  • Page 1 OPERATION MANUAL USF-212S Universal System Frame USF-212PS Power Supply Unit Edition...

  • Page 2: Important Safety Warnings

    Precautions Important Safety Warnings [Power] Operate unit only at the specified supply voltage. Caution Disconnect the power cord via the power plug only. Do not pull on the cable portion. Do not place or drop heavy or sharp-edged objects on the power cord. A damaged cord can cause fire or electrical shock hazards.
  • Page 3 [Circuitry Access] Do not remove covers, panels, casing, or access the circuitry with power applied to the unit. Turn the power off and disconnect the power cord prior to removal. Internal servicing / adjustment of unit should only be performed by qualified personnel. Do not touch any parts / circuitry with a high heat factor.
  • Page 4  USF-212S ITEM REMARKS USF-212S AC Cable 1 set Includes AC Cord Retaining Clip CD-ROM Operation Manual (PDF) Set up Guide  USF-212PS Option ITEM REMARKS USF-212PS Redundant Power Supply Unit 1 set AC Cable Includes AC Cord Retaining Clip...

  • Page 5: Table Of Contents

    10-3. Network Tab ..........................28 10-4. SNMP Tab ..........................30 10-5. Utility Tab ..........................32 11. About SNMP .............................34 12. Specifications and Dimensions ......................36 12-1. Specifications ..........................36 12-1-1. USF-212S ........................36 12-1-2. USF-212PS ........................36 12-2. External Dimensions .......................37 12-2-1. USF-212S ........................37 12-2-2. USF-212PS ........................37...

  • Page 7: Prior To Starting

    The USF-212S is a low cost and space saving Universal System Frame that can be freely configured. Up to 12 modules can be installed into one USF frame. Dual, redundant power supplies can be configured by adding an optional USF-212PS power unit, improving operation safety.

  • Page 8: Installing Ac Cord Retaining Clip

    2. Installing AC Cord Retaining Clip Secure the AC cord with the supplied ladder strap/retaining clip assembly to prevent accidental disconnection from the USF-212S.  Installing the clip Wrap the retaining clip around the AC cord (with the anchor of the ladder strap toward the unit). Insert the anchor into the hole next to the AC IN socket.

  • Page 9: Usf-212S Module List

    Lower the environmental temperature to continue operation. FAN1 Cooling fans. Operation status can be monitored by Web GUI Status FAN2 Tab. Refer to Sec.10-1. “Status Tab.” FAN3 DC 1 and DC 2 become functional when a USF-212PS power supply option is installed.

  • Page 10: Opening The Front Panel

    4-2. Opening the Front Panel IMPORTANT The front panel may be difficult to open if the USF frame is placed on a desk, and may be damaged if it is forced to open. Perform the following steps after setting the frame in a rack Loosen the two thumbscrews on the front panel by turning them counterclockwise.

  • Page 11: Detaching The Front Panel

    4-3. Detaching the Front Panel Fully draw out the front panel. The front panel can be detached by gently pushing both rails inward. NOTE Handle the front panel carefully so as not to bend the rails. IMPORTANT After the front panel is installed, the ALARM LED on the front panel will light in the following order.

  • Page 12: Front Interior

    DC power supply shutting down if either power unit fails. The dedicated and optional USF-212PS power supply units are the same configuration, and can be exchanged. Refer to Sec. 7. "Installing or Removing a Redundant Power Supply Unit”...

  • Page 13: Slot Number

    Stand by power is activated in the USF-212S power supply unit when the AC cable is inserted. When the front switch of the USF-212PS Power Supply unit is turned off, the DC supply to USF-212S is disconnected. Redundant operation is available by installing an optional USF-212PS power supply unit.

  • Page 14: Rear Panel

    Supplies AC100 to 240V power using the provided power supply power supply 1 cable. AC Inlet for When an optional USF-212PS is installed, supplies AC100 to 240V power supply 2 power using the provided power supply cable. Ground terminal Grounds the power supply for safety.

  • Page 15: Fan

    4-8. Fan Fan unit prevents overheating from internal heat generation, pulling air through the front panel and out the rear and right side panels. Do not block the fan vents. (Rear Panel) (Front Panel) Air Flow Diagram 4-9. Internal SDI Bus The USF-212S frame provides 4-slot groupings internal SDI bus which allows SDI signals to be transferred bi-directionally.

  • Page 16: Alarm Connector

    4-10. ALARM Connector Matching connector 9-pin D-sub male *Using inch screws 9-pin D-sub female ALARM Connector Assignment Table (9-pin D-sub female) Signal Signal Details ALARM 1 ALARM 2 ALARM 3 ALARM 1 to 6 functions assigned through Web GUI setting page. Refer to Sec.

  • Page 17: Usf Module Installation

    5. USF Module Installation USF Modules can be installed into any free slot. If multiple free slots exist, do not install modules side-by-side but leave slots open to prevent overheating and facilitate signal connection from the rear panel. NOTE  USF Modules come as front and rear sets.

  • Page 18: Installing A Usf Front Module

    5-2. Installing a USF Front Module IMPORTANT Make sure to install the front module after installing the rear module. Slot 1 is the top slot in the right block of the front panel. Refer to Sec. 4-5. "Slot Number” Set the front module on the guide rail and carefully insert the front module slowly. PCB Guide Rail Locations PCB Guide Rail PCB Guide Rail...

  • Page 19: Replacing A Usf Module

    6. Replacing a USF Module Follow the procedure described below to remove and replace a defective USF Module. Since no electrical components are mounted on most USF rear modules, it is possible to recover proper operation by replacing front modules. NOTE When both front and rear module are to be replaced, make sure to replace the rear module after pulling out the front module.

