment of top jaw Gripping part center height H (㎜) m×r×2 ( ㎏ ・㎜) Input  ...
  • Page 24 Input   force Limit 26.1 NL06  5  0 Standard soft top jaw Standard soft top jaw Mass moment of top jaw Gripping part center height H (㎜) m×r×3 ( ㎏ ・㎜) Input   force NL08 Limit  0 Standard soft top jaw Standard soft top jaw Mass moment of top jaw Gripping part center height H (㎜) m×r×3 ( ㎏ ・㎜) Input   force NL10  80 Limit  70  60  50  40  30  20  10  0...
  • Page 25 Input   force Limit NL18  80  60 30kN  40  50 20kN  20   0 1000  500 1500 2000 2500 3000 Standard soft top jaw Standard soft top jaw Mass moment of top jaw Gripping part center height H (㎜) m×r×3 ( ㎏ ・㎜) Fig.14 NLT type Input   force NLT06 Limit 17.4  5  0 Standard soft top jaw Standard soft top jaw Mass moment of top jaw Gripping part center height H (㎜) m×r×2 (...
  • Page 26 NOTICE Analysis of the gripping force, input force and rotation speed using Fig. 11-14 is carried out as shown below. ・For example, in the case of N-04 standard soft jaw (mass moment 17kg・mm), it cannot exceed 6000min  (rpm),  and  the  gripping  force  loss  due  to  the  centrifugal  force  at  this  rotation  speed  is  15.2kN  (approx.  1550kgf).  The  required  static  gripping  force  for  the  dynamic  gripping  force  (gripping  force  loss  by  static  gripping  force  -  centrifugal ...
  • Page 27: Forming Soft Jaw

     4 . Forming Soft Jaw 4−1 Attachment of soft jaw The attaching position of the soft jaw can be adjusted by loosening the socket head cap screw, attaching the soft jaw  and by changing each serration engagement position. Use the most appropriate soft jaw considering the shape, dimension, material, and surface roughness of the work and  the cutting conditions, etc. DANGER ・Use the T nut so that it does not come out from the master jaw. (Refer to Fig.15) ・It if the T nut comes out from the master jaw, the master jaw and T nut will break causing the work to fly out and a  possible precision failure. Hard  jaw  T  nut Fig.15 ・Always tighten the bolts at the specified torque. If the torque is insufficient or excessive, the bolt will break, which is  dangerous as the chuck or work will fly out. Table 8 Bolt size Tightening torque Bolt size Tightening torque Bolt size Tightening torque M 6 13 N ・ m 107 N ・ m 402 N ・ m M 8 33 N ・ m 171 N ・ m 539 N ・ m 73 N ・...
  • Page 28: Forming Soft Jaw With Outside Diameter Gripping

    4−2 Forming soft jaw with outside diameter gripping 1.Preparation of the plug for forming ・Prepare  the  plug  for  forming.  The  surface  roughness  of  the  plug  outside  diameter  is  to  be  approximately  25s,  and  make  a  shape  with sufficient thickness which does not distort. ・It is convenient to prepare various outside diameter dimensions for  dimensions of forming parts. ・It  is  convenient  to  process  tapping  in  the  center  part  of  the  plug  and to guide with a bolt, etc.
  • Page 29: Forming Soft Jaw With Inside Diameter Gripping

    4−3 Forming soft jaw with inside diameter gripping 1.Preparation of the ring for forming ・Prepare  the  ring  for  forming.  The  surface  roughness  of  the  ring  inside  diameter  is  to  be  approximately  25s,  and  make  a  shape  with a sufficient thickness which does not distort. ・It is convenient to prepare various inside diameter dimensions for  dimensions of forming parts. 2.Process of the ring gripping part for forming ・Operate the switch valve and minimize the jaw to close. ・Then, process the φD part (part to grip the ring for forming). Set  the  dimension  φD  so  that  gripping  near  the  center  of  the  jaw  maximum stroke (diameter) is possible.
  • Page 30: Forming Method When You Use Forming Jig

    4−4 Forming method when you use forming jig 1.Preparation of the jig for forming Ex.1 Ex.2 Plate ・Prepare  the  jig  for  forming.  (There  is  a  commercially  available  product.) ・Attach  the  pin  (Example  1)  or  the  bolt  and  nut  (Example  2)  by  dividing equally into 3 portions onto the ring shape plate. Make the  Protrusion ring into a shape with sufficient thickness which does not distort. Bolt  and  nut 2.Gripping of the jig for forming ・Operate  the  switch  valve  and  maximize  the  opening  of  the  jaw.  Then, operate the switch valve to insert the jig for forming into the ...
  • Page 31: Usage

