Summary of Contents for shokz OPENCOMM C102

  • Page 1 OPENCOMM C102 User Guide...

  • Page 2: Table Of Contents

    CONTENTS Contents HOW IT WORKS Headset Controls ON/OFF Pairing NFC Pairing How to Wear Volume Mute the Microphone Multifunction Button Check Battery Status EXTRA FEATURES EQ Modes Switching EQ modes Multipoint Pairing Turn Multipoint Pairing Off Restore Factory Settings Changing languages CARE AND MAINTENANCE Charging Tips Moisture Detection Alert...
  • Page 3 CONTENTS Warranty TROUBLESHOOTING WHAT’S IN THE BOX REGULATORY AND LEGAL INFORMATION...

  • Page 4: How It Works

    How It Works...

  • Page 5: Headset Controls

    HEADSET CONTROLS Headset Controls Power/Volume + Button LED Indicator Multifunction Button Volume - Button Magnetic Charging Port Microphone 1 Microphone 2 NFC Function...

  • Page 6: On/Off

    Turn on the headset： Press and hold the Power/Volume + Button until the LED Indicator flashes blue. *Audrey will say： “ Welcome to Shokz” Turn off the headset： Press and hold the Power/Volume + Button until the LED Indicator flashes red.

  • Page 7: Pairing

    1. Start with OpenComm turned off. 2. Press and hold the Volume + Button until the LED Indicator flashes red and blue alternately. Settings BLUETOOTH Connected OpenComm by Shokz 3.Open your device's Bluetooth settings and select "OpenComm by Shokz." Audrey will say "connected."...

  • Page 8: Nfc Pairing

    NFC PAIRING NFC Pairing Operate controls with headset powered off. Power/Volume + Button LED Indicator 1.Power on your headset (press and hold Power/Volume+ until LED Indicator flashes blue)
  • Page 9 NFC PAIRING Settings Connected OpenComm by Shokz 2. Unlock your phone and turn on NFC pairing (Refer to your phone's user guide if needed). 3. Position the headset's NFC logo near the NFC detection area of your phone until the device shows pairing is completed. The headset's LED Indicator will flash blue once when pairing is...

  • Page 10: How To Wear

    HOW TO WEAR How to Wear Pick up the headset, bring them behind the back of the base of your neck, position the earhooks on your ears. *Position the noise-canceling microphone close to your mouth. *Wearing your headset the wrong way could cause discomfort.

  • Page 11: Volume

    VOLUME Volume Operate volume controls while audio is playing. Power/Volume + Button Volume - Button How to change volume: While your audio is playing, adjust headset volume by pushing either the Volume + or Volume ‒ buttons. *A “beep” will sound when the volume is at its max. *Listening with headset at high volume may affect your hearing and the audio will be distorted.

  • Page 12: Mute The Microphone

    MUTE THE MICROPHONE Mute the Microphone During a call Power/Volume + Button Volume - Button To Turn Mute On Press and hold the Volume + and Volume - buttons while on a call until Audrey says "Mute on". To Turn Mute Off Press and hold the Volume + and Volume - buttons while the microphone is muted until Audrey says "Mute off".
  • Page 13 MULTIFUNCTION BUTTON Multifunction Button Multifunction Button Play/pause music Answer call Next song End call Double-click while music is playing Previous song Triple-click while music is playing...

  • Page 14: Multifunction Button

    MULTIFUNCTION BUTTON Multifunction Button Play music Click once Pause music Click once Next song Double-click while music is playing Previous song Triple-click while music is playing Switch language Double-click while pairing Answer call Click once End call Click once during a call Answer call waiting and Press and hold for 2 seconds end current call...

  • Page 15: Check Battery Status

    CHECK BATTERY STATUS Check Battery Status Operate controls while audio is not playing Power/Volume + Button Volume - Button How to check battery status： Click the Volume + or Volume - button while music is paused， Audrey will tell you the battery status: * "Battery high/Battery medium/Battery low/Charge me"...

  • Page 16: Extra Features

    Extra Features...

  • Page 17: Eq Modes

    EQ MODES EQ Modes Standard Mode： Standard listening mode with your ears open. Earplug Mode： Use earplugs with headset in noisy environments where it is safe to block out ambient noise, such as on a train or in a factory plant.

  • Page 18: Switching Eq Modes

    SWITCHING EQ MODES Switching EQ Modes Operate controls while music is playing Power/Volume + Button Volume - Button How to switch EQ mode： Press and hold both buttons （Power/Volume + Button and Volume - Button） while music is playing until you hear a beep. *Audrey will say：...

