Hyundai Sonata 2015 Manual

~ Accessory Installation
Instructional Symbols / Definitions
Denotes warnings that may lead to
serious physical injury or vehicle
damage.
Denotes cautions to be taken to
avoid physical injury or electronic
component damage.
Denotes cautions to be taken to avoid
vehicle and component damage.
Basic Required Hand Tools
Ratchet 10mm Socket
T20 Torx Driver Torque Wrench
Notes to the Installer:
1) Read the entire installation instructions prior to beginning the installation of this accessory.
2) Make sure the vehicle is completely clean before the accessory is installed.
3) Ensure the vehicle is properly protected in the area(s) that the accessory is to be installed.
4) To prevent vehicle damage, never place tools on top of painted surfaces, seats, dash pad, console,
or floor/carpet/mats.
5) Always wear appropriate safety gear to include gloves and safety glasses when required.
6) Do NOT accidently start vehicle while performing function checks at the end of the install.
*550-0624-000*
550-0624 Rev. AAA
HYUNDAI Genuine Accessories
Sonata
Vehicle Model
2015 ~
Model Year
C2062 ADU00/P0
Part No.
Note: Difficulty stated above reflects the minimum level of expertise
required to install the accessory.
( A ) Customer ( B ) Dealer Technician
This product is only applicable to vehicles equipped with Blue Link.
Denotes quality processes to be
checked prior to moving to the
next step.
Denotes specific tools that are
necessary to complete the step.
Denotes instructional steps
N
O necessary to complete the
T
process.
E
T20 Torx Socket
Revision Date
03/03/2014
Accessory
Mirror, Auto-dim w/
HL4, BL, & Comp
( B )
Difficulty
( C ) Master Technician
Denotes safety equipment required to
be used such as a mask, safety glasses,
gloves, and hearing protection.
Mask Safety Glasses
Hearing Protection
Gloves
All dealers must determine if
FMVSS 110
the weight they have added
Compliance
in the form of all options or
Information accessories, when added to
the weight of all Port/Dealer
Installed options or acces-
Part Number:
sories, exceeds the lesser
C2062 ADU00
of 1.5% of GVWR or 100
lbs. If the additional weight
C2062 ADUP0
does exceed the lesser of
the indicated thresholds,
1.31 lbs
a "Load Carrying Capacity
0.593 kg Reduced" label must be
installed. A black fine point,
(Gross Weight)
indelible marker must be
used to write by hand onto
the label, the reduced car-
rying capacity in kilograms
or pounds, which is the total
weight of all added options
and accessories.
Load Label Part Number:
NP070 - 09003
Page: 1 of 9