    ・If the protrusion of the work is long, support it with a center or the steady rest. If the protrusion is long the tip of  the work turns, and this is dangerous as the work will fly out. 5−3 Precautions related to usage of jaw DANGER ・If  a  soft  jaw  other  than  one  made  by  Kitagawa  Corporation  is  used,  the  engagement  will  be  inferior,  and  the  master jaw will be deformed, the gripping precision will worsen, and the work will fly out due to gripping failure,  which is dangerous. ・Do not use a top jaw with a different serration pitch from the master jaw. The engagement of the crests of the  serration  will  become  insufficient,  therefore,  the  serration  crests  will  break  when  gripping  the  work,  and  this  is ...
  • Page 32: Precautions Related To Processing

    5−4 Precautions related to processing DANGER <1> Unbalance ・In  the  case  of  processing  largely  unbalanced  work,  lower  the  rotation  speed.  The  work  will  fly  out  and  this  is      dangerous. ・Vibrations  are  generated  if  there  is  unbalance  owing  to  the  work  or  the  jig,  etc.  Vibration  not  only  will  impart  a  negative ...
  • Page 33 Table 10 Type A (mm)  B (mm)  C (mm) N-04, NL04, NT04 15 or less N-05, NT05 15 or less N-06, NL06, NLT06 20 or less N-08, NL08, NLT08 20 or less N-10, NL10, NLT10 20 or less N-12, NL12, NLT12 20 or less N-15, NT15 30 or less N-18, NL18 30 or less N-21 30 or less N-24 30 or less A, B: Additional process impossible dimension. C: Processible depth of tapping or drilling a hole. DANGER ・The chuck can be modified only in the manufacturer permissible range. This will not only break the chuck but the  chuck and work may fly out, which is dangerous. ・Provide a countermeasure against flying out (dwell pin, etc.) due to centrifugal force to the locator or the jig, and  attach with bolts which have sufficient strength. The locator or the jig may fly out, and this is dangerous.
  • Page 34: Maintenance And Inspection

    6−2 Grease lubrication 1.Position to lubricate ・Lubricate using a grease gun from the grease nipple on the body periphery part or each master jaw periphery part.  Supply  grease  when  the  jaw  is  open.  After  lubrication,  repeat  opening  and  closing  the  jaw  several  times  without  gripping work. 2.Grease to use ・Use the designated grease specified in Table 11. If grease other than the designated grease is used, sufficient effect  may not be obtained. Table 11 Genuine  Kitagawa genuine product CHUCK GREASE PRO product (Kitagawa distributor of each country) Kitagawa chuck grease Conventional product Molykote EP Grease TORAY Dow Corning (only inside Japan) Conventional Chuck EEZ grease Kitagawa-Northtech Inc. (North American region) product MOLYKOTE TP-42...
  • Page 35: Disassembling

    6−3 Disassembling Disassembling procedures Read the following disassembling procedures with reference to page 5. 1. Turn off the main power of the machine before starting work. 2. Loosen the jaw attaching bolt [15] and remove the soft jaw [4] and the T nut [5]. 3. Loosen the socket head cap screw (or machine screw) [14] and remove the cover [6]. 4. Remove the stop bolt [12]. 5. Loosen the set screw [16] and remove lead ball [11] (Save these parts carefully because they are small.). Loosen the   draw tube [8] and remove it from the wedge plunger [2]. (4  and 5  : The draw tube is not provided.) 6. Remove the wedge plunger [2] to the body [1] rear side. 7. Remove the master jaw [3] to the outer periphery side of the chuck. 8. The draw screw [7] is assembled in the draw tube [8] to adjust the plunger position.  Usually the draw screw may not   disassemble. Read the following procedures if it is disassembled.  Loosen the set screw [17] on the draw nut [9], and remove the draw nut [9] from the draw screw [7]. Save the steel    ball [19] and the spring [10] carefully. Assembling procedures Read the following assembling procedures with reference to page 5. Assemble again while sufficiently coating the recommended grease in the reverse procedures of disassembling. At this  time, pay sufficient attention so as not to make a mistake in the numbers of the body [1], master jaw [3], and the wedge  plunger [2]. Read the following procedures when you assemble draw screw. (Refer to Fig.19) 1. Install the draw screw [7] to draw tube [8] (4  and 5 : Plunger [2]). 2. Put the spring [10] and the steel ball [19] in a hole of the draw tube [8] (4  and 5  : draw nut [9]). 3. Install the draw nut [9] to the draw screw [7]. 4. Slightly loosen the draw nut [9] from the tightened situation and adjust the clearance between the draw nut and draw   tube [8] (4  and 5 : plunger [2]). Proper clearance: 0.05〜0.15. 5. Screw the set screw [17]. Sufficiently screw the set screw onto the draw screw [7] at the recommended torque of 1.3  〜1.4 times. 6. Stake the set screw to prevent loosing. 0.05〜0.15(Clearance) Staking Draw tube Set screw (4 or 5 :Plunger) Draw screw...
  • Page 36 CAUTION ・Use an eyebolt or a hanging belt when attaching and detaching the chuck to and from the machine, as there is a  danger of injury or damage if the chuck drops. Chuck size(inch) Eyebolt 4〜5 none 6〜10 12〜15 18〜24 WARNING ・Remove the eyebolt or the belt without fail after using. If the chuck is rotated with the eyebolt, etc., attached, they  may fly out and this is dangerous. ・Disassemble and clean the chuck at least once every 6 months or every 100,000 strokes (once every 2 months  or  more  for  cutting  cast  metal).  If  cutting  powder  or  other  substances  stagnate  inside  the  chuck,  it  will  lead  to  insufficient stroke and a drop in the gripping force, and this is dangerous as the work will fly out. Check each part  carefully and replace any part that is worn or cracked. ・After inspection, apply sufficient grease in the designated areas and reassemble. ・After assembling, measure the gripping force according to the method on page 16, and check that the specified  gripping force is obtained. ・If you stop the machine for a long period of time, remove the work from the machine. If you don't, the work can  drop due to a drop in the hydraulic pressure or the cylinder can stop or malfunction.
  • Page 37: Malfunction And Countermeasures

