NI NI 9436 8-Channel C Series Digital Module Limited Availability New From Surplus Stock Open Web Page https://www.artisantg.com/96734-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
Page 2
GETTING STARTED GUIDE NI 9436 8 DI, ±100 VDC to ±250 VDC/100 VAC to 250 VAC, Sinking/Sourcing, 20 ms hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
This document explains how to connect to the NI 9436. Before you begin, complete the software and Note hardware installation procedures in your chassis documentation. The guidelines in this document are specific to Note the NI 9436. The other components in the system might not meet the same safety ratings.
115 V for U.S. or 230 V for Europe. Do not connect the NI 9436 to signals or use Caution for measurements within Measurement Categories III or IV. Safety Guidelines for Hazardous Voltages If hazardous voltages are connected to the device, take the following precautions.
In addition, take precautions when designing, selecting, and installing measurement probes and cables to ensure that the desired EMC performance is attained. 6 | ni.com | NI 9436 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
Preparing the Environment Ensure that the environment in which you are using the NI 9436 meets the following specifications. Operating temperature -40 °C to 70 °C (IEC 60068-2-1, IEC 60068-2-2) Operating humidity 10% RH to 90% RH, (IEC 60068-2-78) noncondensing...
Page 11
Sourcing-Output Device NI 9436 The NI 9436 channel registers as ON when the sourcing-output device drives enough current or applies enough voltage to DI. If no device is connected to DI, the channel registers as OFF. 10 | ni.com | NI 9436 Getting Started Guide...
Page 13
NI 9436 Connection Guidelines Make sure that devices you connect to the NI 9436 are compatible with the module specifications. You must use 2-wire ferrules to create a secure connection when connecting more than one wire to a single terminal on the NI 9436.
Page 15
16-Position Screw Terminal Connector (2) and tighten the screw. Make sure no exposed wire extends past the screw terminal. 14 | ni.com | NI 9436 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
Page 17
1. Insert the stripped end of the wire fully into the appropriate terminal on the 16-Position Screw Terminal Connector (2) 16 | ni.com | NI 9436 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
LabVIEW Help RELATED INFORMATION C Series Documentation Services & Resources ni.com/services ni.com/info cseriesdoc Located at ni.com/manuals Installs with the software 18 | ni.com | NI 9436 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
