- Page 1 INSTALLATION GUIDE HVS-2000PSO Power Supply Units for Power Redundancy Edition...
-
Page 2: Upon Receipt
Upon Receipt HVS-2000PSO units and their accessories are fully inspected and adjusted prior to shipment. Check your received items against the packing lists below. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately. - Page 3 1. Power Unit Installation Slots The slots of power supply units are located on the rear side of the control panel. HVS-2240OU/OUA POWER 1 POWER 2 SER. NO. AC100-240 V 50/60Hz IN POWER MONIT OR OUT LAN2 LAN1 (SUB) (MAIN) HDMI CONTROL GPI IN/T ALLY OUT...
- Page 4 2. Power Unit Initial Installation / Replacement This chapter describes two installation procedures: initially installing to configure power redundancy and replacing the power supply unit using HVS-2240OUA as an example. The installation procedures for other control panels are the same. 2-1.
- Page 5 (7) Turn on the POWER 2 switch. (8) Check that the POWER2 lamp on the control pane lights green. (9) Open the [SETUP > STATUS > ALARM] page in the GUI menu and check that SUPPLIED is displayed under POWER SUPPLY2 of OU . The power unit initial installation is now complete.
