H&S PS6160 Operator's Manual

Manure spreaders
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATOR'S
MANUAL
PS6160
MANURE
SPREADERS
WARNING
READ AND UNDERSTAND THIS MANUAL BEFORE
OPERATING THIS EQUIPMENT. UNSAFE OPERATION
OR MAINTENANCE OF THIS EQUIPMENT CAN
RESULT IN SERIOUS INJURY OR DEATH.
Part #99579
Rev. #03
HSMFG101424
Starting Serial #421PS60001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS6160 and is the answer not in the manual?

Questions and answers

Related Manuals for H&S PS6160

Summary of Contents for H&S PS6160

  • Page 1 OPERATOR’S MANUAL PS6160 MANURE SPREADERS Part #99579 Rev. #03 HSMFG101424 Starting Serial #421PS60001 WARNING READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THIS EQUIPMENT. UNSAFE OPERATION OR MAINTENANCE OF THIS EQUIPMENT CAN RESULT IN SERIOUS INJURY OR DEATH.

  • Page 2: Table Of Contents

    CONTENTS Warranty ..............1-2 Manufacturer’s Statement .

  • Page 3: Warranty

    WARRANTY H&S Manufacturing Co., Inc. (“H&S”) warrants this product to be free from defect in material and workman- ship. Except as noted below, this warranty term is twelve (12) months on parts and labor from the date of delivery of the product to the original purchaser by an authorized H&S dealer. Under this warranty, H&S will repair or replace, at its option, any covered part which is found to be defective in material or workmanship during the applicable warranty term.

  • Page 4: Manufacturer's Statement

    WARRANTY For these warranty terms to be in effect the selling authorized H&S dealer and/or the customer must submit the warranty registration to H&S. THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE OF THIS WARRANTY. H&S and the companies affiliated with it make no warranties, representations, or promises, express or implied, as to the performance or freedom from defect of its products other than those set forth above and NO IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS OR FITNESS FOR A PARTICULAR PURPOSE IS MADE.

  • Page 5: Warranty Registration Form

    WARRANTY REGISTRATION • Date of Purchase: __________________________ • Purchaser Name: ________________________________________________ • Street Address: _________________________________________________ • City: __________________________________________________________ • State: __________________________________ Zip: ____________________ • Phone Number: _________________________________________________ • E-mail Address: _________________________________________________ • Product: _______________________________________________________ • Model Number: _________________________________________________ • Serial Number: __________________________________________________ •...
  • Page 6 Intentionally Left Blank...

  • Page 7: Dealer Pre-Delivery Checklist

    H&S DEALER PRE-DELIVERY CHECKLIST AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS After the Manure Spreader has been completely set up, check to be certain it is in correct operating order before delivering to the customer. The following is a list of points to inspect. Check off each item as you have made the proper adjustments and found the item operating satisfactorily.
  • Page 8 Intentionally Left Blank...

  • Page 9: Dealer Delivery Checklist

    DEALER DELIVERY CHECKLIST AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS This checklist that follows is an important reminder of valuable information that should be passed on to the customer at the time this Manure Spreader is delivered. Check off each item as you explain it to the customer. This delivery checklist, when properly filled out and signed, assures the customer that the pre-delivery service was satisfactorily performed.

  • Page 10: Safety Information

    SAFETY INFORMATION TRACTOR: This operator’s manual uses the term “Tractor” when identifying the power source. W A R N I N G TO PREVENT SERIOUS INJURY OR DEATH BEFORE YOU ATTEMPT TO OPERATE THIS EQUIPMENT, READ AND STUDY THE FOLLOWING INFORMATION.
  • Page 11 SAFETY INFORMATION YOUR SAFETY ALERT! IS INVOLVED. THIS SYMBOL IS USED THROUGHOUT THIS BOOK WHENEVER YOUR PERSONAL SAFETY IS INVOLVED. TAKE TIME TO BE CAREFUL. REMEMBER: THE CAREFUL OPERATOR IS THE BEST OPERATOR. MOST ACCIDENTS ARE CAUSED BY HUMAN ERROR. CERTAIN PRECAUTIONS MUST BE OBSERVED TO PREVENT THE POSSIBILITY OF INJURY OR DAMAGE.
  • Page 12 SAFETY INFORMATION RECOGNIZE SAFETY INFORMATION This is the safety alert symbol. When you see this symbol on your machine or in this manual, be alert to the potential for personal injury. Follow recommended precautions and safe operating practices. UNDERSTAND SIGNAL WORDS A signal word - DANGER, WARNING, or CAUTION - is used with the safety alert symbol.

