Seating system
Sedeo Pro
Instructions for Use
000690790.GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QUICKIE Sedeo Pro and is the answer not in the manual?

Questions and answers

Related Manuals for Sunrise Medical QUICKIE Sedeo Pro

Summary of Contents for Sunrise Medical QUICKIE Sedeo Pro

  • Page 1 Seating system Sedeo Pro Instructions for Use 000690790.GB...
  • Page 2 Wheelchair Components We at SUNRISE MEDICAL have been awarded the ISO-13485 certificate, which affirms the quality of our products at every stage, from R & D to production. Options or accessories shown are available at extra cost. Sedeo Pro | Rev.F...
  • Page 3 If you have any queries about the use, maintenance or safety of your seating system, please contact your local approved Sunrise Medical service agent. If you do not know of an approved dealer in your area or have any other questions please write or telephone:...

  • Page 4: Table Of Contents

    Contents 1.0 User information  ..........5 6.0 Manual and Powered seating options  ....33 1.1 This user manual  ������������������������������������������������������5 6.1 Manual seating options  �����������������������������������������33 1.2 For further information  ��������������������������������������������5 6.2 (Powered) seating options  �������������������������������������34 1.3 Symbols used in this manual  ������������������������������������5 7.0 Reducing the seating system size for transportation purposes  ............35 2.0 Safety  ..............6 7.1 Seat cushion ...

  • Page 5: User Information

    In case there is no authorized dealer in your area or you have any questions, contact Sunrise Medical either in writing or by telephone. For information about product safety notices and product recalls, go to www.SunriseMedical.co.uk...

  • Page 6: 2.1 Seating Related Symbols And Labels Used On The Product

    2.0 Safety Fig. 2.1 Follow the instructions carefully next to these warning symbols! Not paying careful attention to these instructions could result in physical injury or damage to the wheelchair or the environment. Wherever possible, safety information is provided in the relevant chapter. 2.1 Seating related symbols and labels used on the product The signs, symbols and instructions affixed to the wheelchair comprise part of the safety facilities.

  • Page 7: Safety: Trays

    2.5 Safety: Trays Safety: Vent tray DANGER! / WARNING! Using a vent tray will affect the stability and overall weight of your wheelchair. • Make sure that the batteries and the ventilator are securely fastened to the tray before use. •...

  • Page 8: Setting Up The Seating System

    4.0 Setting up the seating system Fig. 4.1 The average wheelchair user does not exist. This is why Sunrise Medical wheelchairs can be pre-set according to specific needs of the user. Pre-settings are carried out once, the first time the wheelchair is going to be used.

  • Page 9: Pre-Set Seat Width

    4.2 Pre-set seat width Fig. 4.5 Flip back armrests / Single Post Removable armrests width (Fig. 4.5) Fine adjustments can be done with the armrest only, for larger adjustments also pre-set the seat plate width. 1. Loosen (A) by one turn. 2.

  • Page 10: Pre-Set Backrest

    4.3 Pre-set backrest Fig. 4.8 Backrest angle (Fig. 4.8) 1. Turn (A) in order to adjust (B). NOTE / CAUTION! Do NOT use an electric tool for this adjustment. Backrest angle home position of reclining back (Fig.4.9 - 4.10) 1. Adjust the back to the required angle with the controller. 2.
  • Page 11 Backrest height with reclining back (Fig. 4.12) Fig. 4.12 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3. Tighten (A). Backrest Flexible lateral support angle (Fig. 4.13) 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3.

  • Page 12: Pre-Set Flip Back Armrests / Single Post Removable

    4.4 Pre-set Flip back armrests / Single post removable Fig. 4.16 armrests Armrest height (figure 4.16) 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3. Tighten (A). Ensure that the arms are supported well, without the shoulders being pushed upwards.
  • Page 13 Armrest pad width (figure 4.19-4.22) Fig. 4.19 To remove: 1. Loosen (A). 2. Remove (B). 3. Loosen (E) by one turn. 4. Remove (F). To position: 1. Slide (A) together with B or C onto D NOTE / CAUTION! Fig. 4.20 Ensure that the ridge on the terminal block falls into the opening 1.
  • Page 14 Armrest angle (figure 4.23) Fig. 4.23 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3. Tighten (A). Side guard height (figure 4.24) 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3.

