  • Page 1 NI NI 9475 8-Channel C Series Digital Output Module Limited Availability New From Surplus Stock Open Web Page https://www.artisantg.com/96743-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 GETTING STARTED GUIDE NI 9475 8-Channel, 60 V, High-Speed, Sourcing Digital Output Module hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 3 This document explains how to connect to the NI 9475. Before you begin, complete the software and Note hardware installation procedures in your chassis documentation. The guidelines in this document are specific to Note the NI 9475. The other components in the system might not meet the same safety ratings.
  • Page 4 Such voltage measurements include signal levels, special equipment, limited-energy parts of equipment, circuits powered by regulated low-voltage sources, and electronics. NI 9475 Getting Started Guide | © National Instruments | 3 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 5 Do not connect the NI 9475 to signals or use Caution for measurements within Measurement Categories II, III, or IV. Safety Guidelines for Hazardous Voltages If hazardous voltages are connected to the device, take the following precautions. A hazardous voltage is a voltage greater than 42.4 Vpk voltage or 60 VDC to earth ground.
  • Page 6 Safety Guidelines for Hazardous Locations The NI 9475 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4 and Ex nA IIC T4 hazardous locations; and nonhazardous locations only.
  • Page 7 Zone 2 hazardous locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI 9475 in Gas Group IIC hazardous locations, you must use the device in an NI chassis that has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
  • Page 8 To minimize interference with radio and television reception and prevent unacceptable performance degradation, install and use this NI 9475 Getting Started Guide | © National Instruments | 7 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 9 In addition, take precautions when designing, selecting, and installing measurement probes and cables to ensure that the desired EMC performance is attained. 8 | ni.com | NI 9475 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 10 Preparing the Environment Ensure that the environment in which you are using the NI 9475 meets the following specifications. Operating temperature -40 °C to 70 °C (IEC 60068-2-1, IEC 60068-2-2) Operating humidity 10% RH to 90% RH, (IEC 60068-2-78) noncondensing...
  • Page 11 Vsup Vsup Signals Each channel of the NI 9475 has a DO pin to which you can connect a device. Each channel also has a COM pin and a Vsup 10 | ni.com | NI 9475 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 12 Connecting an External Power Supply You must connect an external power supply to the NI 9475. This power supply provides the current for the devices you connect to the module. Connect the positive lead of the power supply to Vsup and the negative lead of the power supply to COM.
  • Page 13 Connecting a Device You can directly connect the NI 9475 to a variety of industrial devices such as solenoids, motors, actuators, relays, and lamps. Make sure the devices you connect to the NI 9475 are compatible with the output specifications of the module.
  • Page 14 You must turn all parallel channels on and off simultaneously so that the current on any single channel cannot exceed the 1 A rating. NI 9475 Getting Started Guide | © National Instruments | 13 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 15 Figure 3. Increasing the Current to a Device Connected to the NI 9475 External Power Supply NI 9475 I/O Protection The NI 9475 provides overcurrent protection. Each channel has circuitry that protects it from current surges resulting from short circuits, as described in the following table.
  • Page 16 NI 9475 Getting Started Guide | © National Instruments | 15 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 17 If a short-circuit occurs, the current through DO can exceed the current rating for the power supply and the maximum continuous output current for the NI 9475. 16 | ni.com | NI 9475 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 18 If the power supply you are using with the NI 9475 cannot supply more than 13 A, the module may be damaged if a short-circuit condition occurs. Resetting Channels after an Overcurrent Condition After you have determined and fixed the cause of an overcurrent condition, reset the channel by turning it off.
  • Page 19 LabVIEW Help RELATED INFORMATION C Series Documentation Services & Resources ni.com/services ni.com/info cseriesdoc Located at ni.com/manuals Installs with the software 18 | ni.com | NI 9475 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 20 If your product supports calibration, you can obtain the calibration certificate for your product at ni.com/calibration. NI 9475 Getting Started Guide | © National Instruments | 19 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
  • Page 21 Refer to the NI Trademarks and Logo Guidelines at for information on ni.com/trademarks National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products/technology, refer to the appropriate location: Help»Patents in your software, file on your media, or the National Instruments Patent Notice at patents.txt...
