Summary of Contents for shokz OPENMEET
- Page 1 User Guide...
-
Page 2: Table Of Contents
CONTENTS Contents HOW IT WORKS Shokz App & Shokz Connect Headset Controls ON/OFF Pairing to Mobile Device Pairing to PC How to Wear Music and Calls Wireless Adapter LED indicator Check Battery Status EXTRA FEATURES EQ Modes Switching EQ Modes... - Page 3 CONTENTS WHAT’S IN THE BOX REGULATORY AND LEGAL INFORMATION...
-
Page 4: How It Works
How It Works... -
Page 5: Shokz App & Shokz Connect
Shokz App & Shokz Connect Shokz Connect Download the Shokz App for your phone and Shokz Connect for your computer to get additional features, the latest updates, and to get technical support. *Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. -
Page 6: Headset Controls
HEADSET CONTROLS Headset Controls Multifunction Button LED indicator Answer/End Call Mute/Unmute Microphone USB-C Charging Port... -
Page 7: On/Off
ON/OFF ON/OFF Power On: Press and hold the Multifunction Button for 2 seconds until the LED indicator flashes blue. Power Off: Press and hold the Multifunction Button for 3 seconds until the LED indicator flashes red. -
Page 8: Pairing To Mobile Device
Operate controls with your headset powered off. 1. Start with your headset turned off. 2. Press and hold the Multifuction Button until the LED indicator flashes red and blue alternately. 3. Select "OpenMeet by Shokz" on your device's Bluetooth settings. -
Page 9: Pairing To Pc
2. Plug the included wireless adapter into a USB port on your PC. 3. Connection is established when the LED indicator on the USB adapter is solid cyan. * Only the UC version is equipped with a wireless adapter. For non-UC version, visit www.shokz.com to purchase wireless adapter if necessary. - Page 10 SELECT AUDIO DEVICE : Loop120 by Shokz Connected Configure *To play music or take calls on the headset, please ensure the “Loop120 by Shokz” is both identified as the default input and output devices in your operating system’s audio settings.
-
Page 11: How To Wear
HOW TO WEAR How to Wear If necessary, replace the pressure relief cushions with a different size for optimal comfort and fit. - Page 12 HOW TO WEAR How to Wear 1. Put the headset on your head with the earpieces placed in front of your ears. 2. Adjust the size of the headpiece, so the headset fits comfortably. 3. Adjust the microphone to a position close to your mouth. 4.
-
Page 13: Music And Calls
MUSIC AND CALLS Music and Calls Adjust volume When playing music, slide up to increase the volume and slide down to decrease the volume. *A “beep” will sound when the volume is at its max. *Listening with your headset at a high volume may affect your hearing and the audio will be distorted. - Page 14 MUSIC AND CALLS Music and Calls Mute microphone Click once when on a call Unmute microphone Click once when on a call Activate voice assistant Click once when NOT on a call Switch EQ Modes Press and hold for 3 seconds while music is playing...
-
Page 15: Wireless Adapter
WIRELESS ADAPTER Wireless Adapter Loop120 Loop120 USB-C USB-A Install Shokz Connect on your computer to access additional information related to pairing, firmware updates, feature settings, and resets for the Shokz Bluetooth adapter. -
Page 16: Led Indicator
LED INDICATOR LED indicator ① Pairing mode Charging Battery full Low battery Incoming call Busylight ② Pairing Music streaming Reconnect Incoming call Connected In-call Standby Mode Microphone on mute... -
Page 17: Check Battery Status
CHECK BATTERY STATUS Check Battery Status How to check battery status: Click the multifunction button or answer/end call button while audio is not playing. -
Page 18: Extra Features
Extra Features... -
Page 19: Eq Modes
EQ MODES EQ Modes Standard Mode Balanced frequency for listening to music. Vocal Booster Mode Enhanced intermediate frequencies for audiobooks, podcasts, etc. -
Page 20: Switching Eq Modes
SWITCHING EQ MODES Switching EQ Modes How to switch EQ modes: Press and hold mute/unmute button while music is playing. -
Page 21: Restore Factory Settings
RESTORE FACTORY SETTINGS Restore Factory Settings Multifunction Button Mute/Unmute Microphone Answer/End Call 1. Start with your headset turned off. 2. Press and hold the Multifuction Button until the LED indicator flashes red and blue alternately. 3. Press and hold the Answer/End Call Button and Mute/Unmute Button for 5 seconds until you hear a beep. -
Page 22: Care And Maintenance
Care and Maintenance... -
Page 23: Charging Tips
CHARGING TIPS Charging Tips When the headset battery is low there will be a prompt and the red light will flash intermittently. Use the corresponding charging cable to charge. The LED indicator will turn orange while charging. Once fully charged, the LED indicator will turn from orange to green. -
Page 24: Warranty
WARRANTY Warranty Your headset is covered by a warranty. Visit our website at https://shokz.com/pages/warranty-landing for details of the limited warranty. *Failure to register will not affect your limited warranty rights. -
Page 25: Troubleshooting
TROUBLESHOOTING Troubleshooting If you experience any issues or problems, please visit https://shokz.com/pages/faq for more support... -
Page 26: What's In The Box
Legal Statement*2 (M*2 + L*2) If any part of your product is damaged or missing, do not use it. Contact an authorized Shokz dealer or Shokz customer service. *Please note that product packaging may vary depending on the sales region. - Page 27 Note Design and specification are subject to change without notice. For the most up-to-date product information, please visit https://shokz.com. Warning To avoid the risk of explosion, fire, or leakage from toxic chemicals, please do not disassemble the product or replace, warp, or damage the battery.
- Page 28 REGULATORY AND LEGAL INFORMATION immediately and consult a physician. Only charge with the magnetic charging cable approved by the manufacturer. Other charging cables may not meet applicable safety standards, and charging with such cables could pose a risk of injury to the users or damage to the device. Use this product only with an agency-approved power supply that meets local regulatory requirements (e.g., UL, CSA, VDE, CCC).
