Summary of Contents for Scott ADDICT GRAVEL 2022
- Page 1 ADDICT GRAVEL MY22 TECH MANUAL...
- Page 2 Geometry & Technical Data: Seatpost: Addict Aero Seatpost Clamp: Addict Aero Fork Steerer: 1 1/4 - 1 1/2 Ⓒ Ⓛ IS52 /31,8 – IS Headset: 52/40 Ⓑ Ⓘ Ⓗ Rear Axle: 142mm Ⓓ Front Axle: 100mm BB Housing: 41x86.5mm Ⓙ Ⓐ...
- Page 3 Axles & Dropouts: The new Addict Gravel will have same dropout as the Addict RC and the rest of the Addict family. The Hanger comes in standard and DM options and includes dropout, threaded axle cap, and fixation bolt. 277544 SCO Dropout Addict RC 20 277545 SCO Dropout Addict RC direct mount 20 Front and rear axles are available in two variations;...
- Page 4 Cockpit: The new Addict Gravel will have fully integrated cable routing through the stem and headset, with a gravel specific handlebar from Syncros with 16-degree flare and shorter reach. The Addict Gravel will have two different stem/handlebar options depending on the bike model.
- Page 5 294283 SCO Stem cable cover Speed/Addict 22 The Stem Cable Cover is size specific to the RR2.0/2.5 stem. XXS: 83 mm XS: 93 mm Small: 103 mm Medium/Large: 113 mm XL/XXL: 123mm 277550 SCO Stem steerer cap SY Crest iC Creston iC SL X will use the same Stem cap as Addict RC Creston Handlebars, not size specific.
- Page 6 FD / Chainguide: 290023 SCO FD kit Addict Gravel 22 Includes chainguide, FD mount and FD cable guide blanks Cable Guides & Protection Kits: The new Addict Gravel has several mounts for fitting of bags, fenders, and extra bottle cages. The following kit contains the cable guides and blanks for the different frame and fender mounts.
-
Page 7: Cable Routing
Dedicated fenderset for the Addict Gravel: 288344 SYN Road gravel fender set for AL/CB 290019 SCO C-Stay protection kit Addict gra 22 Cable Routing: ENGLISH / PATRON TECH MANUAL... - Page 8 ADDICT CONTESSA ADDICT TECH MANUAL ENGLISH / SPARK TECH MANUAL...
- Page 9 Geometry & Technical Data: Seatpost: 27.2mm Seatpost Clamp: 31.2mm Fork Steerer: 1 1/4 - 1 1/2 Ⓒ IS52 /31,8 – IS Headset: Ⓛ 52/40 Ⓑ Rear Axle: 142mm Ⓘ Ⓗ Front Axle: 100mm Ⓓ BB Housing: 41x86.5mm Max/Min Front Ⓙ Ⓐ...
- Page 10 Axles & Dropouts: The new Addict will have same dropout as the Addict RC and the rest of the addict family. The Hanger comes in standard and DM options and includes dropout, threaded axle cap, and fixation bolt. 277544 SCO Dropout Addict RC 20 277545 SCO Dropout Addict RC direct mount 20 Front and rear axles are available in two variations;...
- Page 11 Cockpit: There will be a new handlebar and stem for the new Addict. RR.2.0 and RR2.5, with integrated cable routing under the stem. This means you can fit a standard handlebar to the stem and still have full cable integration. 288123 SYN Stem RR 2.0 294283 SCO Stem cable cover Speed/Addict 22 The Stem Cable Cover is size specific to the stem.
- Page 12 The new Addict is fender compatible with the new fenderset from Syncros. 288343 SYN Road endurance fender set for AL/CB Cable Guide Kit: The following kit contains the cable guides and blanks for the different frame and fender mounts. 290022 SCO Cableguide / blank set Addict GR 22 Cable Routing: ENGLISH / PATRON TECH MANUAL...
- Page 13 SPEEDSTER CONTESSA SPEEDSTER TECH MANUAL ENGLISH / SPARK TECH MANUAL...
- Page 14 Geometry & Technical Data: Seatpost: 27.2mm Seatpost Clamp: 31.8mm Ⓒ Fork Steerer: 1 1/4 - 1 1/2 Ⓛ IS52 /31,8 – IS Ⓑ Headset: Ⓘ Ⓗ 52/40 FD Clamp: 31.8mm Ⓓ Rear Axle: 142mm Front Axle: 100mm Ⓙ Ⓐ BB A-Frame: 41x86.5mm Ⓔ...
- Page 15 Axles & Dropouts: The Hanger will come in standard and DM options. It will include the threaded axle caps and fixation bolts. 239530 Dropout Hanger Solace Disc ‘15< 264483 SCO Dropout 142x12 DM Addict/Foil D’17 Front and rear axles are available in two variations; Standard version: 283340 SCO Axle Foil/Addict/Speedster D R 21 283341 SCO Axle Foil/Addict/Speedster D F 21...
- Page 16 The new Speedster is fender compatible with the new fenderset from Syncros. 288343 SYN Road endurance fender set for AL/CB Cable Guide Kit: The following kit contains the cable guides and blanks for the different frame and fender mounts. 290022 SCO Cableguide / blank set Addict GR 22 Cable Routing: ENGLISH / PATRON TECH MANUAL...
- Page 17 SPEEDSTER GRAVEL CONTESSA SPEEDSTER GRAVEL TECH MANUAL ENGLISH / SPARK TECH MANUAL...
- Page 18 Geometry & Technical Data: Seatpost: 27.2mm Seatpost Clamp: 31.8mm Ⓒ Fork Steerer: 1 1/4 - 1 1/2 Ⓛ IS52 /31,8 – IS Ⓑ Headset: Ⓘ Ⓗ 52/40 FD Clamp: 31.8mm Ⓓ Rear Axle: 142mm Front Axle: 100mm Ⓙ Ⓐ BB A-Frame: 41x86.5mm Ⓔ...
- Page 19 Axles & Dropouts: The Hanger will come in standard and DM options. It will include the threaded axle caps and fixation bolts. . 239530 Dropout Hanger Solace Disc ‘15< 264483 SCO Dropout 142x12 DM Addict/Foil D’17 Front and rear axles are available in two variations; Standard version: 283340 SCO Axle Foil/Addict/Speedster D R 21 283341 SCO Axle Foil/Addict/Speedster D F 21...
- Page 20 The new Speedster Gravel is fender compatible with the new fenderset from Syncros. 288344 SYN Road gravel fender set for AL/CB Cable Guide Kit: The following kit contains the cable guides and blanks for the different frame and fender mounts. 290022 SCO Cableguide / blank set Addict GR 22 Cable Routing: ENGLISH / PATRON TECH MANUAL...
- Page 21 SCOTT Sports SA reserves the right to change the content of this techbook, particularly colors, materials and specifications, at any time without prior notice. Any liability shall be exempted. Products shown may not be available in all regions, please check with your local SCOTT retailer for availability. EDITOR...
