- Page 1 USER MANUAL VIA AMOS-3006 Ultra-compact fanless system for embedded transportation applications in demanding environments 1.00-01222020-144700...
- Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
- Page 3 Battery Recycling and Disposal • Only use the appropriate battery specified for this product. • Do not re-use, recharge, or reheat an old battery. • Do not attempt to force open the battery. • Do not discard used batteries with regular trash. •...
- Page 4 VIA AMOS-3006 User Manual Box Contents • 1 x VIA AMOS-3006 system • 1 x 4-pole Phoenix plug connector • 1 x Screw pack for miniPCIe and mSATA modules • 2 x Thermal pads for mSATA module and heatsink • 1 x Screw pack for mounting •...
-
Page 5: Table Of Contents
VIA AMOS-3006 User Manual Table of Contents 1. Product Overview ......................1 Key Features ............................1 1.1.1 High-Performance .......................... 1 1.1.2 Fanless and Ruggedized Chassis ....................1 1.1.3 Optimized Integration with Multiple I/O Access ................1 1.1.4 Storage Expansion .......................... 1 1.1.5 Networking Support........................1 1.1.6... - Page 6 VIA AMOS-3006 User Manual 6.5.1 ACPI Settings ..........................31 6.5.1.1 Enable Hibernation ......................31 6.5.1.2 ACPI Sleep State ........................ 31 6.5.2 S5 RTC Wake Settings ........................32 6.5.2.1 Wake system with Fixed Time ................... 32 6.5.2.2 Wake system with Dynamic Time ..................32 6.5.3 CPU Configuration ........................33 6.5.4...
- Page 7 VIA AMOS-3006 User Manual Save & Exit ............................49 6.9.1 Save Changes and Exit ......................... 49 6.9.2 Discard Changes and Exit ......................49 6.9.3 Save Changes and Reset ......................49 6.9.4 Discard Changes and Reset ......................49 6.9.5 Save Changes ..........................49 6.9.6...
- Page 8 VIA AMOS-3006 User Manual List of Figures Figure 1: Front panel I/O layout .......................... 6 Figure 2: Back panel I/O layout ........................... 6 Figure 3: Dimensions of the VIA AMOS-3006 (front view) .................. 7 Figure 4: Dimensions of the VIA AMOS-3006 (side view) ................... 7 Figure 5: HDMI port diagram ..........................8 Figure 6: USB 3.0 port diagram .......................... 8 Figure 7: Lockable USB 2.0 port diagram ......................9 Figure 8: Gigabit Ethernet port diagram ......................
- Page 9 VIA AMOS-3006 User Manual Figure 56: Illustration of the Save & Exit Settings screen ..................49 Figure 57: Installing the VIA EMIO-1542 module ....................52 Figure 58: Removing the two Wi-Fi antenna holes covers .................. 52 Figure 59: Installing the Wi-Fi antenna cables and antennas ................53 Figure 60: Connecting the Wi-Fi antenna cables to VIA EMIO-1542 module............54 Figure 61: Inserting the VIA EMIO-2531 module ....................55 Figure 62: Securing the VIA EMIO-2531 module ....................55 Figure 63: Removing the Wi-Fi & BT antenna hole cover ..................56 Figure 64: Installing the Wi-Fi & BT antenna cable and antenna ................
- Page 10 VIA AMOS-3006 User Manual List of Tables Table 1: HDMI port pinouts ..........................8 Table 2: USB 3.0 ports pinouts .......................... 8 Table 3: Lockable USB 2.0 ports pinouts ......................9 Table 4: Gigabit Ethernet ports pinouts ......................9 Table 5: Gigabit Ethernet port LED color definition ................... 9 Table 6: VGA port pinouts ..........................