  • Page 20: Installing Or Removing A Power Supply Unit

    To avoid electric shock, make sure to ground the grounding terminal before operation or pull out the AC cable from the outlet. A USF-212PS redundant power supply unit can be installed while the power is on, although the (main) USF-212S power supply should normally be turned off when doing so. To install or remove a power supply unit while the power is on, open the front panel.

  • Page 21: Removing A Power Supply Unit

    7-2. Removing a Power Supply Unit The procedure for removing a USF-212PS from the PS1 SLOT is explained as an example. Open the front panel. Refer to Sec. 4-2 "Opening the Front Panel.” Shut down the Power Supply 1. Unplug the AC cable of Power Supply 1 from the back side. Refer to Sec. 2 "Installing the AC Cord Retaining Clip”...

  • Page 22: Control Module

    8. Control Module Make sure to shut down the power when replacing the control module. 8-1. Internal Control Module Settings Remove the module by loosening the screw on front and pulling the module out using the grab handle. Handle Micro SD connector Name Descriptions Switch S2...

  • Page 23: Control Via Web Gui

    9. Control via Web GUI USF-212S operation can be monitored by a web browser or SNMP Manager via a PC-network connection. Power supply, fan, and temperature states can be displayed by opening the USF-212S Web GUI from a web browser. Control and monitoring of the modules (*1) installed in USF-212S can be done via Web GUI.

  • Page 24: Lan A Port

    9-1-2. LAN A Port LAN A port functions via the built-in USF-212S router. Therefore, LAN A can display respective modules states via Web GUI and SNMP monitor with one IP address assigned for respective modules IP addresses. When building a large scale system with multiple USF-212S units, you can reduce the number of IP addresses.

  • Page 25: Usf-212S Web Gui

    10. USF-212S Web GUI Module status web browser display settings are different between LAN1, 2 and LAN A.  Displaying the web browser from LAN 1 and LAN 2 Open the web browser on the PC connected to LAN 1 and LAN 2, then input the address http://192.168.0.10/ (factory default setting).
  • Page 26  Status Model names of the modules installed in slots 1 to 12 of USF-212S are displayed. PS1 and PS2 indicate the respective power supply mounting and operational states. A red flashing LED indicates abnormal power output, inoperative fan, or a high temperature state being detected.

  • Page 27: Alarm Tab

    10-2. Alarm Tab Clicking an Alarm tab opens a window on the web browser as shown below. Clicking Refresh allows you to update the window contents. Item Function(Default) Description Alarm 1 Alarm 2 Assigns a function for each alarm terminal. Alarm 3 A function is selected from the list below.

  • Page 28: Network Tab

    10-3. Network Tab Clicking the Network tab opens a window as shown below. Set values are indicated. Input values to change settings. The changes are applied by clicking Apply. IMPORTANT Setting changes performed in the Network Tab require the USF-212S to be restarted after they are entered by clicking Apply.
  • Page 29 Example 3: To Control Slot 1 Module by Remote Control Connection. When the Control Base Port setting is 57000, input 172.16.0.10 for the IP address. Input 57001 for the port number. Similarly, input 57002 for the port number of Slot 2. Refer to the FA-10DCCRU operation manual for further details on setting.

  • Page 30: Snmp Tab

    10-4. SNMP Tab Clicking SNMP Tab opens the following page on the web browser. Clicking also opens the same page. IMPORTANT In order to confirm changes in SNMP Tab, click Apply to restart the USF-212S.  SNMP Settings This page allows you to apply various settings to monitor USF-212S by SNMP manager. ...
  • Page 31  Trap Settings Click This window allows you to set various trap transmission from USF-212S to SNMP Manager. Clicking Refresh updates window to the latest.  Unit Trap Settings Item Default Settings Description Enable: If the community names set on Authentication Read Only1, 2/ Read/Write1, 2 are different Disable...

  • Page 32: Utility Tab

    10-5. Utility Tab Clicking the Utility tab opens the window as shown below on the web browser.  System Restart Execute System Restart when network settings or SNMP settings are changed. The following confirmation window will appear when Restart is clicked. Other tab windows cannot be accessed until this window is closed Click OK to execute restart.
  • Page 33 IMPORTANT Save setting parameters to a UTF-8 encoded CSV(Comma-Separated Value) file without BOM (Byte Order Mark).  Slot Name Any name up to 15 characters can be given to Slots 1 to 12. (Half-width and Full-width characters) The set name is displayed in the pane under Slot Name. Slot names are set.

  • Page 34: About Snmp

    11. About SNMP The USF-212S can be remotely monitored using an SNMP monitoring system that supports SNMPv2C. Since functions between the USF-212 and USF-212S are different, refer to the SNMP function descriptions of the unit you are using. MIB (Management Information Base) files required for SNMP monitoring system can be downloaded from Web GUI.
  • Page 35 Power Unit 2 DC Obtains the Power Unit 2 DC status. Output normal: Indicates Power Unit 2 DC output is normal. abnormal: Indicates Power Unit 2 DC output is abnormal. notInstalled: Indicates Power Unit 2 is not installed when turned on. Power Unit 2 FAN Obtains the Power Unit 2 FAN status.

  • Page 36: Specifications And Dimensions

    Consumables (Recommended replacement timespans at room temperature for 24 hour operation) Power unit: Within 5 years Cooling fan: Within 6 years 12-1-2. USF-212PS Power Supply 100 to 240 V AC 50/60Hz Power Consumption 670VA (at 100 to 120V AC at maximum output current)

  • Page 37: External Dimensions

    12-2. External Dimensions 12-2-1. USF-212S (All dimensions in mm.) USF-212 UNIVERSAL S YSTEM FRAME PO W ER ALA RM DC 1 DC 2 LO CK LO CK TE MP 12-2-2. USF-212PS (All dimensions in mm.) 41.3...
  • Page 39 Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
