Schwinn AirDyne AD6 Troubleshooting Manual

Noises from the arm pivot and handlebar/footpeg connection

Hide thumbs Also See for AirDyne AD6:

Download this manual

3/11/24, 3:25 PM

Schwinn AirDyne AD6: Noises from the arm pivot and

handlebar/footpeg connection

Follow this troubleshooting guide to help resolve noise issues on the Schwinn AirDyne AD6.

Some common complaints may include:

Rubbing noises

Squeaking or creaking noises

Squealing noises

Clicking or clunking noises

Follow these steps to troubleshoot the issue

Tools you may need:

Phillips head screwdriver

4mm, 6mm hex/Allen wrenches, or the wrench from the

hardware card included with your machine

14mm socket wrench

Refer to the "Replace the Arm Pivot Assembly" section of the

connection. Follow the steps outlined in the procedure until you reach the step to disconnect the handlebar from the

arm pivot assembly.

Use a 6mm Allen wrench to tighten the two screws on the handlebar (reference 1). Tighten them as much as you can

without stripping the screws. Test to see if the noise persists [13788.A].

about:blank

Schwinn AirDyne AD6:  Noises from the arm pivot and handlebar/footpeg connection

(Reference 1)

service manual

for instructions on accessing the

ID: 13788.1

1/3

Need help?

Do you have a question about the AirDyne AD6 and is the answer not in the manual?

Page 1 Schwinn AirDyne AD6:  Noises from the arm pivot and handlebar/footpeg connection Schwinn AirDyne AD6: Noises from the arm pivot and handlebar/footpeg connection ID: 13788.1 Follow this troubleshooting guide to help resolve noise issues on the Schwinn AirDyne AD6. Some common complaints may include: Rubbing noises Squeaking or creaking noises...
Page 2 3/11/24, 3:25 PM Schwinn AirDyne AD6:  Noises from the arm pivot and handlebar/footpeg connection The screws to tighten on the handlebar are circled. If the issue persists or damage is present, order an Arm Pivot, Left Handlebar, and Right Handlebar [13788.B]. If the issue persists after replacing the arm pivot and handlebar, please select another noise topic to troubleshoot further.