-
Page 11: Product Overview
VIA AMOS-3006 User Manual 1. Product Overview Speed up your commercial and industrial IoT and edge intelligence installations with the VIA AMOS-3006. This ruggedized, fanless system is designed to offer great performance and a rich I/O geature set in the most demanding embedded in-vehicle applications that involve harshest environments. In addition to supporting a wide operating temperature range from -20°C to 60°C and a wide voltage input from 9 ~ 30V, the VIA AMOS-3006 also offers rich array of networking, connectivity, and I/O features, including dual Gigabit Ethernet, four COM ports, two CAN bus ports, and Wi-Fi and dual 4G SIM card support. Fully compatible with a wide range of Microsoft® Windows® operating systems, including Windows 10 IoT, as well as the popular Linux distributions. The VIA AMOS-3006 is powered by high performance 1.2GHz VIA Eden® X4 processor, and its housing is made of a heavy-duty steel body chassis and a robust aluminum alloy top cover that provides high stability which can withstand shock and vibration. Key Features 1.1.1 High-Performance... -
Page 12: Shock And Vibration Resistant
VIA AMOS-3006 User Manual 1.1.8 Shock and Vibration Resistant The VIA AMOS-3006 is shock resistant for maximum reliability. 1.1.9 Mounting Solution The VIA AMOS-3006 supports multiple methods for mounting the chassis securely. In can be mounted to any flat surface, or even to VESA mountable surfaces with the VESA mounting kit. 1.1.10 Embedded Operating System Ready The VIA AMOS-3006 is fully compatible with Microsoft® Windows 10, Windows 8.1, Windows 8, Windows 7, Windows 10 IoT, Windows Embedded Standard 7, and Linux. -
Page 13: Product Specifications
VIA AMOS-3006 User Manual Product Specifications Processor • 1.2GHz VIA Eden® X4 Chipset • VIA VX11 Media System Processor BIOS • AMI BIOS, 32Mbit Flash memory System Memory • 1 DDR3 1333 SDRAM slot Storage • 1 x mSATA slot Graphics • Integrated C-640 DX11 3D/2D graphics with MPEG-2, WMV9, VC-1 and H.264 video decoding accelerator Audio • VIA VT2021 High Definition Audo Codec Display I/O • 1 x HDMI port • 1 x VGA port supporting VGA resolutions up to 2048x1536 pixel • Dual independent VGA + HDMI display at different resolutions, pixel depths, and refresh rates • 2 x USB 3.0 ports •... - Page 14 VIA AMOS-3006 User Manual Front Panel I/O • 2 x Lockable USB 2.0 ports • 2 x COM ports for RS-232/422/485 • 2 x COM ports for RS-232 • 1 x Red LED for HDD activity • 1 x Green LED for power status • 5 x Antenna holes for 4G, GPS, and Wi-Fi Back Panel I/O • 1 x HDMI port • 1 x VGA port • 2 x USB 3.0 ports •...
- Page 15 VIA AMOS-3006 User Manual Dimensions • 250mm(W) x 54.1mm(H) x 109.8mm(D) (9.8” x 2.1” x 4.3”) Weight • 1.3kg (2.87lbs) Compliance • CE, FCC, E-Mark Note: As the operating temperature provided in the specifications is a result of testing performed in a testing chamber, a number of variables can influence this result. Please note that the working temperature may vary depending on the actual situation and environment. It is highly recommended to execute a solid testing program and take all variables into consideration when building the system. Please ensure that the system is stable at the required operating temperature in terms of application.
-
Page 16: Layout Diagram
VIA AMOS-3006 User Manual Layout Diagram Figure 1: Front panel I/O layout Figure 2: Back panel I/O layout... -
Page 17: Product Dimensions
VIA AMOS-3006 User Manual Product Dimensions Figure 3: Dimensions of the VIA AMOS-3006 (front view) Figure 4: Dimensions of the VIA AMOS-3006 (side view) -
Page 18: 2. External I/O Pin Descriptions And Functionality
VIA AMOS-3006 User Manual 2. External I/O Pin Descriptions and Functionality The VIA AMOS-3006 has a wide selection of interfaces, and includes a selection of frequently-used ports as part of the external I/O coastline. HDMI Port ® The VIA AMOS-3006 is equipped with one HDMI port on the back panel. A HDMI port Type A receptacle connector provides connection to High Definition video and digital audio using a single cable. The pinouts of the HDMI port are shown below. Signal Signal TX2+ TX2- TX1+ TX1- Figure 5: HDMI port diagram TX0+ TX0- TXC+ TXC- DDCSCL DDCSDA Hot Plug Detect Table 1: HDMI port pinouts USB 3.0 Ports... -
Page 19: Lockable Usb 2.0 Ports