  • Page 13: Limits Of The Machine

    This manual contains information that will contribute to the safe, reliable and most productive operation. The PS6160 power spreaders are designed as tow behind unit. If you notice degradation of performance, contact your H&S dealer for assistance.

  • Page 14: Safe Practices

    SAFE PRACTICES Safe practices developed from experience in the use of spreaders are described in this manual. Safe installation, operation, and servicing practices have evolved through research, development, and field experience. Accidents occur when equipment is improperly used or maintained. The reason for the safe practices may not always be given. Some are based on common sense;...

  • Page 15: Additional Safety Information

    ADDITIONAL SAFETY INFORMATION -13-...
  • Page 16 ADDITIONAL SAFETY INFORMATION -14-...
  • Page 17 ADDITIONAL SAFETY INFORMATION -15-...
  • Page 18 ADDITIONAL SAFETY INFORMATION -16-...
  • Page 19 ADDITIONAL SAFETY INFORMATION -17-...
  • Page 20 ADDITIONAL SAFETY INFORMATION -18-...
  • Page 21 ADDITIONAL SAFETY INFORMATION -19-...
  • Page 22 ADDITIONAL SAFETY INFORMATION -20-...
  • Page 23 ADDITIONAL SAFETY INFORMATION -21-...
  • Page 24 ADDITIONAL SAFETY INFORMATION -22-...

  • Page 25: Decal Location

    DECAL LOCATION Your H&S Manure Spreader was manufactured with operator safety in mind. Located on the manure spreader are various decals to aid in operation, and warn of danger or caution areas. Pay close attention to all decals on your Manure Spreader. DO NOT REMOVE ANY OF THESE DECALS.

  • Page 26: Safety Decals

    SAFETY DECALS 9194A 82602 9194A 82602 -24-...
  • Page 27 SAFETY DECALS 11599 093366 12794 1494B 51010 -25-...
  • Page 28 SAFETY DECALS 1494K 9194A 1494B 51010 -26-...
  • Page 29 SAFETY DECALS 9194A 1494K 72203A 1906F 98305 -27-...
  • Page 30 SAFETY DECALS 86060 9194B 1494J 96654 1906F -28-...
  • Page 31 SAFETY DECALS 1906F DCAMB -29-...
  • Page 32 SAFETY DECALS DCAMB 123002 11599 1906F -30-...
  • Page 33 SAFETY DECALS 123002 11599 1906F 86060 111593A 1494J -31-...
  • Page 34 SAFETY DECALS 86060 111593A 1494J JD5922 12794 DCRED -32-...
  • Page 35 SAFETY DECALS DCAMB -33-...

  • Page 36: Lubrication Decals

    LUBRICATION DECALS 99952 66076 093020 093020 -34-...
  • Page 37 LUBRICATION DECALS Remote Zerks (2) Zerks for Vertical Beater Top Bearings 093020 093020 99955 093020 -35-...
  • Page 38 LUBRICATION DECALS Note: loooking from under the spreader Remote Zerks (2) Zerks on Torque Limiting Clutch (Driveline PTO under rear of spreader) 093020 093020 -36-...

  • Page 39: Lubrication Guide

    LUBRICATION GUIDE GENERAL INFORMATION IMPORTANT: Catch and dispose of fluid per local waste disposal regulations whenever service is performed on hydraulic components, valves, cylinders, hoses, etc. The operator should become familiar with all lubrication points and establish a systematic routine to ensure complete and quick lubrication of the machine.

  • Page 40: Branding Decals

    BRANDING DECALS HS103270 HS103291 DCSERIAL DCSERIAL HS103201 84044 -38-...
  • Page 41 BRANDING DECALS HS103380 HS103394 97099 97095 HS103380 HS103394 -39-...

  • Page 42: Cap Screw Torque Values

    CAP SCREW TORQUE VALUES -40-...

  • Page 43: Hydraulic Fitting Torque Specifications

    HYDRAULIC FITTING TORQUE SPECIFICATIONS -41-...
  • Page 44 HYDRAULIC FITTING TORQUE SPECIFICATIONS -42-...

