Summary of Contents for shokz OpenComm2 UC

  • Page 1 User Guide...

  • Page 2: Table Of Contents

    CONTENTS Contents HOW IT WORKS Headset Controls ON/OFF Pairing to Mobile Device Pairing to PC How to Wear Music and Calls Wireless Adapter Check Battery Status EXTRA FEATURES EQ Modes Restore Factory Settings Changing Languages CARE AND MAINTENANCE Charging Tips Moisture Detection Alert Storage and Maintenance Warranty...
  • Page 3 CONTENTS WHAT’S IN THE BOX REGULATORY AND LEGAL INFORMATION...

  • Page 4: How It Works

    How It Works...

  • Page 5: Headset Controls

    HEADSET CONTROLS Headset Controls Power/Volume + Button LED Indicator Volume - Button Magnetic Charging Port Multifunction Button Mute/Umute Microphone Microphone 1 Microphone 2...

  • Page 6: On/Off

    Turn on the headset : Press and hold the Power/Volume + Button until the LED Indicator flashes blue. *Audrey will say, “Welcome to Shokz.” Turn off the headset : Press and hold the Power/Volume + Button until the LED Indicator flashes red.

  • Page 7: Pairing To Mobile Device

    1. Start with your headset turned off. 2. Press and hold the Volume + Button until the LED Indicator flashes red and blue alternately. Settings BLUETOOTH OpenComm2 UC by Shokz 3. Select "OpenComm2 UC by Shokz" on your device's Bluetooth settings. Audrey will say, "Connected".

  • Page 8: Pairing To Pc

    PAIRING TO PC Pairing to PC Loop110 Loop110 USB-C USB-A Multifunction Button Operate controls with your headset powered off. 1. Start with your headset turned on. 2. Plug the included USB adapter into a USB port on your PC. 3. Connection is established when Audrey says "Connected" or beeps, and the LED Indicator on the USB adapter is solid blue.
  • Page 9 PAIRING TO PC SELECT THE SOUND DEVICE : Shokz Loop110 Connected Configure *To play music or take calls on the headset, please ensure the “Shokz Loop110” is both identified as the default input and output devices in your operating system’s audio settings.

  • Page 10: How To Wear

    HOW TO WEAR How to Wear Slide the headset over your head, bring it to the back of your neck and position the ear-hooks on your ears. *Position the noise-canceling microphone close to your mouth. *Wearing your headset the wrong way could cause discomfort. Be sure you have the transducers resting in front of your ears.

  • Page 11: Music And Calls

    MUSIC AND CALLS Music and Calls While your audio is playing, adjust the headset volume by pressing either the “Volume +” or Adjust volume “Volume -” buttons. *A “beep” will sound when the volume is at its max. *Listening with your headset at a high volume may affect your hearing and the audio will be distorted.
  • Page 12 MUSIC AND CALLS Answer an incoming call and Click once when receiving a second call place the current on hold Switching between two calls Click once Ending a call and switching Press and hold for 2 seconds to a call on hold Press and hold for 2 seconds when Activate voice assistant the device is on standby...

  • Page 13: Wireless Adapter

    WIRELESS ADAPTER Wireless Adapter Loop110 Loop110 USB-C USB-A Multifunction Button Pair to a new headset Reconnect to the last connected headset Press and hold for 2 seconds Click once LED: Flashes red and blue rapidly LED: Flashes blue every second...
  • Page 14 WIRELESS ADAPTER LED on the adapter Pairing Mode: Flashes red and blue alternatively Reconnect Mode: Flashes blue every second Standby Mode: Flashes blue every five seconds and stop flashing in one minute Bluetooth Connection: Solid blue Streaming Music/Media: Solid blue On a call: Solid green Mute during a call: Solid red...

  • Page 15: Check Battery Status

    CHECK BATTERY STATUS Check Battery Status Operate controls while audio is not playing Power/Volume + Button Volume - Button How to check battery status : Click the “Volume +” or “Volume -” button while music is paused, Audrey will tell you what the battery status is: * "Battery high/Battery medium/Battery low/Charge me"...

  • Page 16: Extra Features

    Extra Features...

  • Page 17: Eq Modes

    EQ MODES EQ Modes Standard Mode Balanced frequency for listening to music Vocal Booster Mode Enhanced intermediate frequencies for audiobooks, podcasts, etc.

