INSTALLATION
GUIDE
MANUAL
HVS-2000PSM
Power Supply Units for Power Redundancy
st
1
Edition

Advertisement

loading
Need help?

Need help?

Do you have a question about the HVS-2000PSM and is the answer not in the manual?

Questions and answers

Summary of Contents for FOR-A HVS-2000PSM

  • Page 1 INSTALLATION GUIDE MANUAL HVS-2000PSM Power Supply Units for Power Redundancy Edition...
  • Page 2: Upon Receipt

    Upon Receipt HVS-2000PSM units and their accessories are fully inspected and adjusted prior to shipment. Check your received items against the packing lists below. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately.
  • Page 3 1. Power Unit Installation Slots HVS-2000PSM is a redundant power unit for HVS-2000. Front panel HVS-2000 DIGITAL VIDEO SWITCHER POWER 1 (Preinstalled) ALARM POWER 2 (Option) ALARM POWER 3 ALARM Rear panel SER. NO. M /E A UX SDI OUTPUT...
  • Page 4 (new installation) and the procedure for replacing the HVS-2000 power supply. 2-1. How to Install a New Power Unit The following procedure shows how to install HVS-2000PSM unit (PS2) on the HVS-2000 for a redundant configuration. (1) Turn OFF the POWER 1 switch on the front panel and unplug the power cord from the rear panel.
  • Page 5 (5) Insert the HVS-2000PSM all the way to the back in PS2 slot. (6) Install the bracket and screws removed in (4) referring to the illustration below. Align the HVS-2000PSM and the screw hole of the bracket. Hook the protruding part of the bracket to the HVS-2000PSM.
  • Page 6 2-2. How to Replace a Power Unit The following procedure shows how to replace the power unit of the HVS-2000 to a new power unit set. (1) Turn all POWER switches on the front panel to OFF. HVS-2000 DIGITAL VIDEO SWITCHER POWER 1 ALARM POWER 2...
  • Page 7 (10) Secure the power cord with the supplied AC cord clamp. (See "AC Cord Clamp Installation" <p. 5>.) (11) Turn on all POWER switches on the front panel. (12) Open the [SETUP > STATUS > ALARM] menu in the GUI. If PS1 has been replaced, select POWER SUPPLY1 on the MU, and if PS2 has been replaced, select POWER SUPPLY2 on the MU, and confirm that SUPPLIED is displayed.
  • Page 8 Tel: +1 352-371-1505 Fax: +1 714-894-5399 FOR-A Latin America and the Caribbean Miami Office Tel: +1 657-600-5759 FOR-A Latin America and the Caribbean Sao Paulo Office Tel: +55 (0)11-99913-3751 FOR-A Europe S.r.l. Via Volturno, 37, 20861, Brugherio MB, Italy Tel: +39 (0)39-916-4811 FOR A UK Limited Trident Court, 1 Oakcroft Road Chessington, KT9 1BD, U.K.
