Schwinn 430: Why is the resistance not changing when adjusted?
Follow this troubleshooting guide to help resolve resistance issues on your Schwinn 430 Elliptical.
Some common complaints may include:
Resistance isn't changing
Can't adjust resistance
Resistance buttons not working
Too easy to pedal
Too difficult to pedal
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
Flathead screwdriver
(2) 6mm hex/Allen wrenches or the wrench from the
hardware card included with your machine
Voltmeter
1.
Inspect the cables at the console. Unplug your machine from power. Use a Phillips head screwdriver to remove the 4
screws connecting the console to the mast and lift the console/handlebars up to expose the cables (reference 1).
Disconnect and inspect the cables and connections coming from the console and the frame for damage, such as
crimps, cuts, or bent pins. If the cables are undamaged, plug them back in, ensuring they are oriented in the correct
direction, and retest your machine [12763.A]. If the console is damaged,
coming from the frame is damaged,
about:blank
Schwinn 430:  Why is the resistance not changing when adjusted?
order a Mast Cable [12763.C].
(Reference 1)
order a Console [12763.B]. If the cable
ID: 12763.1