VIA AMOS-3006 User Manual Lockable USB 2.0 Ports The VIA AMOS-3006 is equipped with two lockable USB 2.0 ports on the front panel which gives complete Plug and Play and hot swap capability for external devices. The USB 2.0 interface complies with USB UHCI, Rev. 2.0. The pinouts of the USB 2.0 ports are shown below. USB1 Port USB2 Port Signal Signal VUSB0 VUSB0 USBDT3- USBDT2- USBDT3+ USBDT2+ Figure 7: Lockable USB 2.0 port diagram Table 3: Lockable USB 2.0 ports pinouts Note: To unlock the USB device from the lockable USB 2.0 port, push the tab on the lockable port then pull the USB device. -
Page 20: Audio Jacks
VIA AMOS-3006 User Manual Audio Jacks The VIA AMOS-3006 offers High Definition audio through two 3.5mm TRS jacks on the back panel: Line-out and Mic-in. The Line-out jack is used for connecting to external speakers or headphones. The Mic-in jack is used for connecting to a microphone. . The diagram of the audio jacks is shown below. Figure 9: Audio jacks diagram LED Indicators There are two LEDs on the front panel of the VIA AMOS-3006 that indicates the status of the system. ● Power LED (PWR) is green and indicates the status of the system's power. ● HDD LED (DISK) is red and indicates the storage activity. Figure 10: LED indicators diagram VGA Port The VIA AMOS-3006 provides a high resolution VGA interface through DE-15 female connector on the back panel. It supports resolutions up to 2048 x 1536 pixels. The pinouts of the VGA port are shown below. Signal Signal Green Blue DDC_SPD Figure 11: VGA port diagram HSync VSync DDC_SCL Table 6: VGA port pinouts... -
Page 21: Com Ports
VIA AMOS-3006 User Manual COM Ports The VIA AMOS-3006 is equipped with four COM ports on the front panel labeled as 'COM 1', 'COM 2', 'COM 3' and 'COM 4'. The COM 1 and COM 2 ports can be configured as RS-232, RS-422, or RS-485 mode. The COM 3 and COM 4 ports' default settings are RS-232 mode. To configure the COM 1 and COM 2 ports, the user needs to setup it in the BIOS. The COM ports pinouts are shown below. Figure 12: COM port diagram COM 1 COM 2 COM 3 COM 4 Signal Signal Signal Signal COM_DCD1 COM_DCD2 COM_DCD3 COM_DCD4 COM_RXD1 COM_RXD1 COM_RXD3 COM_RXD4 COM_TXD1 COM_TXD2 COM_TXD3 COM_TXD4 COM_DTR1 COM_DIR2 COM_DTR3 COM_DTR4... -
Page 22: 2.10 Can Bus Ports
VIA AMOS-3006 User Manual 2.10 CAN Bus Ports The VIA AMOS-3006 is equipped with two CAN bus ports located on the back panel labeled as 'CAN1' and 'CAN2'. Each CAN bus port supports one CAN bus connection. The CAN bus ports supports protocol specification Version 2.0 B. The pinouts of the CAN bus ports are shown below. CAN 1 Port CAN 2 Port Signal Signal CAN1_L CAN2_L Figure 14: CAN bus port diagram CAN1_H CAN2_H Table 9: CAN bus ports pinouts 2.11 DC-in Jack The VIA AMOS-3006 integrates a 4-pole Phoenix DC-in jack that carries a 9V ~ 30V DC external power input. The pinouts of the 4-pole Phoenix DC-in jack are shown below. Signal DC-IN Figure 15: DC-in jack diagram Table 10: DC-in jack pinouts... -
Page 23: 3. Onboard I/O
VIA AMOS-3006 User Manual 3. Onboard I/O This chapter provides information about the onboard connectors on the VIA AMOS-3006. MiniPCIe Slots The VIA AMOS-3006 is equipped with two miniPCIe slots for wireless networking options such as a Wi-Fi, BT, 4G and GPS modules. The miniPCIe slots are labeled as 'MINIPCIE1' and 'MINIPCIE2'. The location of the miniPCIe slots are shown below. Figure 16: MiniPCIe slots diagram SIM Card Slots The VIA AMOS-3006 comes with two SIM card slots that supports 4G SIM cards. SIM card usage on the VIA AMOS- 3006 requires that a 4G module is installed in the miniPCIe slot, enabling the 4G functionality, otherwise the SIM card slot will be disabled. The SIM card slot is designed for use with 4G modules that do not support built-in SIM card slots. The SIM card slots are labeled as 'SIM1' and 'SIM2'. The location of the SIM card slots are shown below. Figure 17: SIM card slots diagram... -
Page 24: Usb Wi-Fi Connectors
VIA AMOS-3006 User Manual USB Wi-Fi Connectors The VIA AMOS-3006 is equipped with two onboard USB Wi-Fi connectors labeled as 'JWLAN1' and 'JWLAN2' for VIA EMIO-1542 USB Wi-Fi module. The location of the USB Wi-Fi connectors are shown below. Figure 18: USB Wi-Fi connectors diagram mSATA Slot The VIA AMOS-3006 comes with an mSATA slot which supports mSATA flash drive module to have a flexible storage. The mSATA slot is labeled as 'MSATA'. The location of the mSATA slot is shown below. Figure 19: mSATA slot diagram... -
Page 25: Ddr3 Sodimm Slot
