- Page 1 2 0 2 5 S C O T T P A T R O N / P A T R O N S T M A N U A L 2024 PATRON | ENGLISH 1 |...
-
Page 2: Table Of Contents
THE PATRON / PATRON ST SHOULD BE ADJUSTED EXACTLY TO THE RIDER FOR MAXIMUM SAFETY AND RIDEABILITY. Please contact your authorized SCOTT dealer for advice in order to avoid technical problems or any harm. GEOMETRY & TECHNICAL DATA HEADSET ADJUSTMENT... -
Page 3: Geometry & Technical Data
PATRON GEOMETRY & TECHNICAL DATA SEATPOST HARDWARE M.FRAME 31.6 Trunnion SEATPOST CLAMP HARDWARE LINKAGE 34.9 8 x 20 TRAVEL MAX TYRE WIDTH SHOCK LENGTH CHAINLINE SHOCK STROKE MAX CHAINRING Tooth 36 MAX ROTOR REAR AXLE 12 x 148 200 Rr 200 Fr HEADSET O52/142 - O52/140 BOSCH CONNECT MODULE not compatible... - Page 4 PATRON PATRON GEOMETRY & TECHNICAL DATA CONT. There will be a stop inside the seat tube to avoid damaging the frame internals. MAX INSERTION (MM): SMALL: 205 MEDIUM: 232 LARGE: 267 XL: 298 All Patron bikes will use the UDH hanger. 2024 PATRON | ENGLISH 4 |...
-
Page 5: Headset Adjustment
PATRON PATRON HEADSET ADJUSTMENT SLACK STEEPER It is important to install the headset correctly depending on the setup required. Make sure the angle indication markers are set opposite each other. Bikes will be delivered with 0,6° cups installed. CUP SIZE (MM): SMALL: 120, MEDIUM: 125, LARGE: 135 XL: 135 288251 SYN HEADSET ZS56/28.6 - ZS56/40 MTB 290060 SCO HEADSET CUP KIT SPARK 22 DO NOT USE A STANDARD HEADSET TOOL! -
Page 6: Battery Installation
PATRON PATRON BATTERY INSTALLATION BATTERY FIXATION MUST ONLY BE CARRIED OUT BY A SCOTT AUTHORISED DEALER USING THE CORRECT GAUGE AND TOOLING ! ITEM QTY DESCRIPTION BOSCH ITEM SCOTT 424333 SCO eRIDE Bosch Battery Battery Cradle Inverted EN12.200.0U0 mount Option 8... - Page 7 PATRON PATRON BATTERY INSTALLATION CONT. Insert the battery, bottom end first. Turn and hold the key and press in the battery, you will hear the first click. Place the bottom part of the battery Let go of the key, then push the cover into position.
- Page 8 PATRON PATRON BATTERY INSTALLATION CONT. Lift up the lock tab, then press the cover into place. You will hear a click when engaged fully. 2024 PATRON | ENGLISH 8 |...
-
Page 9: Motor Installation
PATRON PATRON MOTOR INSTALLATION MOTOR FIXATION MUST ONLY BE CARRIED OUT BY A SCOTT AUTHORISED DEALER USING THE CORRECT TOOLING ! ITEM DESCRIPTION BOSCH ITEM Drive Unit CX BDU38YY EB11.100.01C DU BDU38YY Lockring EB11.200.0JH O-Ring 1270016119 Drive Unit Bezel EB11.200.0KD Front Motor Bolt Wide EB11.200.0T1... -
Page 10: Shock And Shock Cover
PATRON PATRON SHOCK AND SHOCK COVERS Scott Nude 6 rear shock cover is latched at the Piggy back rear shock cover only covers half top and magnetic as the base, it will cover the the opening, with a small base plate. Both parts complete shock. -
Page 11: Bosch Powermore
PATRON PATRON BOSCH POWERMORE Patron’s are Bosch PowerMore ready, no configuration update is required. You will need the follow Bosch parts: BOSCH POWERMORE HOLDER: EB12.110.01Q BOSCH POWERMORE CABLE 250mm: EB12.120.08J 2024 PATRON | ENGLISH 11 |... -
Page 12: Cable Routing
PATRON PATRON CABLE ROUTING Cable routing overview FOR BOSCH COMPONENT CONNECTIONS PLEASE CONSULT YOUR AUTHORISED SCOTT SPORTS DEALER ! 2024 PATRON | ENGLISH 12 |... -
Page 13: Rear Brake Cable Routing
PATRON PATRON CABLE ROUTING CONT. REAR BRAKE CABLE ROUTING Guide from the brake calliper to brake lever, enter mid point in the chainstay, exit front of the chainstay, then enter the main frame. Cross behind the shock on the drive side, through the seat tube on the drive side. Zip tie to the frame cable holder, then zip tie to the shock cover plate. - Page 14 PATRON PATRON CABLE ROUTING CONT. REAR SHOCK CABLE ROUTING Guide from the handlebar lever to the shock. Enter the headtube on the left side, and along the inside of the top tube. Zip tie to the shock cover plate on the drive side. 2024 PATRON | ENGLISH 14 |...