     7 . Malfunction and Countermeasures 7−1 In the case of malfunction Check the points specified in the table below and take the appropriate countermeasure. Table 12 Defective Cause Countermeasure The chuck inside will break. Disassemble and replace the broken part. Disassemble, correct the seized part with oilstone, etc., or replace  The chuck The sliding surface is seized. the part. does not Check the piping and the electric system, and if there is no  operate. The cylinder is not operating. abnormality, disassemble and clean the cylinder. A large amount of cutting powder is inside. Disassemble and clean. Insufficient  The draw bar loosened. Remove the draw bar and retighten it again. stroke of the jaw. Adjust so that the jaw is near the center of the stroke when  The stroke of the jaw is insufficient. gripping the work. The gripping force is insufficient. Check that the correct hydraulic pressure is obtained. The forming diameter of the top jaw is not  Form again based on the correct forming method. consistent with the work diameter. Calculate the cutting force and check that it is suitable for the  The Work The cutting force is too large. specification of the chuck. slips. Supply grease from the grease nipple, and open and close the jaw  Insufficient grease lubrication several times without gripping a work. The rotation speed is too high. Swinging occurs ...
  • Page 38: Attachment

    For Machine Tool Manufactures Following pages are described for machine tool manufacturers (personnel who attach a chuck to a machine). Please  read following instruction carefully when you attach or detach a chuck to machine, and please sufficiently understand  and follow the instructions for safe operation.  8 . Attachment 8−1 Outline drawing of attachment Cylinder adapter Top jaw Draw bar Chuck Cylinder NC lathe Support Drain hose Flexible hose Use one with large inside diameter as possible Pressure  Pump Pressure  gauge adjusting screw Manual switching valve SOL. Line filter Solenoid valve Tank Return onto the oil surface Fig.20 ・Attach the manual switching valve at a position where it is easy to operate for the attaching equipment. ・Install the hydraulic unit at a position where the drain hose is not kinked and the needle of the pressure gauge is     easily read.
  • Page 39: In The Case That The Back Plate Must Be Manufactured