  • Page 15: Pre-Set Reclining Flip Back Armrests

    4.5 Pre-set Reclining flip back armrests Fig. 4.25 Armrest height Fine or gross adjustment it is a two-part process: PART 1 (Fig. 4.25) 1. Turn (A) in order to adjust (B). PART 2 (Fig. 4.26) 1. Loosen (A) by one turn 2.

  • Page 16: Pre-Set Multi-Adjustable Armrests

    4.6 Pre-set Multi-Adjustable armrests Fig. 4.28 Armrest height Fine or gross adjustment, it is a two-part process: Part 1 (Fig. 4.28) 1. Loosen (A) in order to adjust (B). Part 2 (Fig. 4.29) 2. Loosen (A) in order to adjust (B). 3.

  • Page 17: Pre-Set Seat Width

    4.7 Pre-set seat width Fig. 4.33 Pre-set the armrest width: NOTE: Only if the armrest width adjustment of Fig.4.31 & 4.32 is not enough, the armrest axle can be moved out. • Loosen the two screws (5.0mm Allen key) on the traversing tube as shown in (Fig.

  • Page 18: Side Guard

    4.8 Side guard Fig. 4.34 Side guard height (Fig. 4.34) 1. Unscrew (A). 2. Adjust (B) to the desired position. 3. Tighten (A). Side guard depth (Fig. 4.35) 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3.

  • Page 19: Pre-Set Center Mount Legrest

    4.10 Pre-set center mount legrest Fig. 4.38 Lower leg length (Fig. 4.38) A L+R 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3. Tighten (A). NOTE / CAUTION! Ensure that there is sufficient free space under (B) for the wheelchair to drive over obstacles.

  • Page 20: Pre-Set Fixed Center Mount Legrest

    4.11 Pre-set Fixed center mount legrest Fig. 4.42 Lower leg length (Fig. 4.42) 1. Loosen (A) by one turn 2. Adjust (B) to the desired position 3. Tighten (A) 4. Repeat for the other side. Ankle angle (Fig. 4.43) 1. Flip up (A). 2.

  • Page 21: Pre-Set Power Center Mount Legrest

    4.12 Pre-set power center mount legrest Fig. 4.45 DANGER! / WARNING! • Be aware of your environment to make sure you do not injure your legs when Leg Rests are extended. • Always ensure that the Leg Rests or foot plates do not come into contact with the castors before driving the wheelchair.

  • Page 22: Pre-Set Swing Away Legrests

    4.13 Pre-set swing away legrests Fig. 4.50 Legrest width (Fig. 4.50) 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3. Tighten (A). Lower leg length (Fig. 4.51) 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3.

  • Page 23: Pre-Set Headrest

    Calf pad height (Fig. 4.54) Fig. 4.54 1. Loosen (A) a few turns. 2. Adjust (D) to the desired position. 3. Tighten (A). Calf pad depth (Fig. 4.54) 4. Loosen (B) a few turns 5. Adjust (D) to the desired position. 6.

  • Page 24: Pre-Set Fixed / Swing Away Controller Bracket

    Headrest cushion width position (Fig. 4.58) Fig. 4.58 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3. Tighten (A). Fig. 4.59 4.15 Pre-set fixed / swing away controller bracket Depth of the controller (Fig. 4.59) 1.

  • Page 25: Pre-Set Thigh Support

    4.16 Pre-set thigh support Fig. 4.62 Thigh support height (Fig. 4.62) 1. Loosen (A) by one turn. 2. Adjust to the desired position. 3. Tighten (A). Thigh support depth (Fig. 4.62) 1. Loosen (A) by one turn and lift thigh support. 2.

