- Page 1 HARDWARE QUICK START GUIDE VIA AMOS-9000 Compact and fanless Hexa-Core Arm® system for demanding Edge AI, factory safety and automation applications 1.00-27122024...
- Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
- Page 3 Safety Precautions • Always read the safety instructions carefully. • Keep this User Manual for future reference. • All cautions and warnings on the equipment should be noted. • Keep this equipment away from humidity and direct sunlight. • Put this equipment on a reliable flat surface before setting it up. •...
- Page 4 Description AMOS-9000-1H11A0 VIA AMOS-9000 system with 1.5GHz NVIDIA Jetson Orin Nano Hexa-Core SoC, 8GB LPDDR5 DRAM, 128GB SSD, HDMI, 3 USB 3.2 Type A, USB 3.2 Gen 1, Micro USB 2.0 OTG, 2 GLAN, 2 COM, CAN/UART, DIO, Audio jack, 3 M.2 slots, Micro SIM card slot, 12˜24V DC-in...
-
Page 5: Table Of Contents
VIA AMOS-9000 Hardware Quick Start Guide Table of Contents Introduction ..............................1 System Specifications ..........................1 System Layout ............................4 System Dimensions ..........................6 Hardware Installation ............................. 7 System Installation ..........................7 Connecting the System to a Power Source ................... 7... - Page 6 Figure 03: VIA AMOS-9000 system left panel I/O ....................5 Figure 04: VIA AMOS-9000 system right panel I/O ....................5 Figure 05: Dimensions of the VIA AMOS-9000 system (front panel I/O) ............. 6 Figure 06: Dimensions of the VIA AMOS-9000 system (left panel I/O) ..............6 Figure 07: Connecting the power cable to the system ..................
-
Page 7: Introduction
VIA AMOS-9000 a highly flexible and reliable platform for many smart entry-level commercial, consumer, and industrial applications, such as, Edge AI, factory safety and automation. This user guide introduces the VIA AMOS-9000 system and provides instructions to quickly set up the system for use. - Page 8 VIA AMOS-9000 Hardware Quick Start Guide Onboard I/O • 1 x M.2 M Key for an M.2 M Key 2280 PCIe/NVMe SSD • 1 x M.2 B Key slot for a 4G LTE/5G mobile broadband module • 1 x M.2 E Key for a Wi-Fi module •...
- Page 9 VIA AMOS-9000 Hardware Quick Start Guide Mechanical Construction • Aluminum alloy metal chassis Dimensions • 150mm(W) x 66.7mm (H) x 105.2mm (D) (5.90" x 2.62" x 4.14") Weight • 1.3kg (3lbs) Compliance • CE, FCC, BSMI, UKCA, VCCI Note: As the operating temperature provided in the specifications is a result of testing performed in a testing chamber, a number of variables can influence this result.
-
Page 10: System Layout
VIA AMOS-9000 Hardware Quick Start Guide 1.2 System Layout GLAN HDMI Micro SIM Card Slot DC-In Jack Audio Jack Power Button USB 3.2 Type A Figure 01: VIA AMOS-9000 system front panel I/O CAN/UART Antenna Holes Figure 02: VIA AMOS-9000 system back panel I/O... -
Page 11: Figure 03: Via Amos-9000 System Left Panel I/O
VIA AMOS-9000 Hardware Quick Start Guide USB 3.2 Type A Antenna Hole Figure 03: VIA AMOS-9000 system left panel I/O Reset Button Software Upgrade Button Ground Micro USB 2.0 OTG USB 3.2 Gen 1 Figure 04: VIA AMOS-9000 system right panel I/O... -
Page 12: System Dimensions
VIA AMOS-9000 Hardware Quick Start Guide 1.3 System Dimensions 66.7mm (2.62 in.) 150mm (5.90 in.) Figure 05: Dimensions of the VIA AMOS-9000 system (front panel I/O) 105.2mm (4.14 in.) Figure 06: Dimensions of the VIA AMOS-9000 system (left panel I/O) -
Page 13: Hardware Installation
2.2 Connecting the System to a Power Source The VIA AMOS-9000 system requires a 12V or 24V DC input power supply. A 2-pole Phoenix plug to DC jack power cable is provided in the VIA AMOS-9000 system's standard package for connecting to a compatible 100 ~ 240V AC-to-DC power adapter. -
Page 14: Figure 08: The "Power" Button
VIA AMOS-9000 Hardware Quick Start Guide Step 4 Switch ON the power source and press the "POWER" button on the VIA AMOS-9000 system's front panel. Power Button Figure 08: The "POWER" button... -
Page 15: Technical Support And Assistance
VIA AMOS-9000 Hardware Quick Start Guide 3. Technical Support and Assistance • For utility downloads, the latest documentation, and information about the VIA AMOS-9000 system, please visit our website at https://www.viatech.com/en/edge/via-amos-9000/. • For technical support and additional assistance, always contact your local sales representative or system distributor, or go to https://www.viatech.com/en/support/drivers/... - Page 16 Taiwan Headquarters Japan China 1F, 531 Zhong-zheng Road, 940 Mission Court 3-15-7 Ebisu MT Bldg. 6F, Tsinghua Science Park Bldg. 7 Xindian Dist., New Taipei City 231 Fremont, CA 94539, Higashi, Shibuya-ku No. 1 Zongguancun East Road, Taiwan Tokyo 150-0011 Haidian Dist., Beijing, 100084 Japan China...