  • Page 46: Transporting

    TRANSPORTING TRANSPORT LIGHTING & REFLECTORS When transporting on the highway, connect the spreader to the tractor with a lighting power cord. lighting system is to be connected to the 7 pin power receptacle (per SAEJ560B) on your tractor. If your tractor is not equipped with the proper receptacle, see your tractor dealer for details.

  • Page 47: Preparing For Operation

    PREPARING FOR OPERATION TRACTOR CONNECTIONS Tractor Hitch Fasten the spreader hitch to the drawbar with a hitch pin with a safety locking device. Use a 1-1/4” diameter hitch pin to pull spreader. Remove the weight from the jack (jack is not to be used when spreader is loaded).
  • Page 48 PREPARING FOR OPERATION PTO ASSEMBLY Attach the PTO of the spreader to the tractor by sliding the spring loaded locking collar on PTO yoke rearward, then sliding it onto the tractor PTO shaft. Release spring loaded collar. Be sure the pins fall into the groove of the tractor PTO shaft and collar snaps forward into locking position.

  • Page 49: Operation

    OPERATION EMERGENCY SHUTDOWN If a foreign object becomes lodged in the beater area and disengages the torque limiting clutch, stop the hydraulic drive apron and disengage the PTO. Stop the tractor engine, remove the ignition key, and allow all mechanisms to stop before cleaning or working on the spreader. LOADING Begin loading the spreader at the front end and work toward the rear until loading is completed.
  • Page 50 OPERATION NOW STANDARD - REVERSING THE MAIN APRON If the manure spreader is equipped with a reversing valve that allows the operator to reverse the main apron if a problem arises such as an obstruction in the beater area. Follow the steps below to reverse the apron. CAUTION: DO NOT RUN THE APRON CHAIN IN REVERSE LONGER THAN NECESSSARY AS DAMAGE COULD OCCUR IF THE LOAD IS BACKED INTO THE FRONT OF THE MANURE SPREADER.

  • Page 51: Servicing

    SERVICING NOTE: Be certain to disconnect all sources of power before servicing. Keep pant cuffs and loose clothing away from all drives as well as the other moving parts. Keep off the equipment when in use, and keep all shields in place. Do not attempt to clean, grease or lubricate while the machine is running. Never allow riders in or on the machine.

  • Page 52: Adjustments

    ADJUSTMENTS MAIN APRON ADJUSTMENT Loosen front jam nut. Tighten rear nut until desired tension is achieved. Tighten evenly to ensure chain slats are straight. Retighten jam nuts before operating. (1 on each front corner of the spreader - see image in the pictures below). Adjustment Bolt Left side of the Spreader Adjustment Bolt...
  • Page 53 ADJUSTMENTS MAIN APRON ADJUSTMENT Apron slats should sit 1/2” above the first driveshaft support cross member. The apron will be damaged if the machine is operated with one end of the apron slats running ahead of the opposite end. TIMING OF BEATERS The vertical beaters on the manure spreader are preset from the factory.
  • Page 54 ADJUSTMENTS BEATER REMOVAL The beater attachment can easily be removed for various reasons such as manure stock piling. 1. Remove bolts, nuts at the same location on each side (A). 2. Disconnect the quick disconnect PTO from the gearbox under the rear of the manure spreader and remove the rear half of the PTO.

  • Page 55: Optional Equipment

    OPTIONAL EQUIPMENT ELECTRIC ADJUST HYDRAULIC VARIABLE SPEED APRON CONTROL The optional electric adjust valve allows you to adjust your apron speed from the tractor cab if the tractor is not equipped with variable speed hydraulic controls. MANUAL ADJUST HYDRAULIC VARIABLE SPEED APRON CONTROL HYDRAULIC ACTUATOR LIGHT COVERS The optional light covers are hydraulically linked to the hydraulic end gate so that when the end gate is raised, the cover closes over...
  • Page 56 OPTIONAL EQUIPMENT RUBBER SPRING SUSPENSION PACKAGE FIT-A-ROUND SCREEN EXTENSION -54-...

  • Page 58: Service Notes

    SERVICE NOTES __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ -56-...
  • Page 59 SERVICE NOTES __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ -57-...
  • Page 61 H&S MFG. CO. products approved for the FEMA SEAL OF QUALITY Manufactured By: H&S MANUFACTURING CO., INC. 2608 S. HUME AVE. MARSHFIELD, WI 54449 (715) 387-3414 | hsmfgco.com...