  • Page 26: Pre-Set Laterals

    4.17 Pre-set laterals Fig. 4.64 Laterals width (Fig. 4.64) 1. Loosen (A) completely. 2. Adjust (B) to the desired position. 3. Tighten (A). Laterals height (Fig. 4.65) 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3.

  • Page 27: Pre-Set Lateral Swing Away Knee Support

    4.18 Pre-set lateral swing away knee support Fig. 4.68 Knee support depth (Fig. 4.68) 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3. Tighten (A). Fig. 4.69 4.19 Pre-set pommel Pommel height (Fig. 4.69) 1. Loosen (A) by one turn. 2.

  • Page 28: Lap Strap / Seating Positioning Belt

    4.20 Lap strap / seating positioning belt Fig. 4.71 DANGER! / WARNING! • This product is only to be used to position a single person in a wheelchair. • Lap straps are not suitable for transit purposes, approved occupant restraint systems must be used. •...

  • Page 29: Using The Seating System

    Fig. 5.1 5.1 Getting in and out of the wheelchair (Transferring) Sunrise Medical recommend that you consult your healthcare professional for assistance in developing your personal front or side transfer technique to best suit your needs and avoid any personal injury.

  • Page 30: Preparing For Side Transfer

    5.3 Preparing for side transfer Fig. 5.4 DANGER! / WARNING • Move your system as close as you can to the seat you are transferring to. If possible, use a transfer board. • Transfer as far back onto the seat surface as you can. This will reduce the risk that you will miss the seat or fall.

  • Page 31: Headrest

    5.4 Headrest Fig. 5.9 Removing/positioning the headrest (Fig. 5.9) 1. Lift (A). 2. Slide (B) out of or into (C). 3. Push (A) down. Fig. 5.10 5.5 Swing-away controller bracket The joystick is mounted with a mechanism that allows the joystick to be locked in two forward positions.

  • Page 32: Knee Support

    5.7 Knee support (Fig. 5.13) Fig. 5.13 1. Loosen A to swing away B 5.8 Thigh support (Fig. 5.14) 1. Loosen (A) by one turn 2. Remove (B) Fig. 5.14 5.9 Hemiplegia armrest (Fig. 5.15) 1. Pull (A) out of the locked position and twist(B) into the desired position.

  • Page 33: Manual And Powered Seating Options

    6.0 Manual and Powered seating options Fig. 6.1 6.1 Manual seating options Manually reclining backrest (by user) (Fig. 6.1) 1. Squeeze (A). 2. Lean forwards or backwards to adjust (B) to the desired position. NOTE / CAUTION Keep squeezing (A). 3.

  • Page 34: Powered) Seating Options

    4.5kph/3mph when the seat is elevated, this feature is called C-Me. For guidance with user weight limits and recommended chair configuration when using C-Me, please refer to your Sunrise Medical authorized dealer. Note: User weight is restricted to a maximum of 136kg in combination with the C-Me option.

  • Page 35: Reducing The Seating System Size For Transportation

    7.0 Reducing the seating system size for transportation Fig. 7.1 purposes DANGER! / WARNING! The wheelchair can be reduced in size for transportation without a passenger. Any components of the seating system that can be detached easily should be removed. Store away such components safely so that they can not cause injury or damage, or become damaged themselves.

  • Page 36: Flip Down Backrest Quick Release

    7.3 Flip down backrest quick release (Fig. 7.4) Fig. 7.4 Folding the backrest fully forward 1. Loosen (A). 2. Fold (B) fully forward. NOTE / CAUTION If necessary, first remove the back cushion and/or the armrest assemblies. 7.4 Folding down backrest with reclining armrests Fig.