  • Page 18: Restore Factory Settings

    RESTORE FACTORY SETTINGS Restore Factory Settings Operate controls with headset powered off Power/Volume + Button LED Indicator Audrey will say, “pairing.” 1. Start with your headset powered off. 2. Press and hold the “Volume +” button until Audrey says “Pairing”. The LED indicator will flash red and blue.
  • Page 19 RESTORE FACTORY SETTINGS Power/Volume + Button Volume - Button Multifunction Button 3. Press and hold the multifunction button, Volume - button, and Volume + button until you hear two beeps and feel the vibration. 4. Turn your headset off. The headset is now reset and can be re-paired to your device.

  • Page 20: Changing Languages

    CHANGING LANGUAGES Changing Languages Your headset has four built-in languages: Chinese, English, Japanese and Korean. Follow the instruction when your headset is powered off. Power/Volume + Button LED Indicator Audrey will say, “pairing.” 1. Start with your headset powered off. 2.
  • Page 21 CHANGING LANGUAGES Multifunction Button 3. Double-press the multifunction button. Languages have been switched when you hear the corresponding language.

  • Page 22: Care And Maintenance

    Care and Maintenance...

  • Page 23: Charging Tips

    CHARGING TIPS Charging Tips The headset will automatically shut down when charging Magnetic Charging Cable Charging Charging Completed When the headset is at low battery, there will be a “charge me” prompt and the red light will flash intermittently. Use the corresponding magnetic charging cable for charging.

  • Page 24: Moisture Detection Alert

    MOISTURE DETECTION ALERT Moisture Detection Alert How it Works: These headset can detect liquid such as water, sweat, or rain. If the headset is plugged into the charger while wet, the LED indicator will flash red and blue. The headset will then emit a beep.

  • Page 25: Storage And Maintenance

    STORAGE AND MAINTENANCE Storage and Maintenance OpenComm2 UC · Store the headset in a cool, dry place. The working temperature should be 0~45°C(32~113°F). Working in a cold/hot environment, a highly humid area, or an extremely low air pressure may reduce the battery life.
  • Page 26 · Keep the product away from heat sources, direct sunlight, combustible gas, or liquids. · Do not disassemble the product. · Unplug, discontinue use, and contact Shokz if the product overheats or has a damaged outer casing or plug. Note Design and specification are subject to change without notice.

  • Page 27: Warranty

    WARRANTY Warranty Your headset is covered by a warranty. Visit our website at https://shokz.com/pages/warranty-landing for details of the limited warranty. *Failure to register will not affect your limited warranty rights.

  • Page 28: Troubleshooting

    TROUBLESHOOTING Troubleshooting If you experience any issues or problems, please visit https://shokz.com/pages/faq for more support...
  • Page 29 User Guide Headset/USB-A Adapter Legal Statement If any part of your product is damaged or missing, do not use it. Contact authorized Shokz dealer or Shokz customer service. *Please note that the packaging envelope may vary depending on the sales region.
  • Page 30 REGULATORY AND LEGAL INFORMATION Regulatory and Legal Information OpenComm2 UC FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules.
  • Page 31 Responsible party (contact for FCC matters only): AfterShokz LLC. 3200 Gracie Kiltz Lane, Suite 300 Austin, TX 78758, United States www.shokz.com Industry Canada This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s): Operation is subject to the fol-...
  • Page 32 CE Declaration of Conformity Shokz Holding Limited hereby declares that this prod- uct is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU and all other applicable EU Directive requirements.
  • Page 33 UK Declaration of Conformity Shokz Holding Limited hereby declares that this product is in compliance with the essential requirements and all other applicable United Kingdom’s regulations. The complete declaration of conformity can be found at: https://shokz.com/pages/policies. Shokz’s authorised representative in the UK is Pinpoint Consumer Electron- ics Ltd., Unit 35, Meridian House, Road One, Winsford In-...
  • Page 34 REGULATORY AND LEGAL INFORMATION Shokz Loop110 USB-A/USB-C Wireless Adapter FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following...
  • Page 35 CE Declaration of Conformity Shokz Holding Limited hereby declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU and all other applicable EU Directive requirements.
  • Page 36 REGULATORY AND LEGAL INFORMATION UK Declaration of Conformity Shokz Holding Limited hereby declares that this product is in compliance with the essential requirements and all other applicable United Kingdom’s regulations. The complete declaration of conformity can be found at: https://shokz.com/pages/policies.