VIA AMOS-3006 User Manual DDR3 SODIMM Slot The AMOS-3006 comes with one DDR3 SODIMM slot labeled as 'SODIMM' that supports non-ECC DDR3 1333 SDRAM SODIMM memory module. The DDR3 SODIMM memory slot can accommodate up to 8GB memory size. The location of the DDR3 SODIMM slot is shown below. Figure 20: DDR3 SODIMM slot diagram... -
Page 26: 4. Onboard Jumper
VIA AMOS-3006 User Manual 4. Onboard Jumper Jumper Description A jumper consists of a pair of conductive pins used to close in or bypass an electronic circuit to set up or configure a particular feature using a jumper cap. The jumper cap is a small metal clip covered by plastic. It performs like a connecting bridge to short (connect) the pair of pins. The usual colors of the jumper cap are black/red/blue/white/yellow. Jumper Setting There are two settings of the jumper pin: 'Short and Open'. The pins are 'Short' when a jumper cap is placed on the pair of pins. The pins are 'Open' if the jumper cap is removed. In addition, there are jumpers that have three or more pins, and some pins are arranged in series. In case of a jumper with three pins, place the jumper cap on pin 1 and pin 2 or pin 2 and 3 to Short it. Some jumpers size are small or mounted on a crowded location on the board that makes it difficult to access. Therefore, using a long-nose plier in installing and removing the jumper cap is very helpful. Figure 21: Jumper settings example Caution: Make sure to install the jumper cap on the correct pins. Installing it on the wrong pins might cause damage and malfunction. -
Page 27: Usb 2.0 Power Type Jumper
VIA AMOS-3006 User Manual USB 2.0 Power Type Jumper The USB 2.0 power type jumper labeled as 'VUSB_SEL1' controls the power type delivered to the lockable USB 2.0 ports on the front panel. The power can be set either on +5VSUS (Standby power) or +5V. The +5VSUS is the default setting. The VUSB_SEL1 jumper settings are shown below. Figure 22: USB 2.0 power type jumper diagram VUSB_SEL1 Settings Pin 1 Pin 2 Pin 3 Short Short Open +5VSUS (default) Open Short Short Table 11: USB 2.0 power type jumper settings... -
Page 28: 5. Hardware Installation
VIA AMOS-3006 User Manual 5. Hardware Installation This chapter provides information about the hardware installation procedures. It is recommended to use a grounded wrist strap before handling computer components. Electrostatic discharge (ESD) can damage some components. Installing the DDR3 SODIMM Memory Step 1 Remove the six screws of the bottom cover plate, and then gently lift up the bottom plate. Figure 23: Removing the bottom plate cover... -
Page 29: Figure 24: Unscrewing The Front And Back Panel Plates
VIA AMOS-3006 User Manual Step 2 Remove all screws on the front and back panel plates. Then remove all hex standoff screws of the VGA, DIO, CAN bus and COM ports as shown in the figures below. Figure 24: Unscrewing the front and back panel plates Figure 25: Removing all the hex standoff screws of the VGA, DIO, CAN bus and COM ports... -
Page 30: Figure 26: Removing The Front And Back Panel Plates
VIA AMOS-3006 User Manual Step 3 Gently detach the front and back panel plates from the chassis. Figure 26: Removing the front and back panel plates Step 4 Remove the four screws and two hex standoff screws on the VIA EMIO-3006 daughterboard. Figure 27: Unscrewing the VIA EMIO-3006 daughterboard... -
Page 31: Figure 28: Removing The Anti-Vibration Bracket And Two Hex Standoff Screws
VIA AMOS-3006 User Manual Step 5 Remove the anti-vibration bracket, and then remove its two hex standoff screws. Figure 28: Removing the anti-vibration bracket and two hex standoff screws Step 6 Pull up the VIA EMIO-3006 daughterboard to detach it from the mainboard (VIA EITX-2004). Figure 29: Removing the VIA EMIO-3006 daughterboard... -
Page 32: Figure 30: Installing The Ddr3 Sodimm Memory Module
VIA AMOS-3006 User Manual Step 7 Align the notch on the DDR3 SODIMM memory module with the counterpart on the DDR3 SODIMM slot. Then insert the DDR3 SODIMM memory module at a 30° angle. Step 8 Push down the DDR3 SODIMM memory module until the locking clips lock the module into place. Figure 30: Installing the DDR3 SODIMM memory module Step 9 Reinstall the VIA EMIO-3006 daughterboard, anti-vibration and its hex standoff screws, front and back panel plates, and the bottom plate cover. -
Page 33: Installing The Msata Flash Drive Module