- Page 15 PATRON PATRON CABLE ROUTING CONT. REAR DERAILLEUR CABLE ROUTING Guide from the shifter to the rear derailleur. Enter the headtube on the right side and along the inside of the top tube. First attach to the left side of the shock cover plate, then again to the left side frame cable holder.
- Page 16 PATRON PATRON CABLE ROUTING CONT. DROPPER SEATPOST CABLE ROUTING Guide from dropper lever to the post, enter at the head tube on the left side and along the inside of the top tube. Install a protective tube to the dropper cable. Then first zip tie the protective tube to the shock cover plate left side of the shock cover (1), then again to the left side frame cable holder (2).
- Page 17 PATRON PATRON CABLE ROUTING REAR LIGHT CABLE ROUTING Guide from the motor to the light. The cable must go above the chainstay / seatstay pivot, and enter the main frame via the main cable guide. 2024 PATRON | ENGLISH 17 |...
-
Page 18: General Spare Parts
PATRON PATRON GENERAL SPARE PARTS (illustration only) 286000 SCO DROPOUT SRAM UDH 21 Reverse Thread 25 Nm 290016 SCO AXLE RWS REAR 148X12 SPARK PLUG 22 10 Nm 297749 SCO eRIDE BOSCH RIM SPEED SENSOR 22 424177 SCO eRIDE MOTOR COVER OPTION 7 PATRON 25 5 Nm T 25 424174 SCO eRIDE SHOCK COVER PATRON 25... - Page 19 PATRON PATRON GENERAL SPARE PARTS (illustration only) 424175 SCO eRIDE SHOCK COVER PB PATRON 25 T 15 3 Nm 425428 SCO eRIDE BAT COVER PATRON 25 T 15 3 Nm 424169 SCO eRIDE CHARGE PORT ASSEMBLY SPIN 25 T 20 424183 SCO eRIDE TT REMOTE ADAPT PATRON CARB 25 T 10 0.5 Nm...
- Page 20 PATRON PATRON GENERAL SPARE PARTS (illustration only) 424392 SCO eRIDE SEATPOST CLAMP PATRON CB 25 6 Nm T 25 424169 SCO eRIDE CHARGE PORT ASSEMBLY SPIN 25 T 10 2 Nm 424541 SCO eRIDE DT CABLE HOLDER PATRON 25 (for Bosch wires only) 2024 PATRON | ENGLISH 20 |...
-
Page 21: Manufacture's Guarantee
SCOTT, the duration of the manufacturer’s guarantee is limited to two years. If a defect on the SCOTT bicycle is remedied within the scope of a manufacturer’s guarantee or a warranty claim, the duration of the manufacturer’s guarantee is not extended. The manufacturer’s guarantee ends, when the first-time buyer transfers ownership of the SCOTT bicycle to a third person. - Page 22 À DÉPOSER À DÉPOSER EN MAGASIN EN DÉCHÈTERIE 2024 PATRON | ENGLISH 22 |...
