Parts Overview

1. CONTROL POD
2. Speaker
3. Coil Connector Socket
4. Battery Compartment
5. Battery Cover
6. HANDLE ASSEMBLY
7. Locating Hook
8. Control Pod Screw
9. Camlock
10. Handgrip
11. Armrest Adjustment Camlock
12. Upper Shaft
13. Armrest with Stand
14. MIDDLE SHAFT
15. Camlock
16. LOWER SHAFT
17. Rubber Washers (×2)
18. Coil Nut & Bolt
19. COIL
20. Skidplate
21. Yoke Bracket
22. Coil Cable
23. Coil Connector
1
2
4
3
5
7
6
9
8
15
17
20
21
3
10
12
11
14
16
19
22
23
13
18
