Hyundai Santa Cruz Bull Bar Installation Instruction

Thank you very much for choosing our products.
Please read the installation instruction carefully before using our product and be sure to
fully understand the contents mentioned above for subsequent installation.
In addition, please keep properly the installation instruction for product maintenance in
future.
 The following symbols are used in this installation instruction.
 Non-compliance may cause the problems with vehicle. Please do not
install that is not recorded in this instruction.
 Please forgive that we are not responsible for any consequences
arising from the installation not according to our installation instruction.

Product Composition *Please confirm if it is missing.
Mounting bracket 1 Mounting bracket 2
(2 pieces) (2 pieces L/R)
M12 Nut M10 Lock Washer
(4 pieces) (4 pieces)

Attentions
- The labels of fitting procedure inside the thick wireframe is particularly important. Pay attention to them in the
actual installation.
- Pay attention to safety during installation.
Hyundai Santa Cruz Bull Bar
Installation Instruction
Attentions
Relevant matters must be obeyed for safety.
Non-compliance may result in injury or other
accidents.
Please read carefully and obey strictly.
Relevant matters must be obeyed for the smooth
installation
and use.
M10*30 T Bolt
(4 pieces)
M10 Flat Washer
(4 pieces)
M12*35 Bolt M12 Lock Washer
(6 pieces) (6 pieces)
M10 Nut
(4 pieces)
M12 Flat Washer
(10 pieces)