  • Page 19: Multipoint Pairing

    MULTIPOINT PAIRING Multipoint Pairing Pair Two Devices Switch between two devices seamlessly with multipoint pairing...
  • Page 20 MULTIPOINT PAIRING Multipoint Pairing Operate controls with headset powered off Power/Volume + Button LED Indicator Audrey will say “pairing” 1. Start with your headset powered off. 2. Press and hold Volume + until Audrey will say “pairing” and the LED indicator flashes red and blue alternately.
  • Page 21 MULTIPOINT PAIRING Power/Volume + Button Multifunction Button Audrey will say "multipoint enabled." 3.Press and hold the multifunction button and Volume + button until Audrey says "multipoint enabled."...
  • Page 22 MULTIPOINT PAIRING Settings BLUETOOTH Connected OpenComm by Shokz First Device Audrey will say "connected". 4.Open first device's Bluetooth® menu and select "OpenComm by Shokz."Audrey will say "connected". 5.Turn your headset off.
  • Page 23 Audrey will say "connected". 6.Re-enter pairing mode by pressing and holding Volume + until Audrey says “pairing” and the LED indicator flashes red and blue alternately. 7.Open second device's Bluetooth® menu and select "OpenComm by Shokz."Audrey will say "connected." 8.Turn your headset off.
  • Page 24 Connected OpenComm by Shokz connected Bluetooth： turn on First Device Second Device You will hear a beep, then Audrey will say “Welcome to Shokz, connected. Second device connected.” 9.Turn your headset on. Your headset is now connected to both devices.

  • Page 25: Turn Multipoint Pairing Off

    TURN MULTIPOINT PAIRING OFF Turn Multipoint Pairing Off Operate controls with headset powered off. Power/Volume + Button LED Indicator Audrey will say “pairing” 1. Start with your headset powered off. 2. Press and hold Volume + until Audrey will say “pairing” and the LED indicator flashes red and blue alternately.
  • Page 26 TURN MULTIPOINT PAIRING OFF Volume - Button Multifunction Button Audrey will say "multipoint disabled." 3. Press and hold the multifunction button and Volume - button until Audrey will say "multipoint disabled."...

  • Page 27: Restore Factory Settings

    RESTORE FACTORY SETTINGS Restore Factory Settings Operate controls with headset powered off. Power/Volume + Button LED Indicator Audrey will say “pairing” 1. Start with your headset powered off. 2. Press and hold Volume + until Audrey will say “pairing” and the LED indicator flashes red and blue alternately.
  • Page 28 RESTORE FACTORY SETTINGS Power/Volume + Button Volume - Button Multifunction Button 3.Press and hold the multifunction button, Volume ‒ button and Volume + button until hear two beeps and feel the vibration. 4.Turn your headset off. OpenComm is now reset and can be re-paired to your device.

  • Page 29: Changing Languages

    CHANGING LANGUAGES Changing Languages Your headphones have four built-in languages: Chinese, English, Japanese and Korean. Follow the instruction when headset powered off Power/Volume + Button LED Indicator Audrey will say “pairing” 1. Start with your headset powered off. 2. Press and hold Volume + until Audrey will say “pairing” and the LED indicator flashes red and blue alternately.
  • Page 30 CHANGE THE LANGUAGE Multifunction Button 3. Double-press the multifunction button. Languages have been switched when you hear the corresponding language.

  • Page 31: Care And Maintenance

    Care and Maintenance...

  • Page 32: Charging Tips

    CHARGING TIPS Charging Tips The headset will automatically shut down when charging Magnetic Charging Cable Charging Charging Completed When the headset is at low battery, there will be a “charge me” prompt and the red light will flash intermittently. Use the corresponding magnetic charging cable for charging.

  • Page 33: Moisture Detection Alert

    MOISTURE DETECTION ALERT Moisture Detection Alert How it Works: These headset can detect liquid such as water, sweat, or rain. If the headset this plugged into the charger while wet, the LED indicator will flash red and blue. The headset will then emit a beep.

  • Page 34: Storage And Maintenance

    Note Design and specification are subject to change without notice. For the most up-to-date product information, please visit www.shokz.com. Warning To avoid the risk of explosion, fire, or leakage from toxic chemicals, please do not disassemble the product or replace, deform, or...
  • Page 35 WARRANTY Warranty Your headset are covered by a warranty. Visit our website at https://uk.shokz.com/pages/warranty-claim for details of the limited warranty. *Failure to register will not affect your limited warranty rights.
  • Page 36 TROUBLESHOOTING Troubleshooting If you have any trouble or problems,please visit https://uk.shokz.com/pages/support-new for more support!
  • Page 37 Charging Cable User Guide Legal Statement If any part of your product is damaged or missing, do not use it. Contact authorized Shokz dealer or Shokz customer service. *Please note that the packaging envelope may vary depending on the sales region.
  • Page 38 REGULATORY AND LEGAL INFORMATION Regulatory and Legal Information FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including...
  • Page 39 CE Declaration of Conformity Shokz Holding Limited hereby declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU and all other applicable EU Directive requirements.
  • Page 40 REGULATORY AND LEGAL INFORMATION as household waste, and should be delivered to an appropriate collection facility for recycling. Proper disposal and recycling helps protect natural resources, human health and the environment. For more information on disposal and recycling of this product, contact your local municipality, disposal service, or the shop where you bought this product.