  • Page 37: Swing Away Legrests

    7.6 Swing away legrests (Fig. 7.7) Fig. 7.7 Removing a swing-away legrest 1. Loosen the calf band. 2. Push the catch (A) to the rear in order to unlock the leg rest. 3. Swing the leg rest outwards. 4. Remove the leg rest (B) from its bracket by lifting. You should hear a click when replacing the leg rest.

  • Page 38: Maintenance And Cleaning

    Ensure surfaces are rinsed well with clean • If a broken or loose component is found, discontinue use water and dried thoroughly. immediately and contact your authorised Sunrise Medical supplier for replacement. • Check all Velcro fastening straps for correct adhesion when 8.3 Hygiene measures when being re-used:...

  • Page 39: General Cleaning Instructions

    8.4 General cleaning instructions: 8.6 Cleaning controls: Should the control of your wheelchair become soiled or dirty, NOTE / CAUTION! it can be wiped with a damp cloth with a dilute disinfectant • You should remove stains on your seat as soon as possible. until clean.

  • Page 40: Disposal

    9.0 Disposal The symbols below mean that in accordance with local laws and regulations your product should be disposed of separately from household waste. When this product reaches the end of its life, take it to the local collection point designated by local authorities. The separate collection and recycling of your product at the time of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects the environment.

  • Page 41: Technical Specifications

    10.0 Technical specifications: 10.1 Applicable norms / standards EN-ISO10993-5: 2009 Biological evaluation of medical devices. EN 1021 1&2 Assessment of the ignitability of upholstered furniture. Ignition source: smouldering cigarette/ match lame equivalent. Sedeo Pro | Rev.F | English...

  • Page 42: Technical Specifications

    10.2 Technical specifications: SEDEO Pro seating system Imperial system values & Metric system values alternative Minimum Maximum Minimum Maximum Seat angle adjustment Powered tilt with COG adjustment optional 0° - 30° -5° - 25° Powered tilt with COG adjustment optional -5°...
  • Page 43 Imperial system values & Metric system values alternative Minimum Maximum Minimum Maximum Power Center Mount Legrest Lower leg length (from seatplate) 360 mm 540 mm 14.2" 21.2" Knee angle 90° - 180° 90° - 180° Max length compensation 260 mm 10.2"...

  • Page 44: Sedeo Pro Hd Seating System

    10.3 Technical specifications: SEDEO Pro HD seating system Metric system values Imperial system values & alternative Minimum Maximum Minimum Maximum Seat angle adjustment Powered tilt with COG adjustment optional 0° - 30° -5° - 25° Powered tilt with COG adjustment optional -5°...
  • Page 45 Metric system values Imperial system values & alternative Minimum Maximum Minimum Maximum Swing away legrests Lower leg length (from seatplate) 350 mm 510 mm 13.8" 20.1" Knee angle 70° 70° Ankle angle 0° - 180° 0° - 180° Swing away legrests, manual elevating / power elevating Lower leg length (from seatplate) 350 mm...

  • Page 46: Guarantee / Warranty

    Additional Notes For Australia Only: ANY WAY. For goods provided by Sunrise medical Pty Ltd in Sunrise Medical* provides a guarantee, as set out in the Australia, our goods come with a guarantee by Sunrise warranty conditions, for wheelchairs to its customers covering Medical that cannot be excluded under Australian the following.
  • Page 47 Sedeo Pro | Rev.F...
  • Page 48 Sunrise Medical GmbH Sunrise Medical S�r�l� Kahlbachring 2-4 Via Riva, 20 – Montale 69254 Malsch/Heidelberg 29122 Piacenza Deutschland Italia Tel.: +49 (0) 7253/980-0 Tel�: +39 0523 573111 Fax: +49 (0) 7253/980-222 Fax: +39 0523 570060 www.SunriseMedical.de www�SunriseMedical�it Sunrise Medical AG Sunrise Medical Erlenauweg 17 Thorns Road CH-3110 Münsingen Brierley Hill...