    DANGER ・When other actuators are operated by the same hydraulic pressure source as the cylinder for chuck, be sure that  a  pressure  drop  of  the  cylinder  does  not  occur  during  use.  A  hydraulic  pressure  drop  leads  to  a  drop  in  the  gripping force which could allow the work to fly out. ・ As to the drain hose  ・ Use a transparent vinyl hose for visualization.  ・ Provide a stream slope, without air pocket. This will ensure no back pressure.  ・ The end of the hose is physically above the oil level. (Refer to Fig.20) ・ If the hydraulic oil stagnates inside the cylinder, oil leakage occurs, which may cause a fire. WARNING ・Install after removing the dust inside the pipe completely. ・Add  a  filter  to  the  pressure  supply  line.  If  foreign  matters  gets  inside  the  cylinder,  this  is  dangerous  since  the  rotation valve of the cylinder will seize, the hose will tear off, and the cylinder will rotate. This is also dangerous ...
  • Page 40 Table 13-2 Type Air cylinder D (min) N-04,NT04,NL04 AY1315R A-43 N-05,NT05 AY1315R A-34 N-06,NL06,NLT06 AY1720R A-151.5 N-08,NL08,NLT08 AY2225R A-182 N-10 AY2225R A-209 The dimension L in Fig.21 is determined from the distance A between the cylinder adapter and the back plate. (Example) In the combination of N-06, Y1020RE, and when A=800mm, the draw bar length L is to be  L = A − 131.5 = 800 − 131.5 = 668.5mm. At the time of the screw process of the dimension C, the precision is to be JIS 6H and 6h, 6g matching the screw of the  piston  of  the  cylinder.  Pay  attention  so  that  the  thread  parts  on  both  ends  and  the  inner  periphery  do  not  swing  or  become unbalanced.
  • Page 41 D (min) ― ― Dimension A (spigot joint diameter) conforms to the DIN standard. DANGER ・Always tighten the bolts at the specified torque. If the torque is insufficient or excessive, the bolt will break, which  is dangerous as the chuck or work will fly out. ・Use  the  bolts  attached  to  the  chuck,  and  do  not  use  other  bolts.    However,  if  you  must  use  other  bolts  not  provided by Kitagawa, use bolts that have at least a strength classification of 12.9 (10.9 for M22 or more) and be  sure they are long enough. Table 15 Bolt size Tightening torque Bolt size Tightening torque M 6 13 N ・ m 250 N ・...
  • Page 42 2.Production of draw bar Cylinder Cylinder adapter Chuck Width across flat Draw bar Clearance Fig.26 Fig.27 Table 17-1 Type Hydraulic  cylinder D (min) N-06A05 NL06A05 Y1020R A-116.5 NLT06A5 N-08A05 NL08A05 Y1225R A-145 NLT08A5 N-10A06 Y1225R A-145 NL10A06 Y1530R A-145 NLT10A6 N-10A08 Y1225R A-171 NL10A08 Y1530R A-171 NLT10A8 N-12A06 Y1530R A-150 NLT12A6 Table 17-2 Type...
  • Page 43 Hex key Set  screw Lead ball Wedge plunger Draw tube Fig.28 2.Attaching the draw bar to the cylinder ・Apply adhesive onto the screw part of the draw bar, and screw it into the piston rod of cylinder. At this time, refer to   the instruction manual for the cylinder for tightening torque. NOTICE ・When  attaching  the  draw  bar  to  the  cylinder,  the  stopper  pin  of  the  piston  may  break  if  tightened  at  the  stroke  middle position of the piston. In the case of a Y type cylinder, screw it in so that the piston rod is fully in. Follow  the explanation of the instruction manual for the cylinder for other items about the cylinder. ・Use the cylinder that matched the stroke of the chuck. The cover is damaged if you use the cylinder that have  longer stroke than the chuck, because the jaws move for a long distance. 3.Attach the cylinder to the spindle (or the cylinder adapter) ・Check the run-out of the cylinder, and if it is normal, attach the hydraulic pipe. ・Move 2 to 3 times at low pressure (0.4 MPa-0.5 MPa, 4 - 5 kgf/cm ) and set the piston at the forward end and turn off   the power supply. CAUTION Chuck size(inch) Eyebolt...
  • Page 44 5.Attach the chuck matching to the attaching surface of the spindle (or the back plate). ・Turn the handle for connection to make a state that the chuck closely contacts the spindle attaching surface of the lathe. ・In the case of adjusting the centering of the chuck, lightly hit the body side face with a plastic hammer. ・Tighten the chuck attaching bolts evenly. At this time, tighten the bolts at the specified torque. DANGER ・Always tighten the bolts at the specified torque. If the torque is insufficient or excessive, the bolt will break, which  is dangerous as the chuck or work will fly out. ・Use  the  bolts  attached  to  the  chuck,  and  do  not  use  other  bolts.    However,  if  you  must  use  other  bolts  not  provided by Kitagawa, use bolts that have at least a strength classification of 12.9 (10.9 for M22 or more) and be  sure they are long enough. Table 18 Bolt size Tightening torque Bolt size Tightening torque 13 N ・ m 250 N ・ m 33 N ・...
  • Page 45: Other Information

     9 . Other information 9−1 About standards and orders This product is based on the following standards or orders.  ・ Machinery directive : 2006/42/EC Annex I  ・ EN ISO 12100 : 2010  ・ EN1550 : 1997+A1 : 2008 9−2 Information about markings of product Manufacturer's logo Type of Jaw No. top jaws F MAX:MAX PERMISSIBLE INPUT FORCE ΣS MAX:MAX STATIC GRIPPING FORCE Manufacturer's N MAX:MAX PERMISSIBLE  SPEED address MASS:MASS Specifications Type MFG No. Jaw No. Stroke mark Fig.30 9−3 About disposal Ultimate disposal of this product should be handled according to all national laws and regulations.