VIA AMOS-3006 User Manual Installing the mSATA Flash Drive Module Note: It is highly suggested to use Transcend's mSATA flash drive module. Step 1 Prepare the mSATA thermal pads provided in the package. Step 2 Peel off the bottom protective (plastic) cover of mSATA thermal pad. Paste the thermal pad onto the controller chip on mSATA module. Figure 31: Installing the mSATA thermal pad Step 3 Peel off the remaining protective (plastic) cover of the mSATA thermal pad. Figure 32: Peeling off the protective plastic cover of mSATA thermal pad... -
Page 34: Figure 33: Inserting The Msata Module
VIA AMOS-3006 User Manual Step 4 Flip over the mSATA module. Align the notch on the mSATA module with the counterpart on the mSATA slot. Then insert the module at a 30° angle. Figure 33: Inserting the mSATA module Step 5 Once the mSATA module has been fully inserted, push down the module until the screw hole is aligned with the standoff hole. Then secure the module with the provided screw. Figure 34: Securing the mSATA module... -
Page 35: Figure 35: Installing The Thermal Pad On Msata Heatsink
VIA AMOS-3006 User Manual Step 6 Install the thermal pad for the mSATA heatsink as shown in the figure below. Make sure to removed the protective (plastic) cover of the thermal pad. Figure 35: Installing the thermal pad on mSATA heatsink Step 7 Reinstall the VIA EMIO-3006 daughterboard, anti-vibration bracket and its hex standoff screws, front and back panel plates, and the bottom plate cover. -
Page 36: Installing The 4G Sim Card
VIA AMOS-3006 User Manual Installing the 4G SIM Card Step 1 Remove the bottom plate cover. Step 2 Firmly push back the SIM card slot to unlock the opening. Then pull up the slot and place the 4G SIM card inside. Close the SIM card slot and lock it by sliding back the slot. Figure 36: Installing the 4G SIM card... -
Page 37: Installing The Rubber Feet
VIA AMOS-3006 User Manual Installing the Rubber Feet Step 1 On the bottom side of the VIA AMOS-3006, identify the area where to install the rubber feet. Step 2 Attach each rubber foot. Firmly press it down to ensure the rubber foot is properly in place. Figure 37: Installing the rubber feet... -
Page 38: 6. Bios Setup
VIA AMOS-3006 User Manual 6. BIOS Setup This chapter gives a detailed explanation of the BIOS setup functions. Entering the BIOS Setup Utility Power on the computer and press Delete during the beginning of the boot sequence to enter the BIOS Setup Utility. If the entry point has passed, restart the system and try again. Control Keys Move up one row Down Move down one row Left Move to the left in the navigation bar Right Move to the right in the navigation bar Enter Access the highlighted item / Select the item Increase the numeric value Decrease the numeric value General help Restore the previous CMOS value Load optimized defaults Save all the changes and exit Esc Jumps to the Exit screen or returns to the previous screen Notes: 1. Must be pressed using the 10-key pad. -
Page 39: Main Menu
VIA AMOS-3006 User Manual Main Menu The Main menu screen is the default screen that is shown when the BIOS Setup Utility is launched. This screen can be accessed by traversing the navigation bar to the 'Main' label. Figure 38: Illustration of the Main Menu screen 6.4.1 BIOS Information The content in this section of the screen shows the information about the BIOS vendor, the Core version, compliancy, the project version and date & time of the project build. 6.4.2 Memory Information This section shows the amount of memory that is installed on the hardware platform. 6.4.3 System Language This option allows the user to configure the language that the user wants to use. 6.4.4 System Date This section shows the current system date. Press Tab to traverse right and Shift+Tab to traverse left through the month, day, and year segments. The + and - keys on the number pad can be used to change the values. The weekday name is automatically updated when the date is altered. The date format is [Weekday, Month, Day, Year]. -
Page 40: Advanced Settings
VIA AMOS-3006 User Manual Advanced Settings The Advanced Settings screen shows a list of categories that can provide access to a sub-screen. Sub-screen links can be identified by the preceding right-facing arrowhead. Figure 39: Illustration of the Advanced Settings screen The Advanced Settings screen contains the following links: ● ACPI Settings ● S5 RTC Wake Settings ● CPU Configuration ● SATA Configuration ● USB Configuration ● F81865 Super IO Configuration ● F81865 H/W Monitor ● Clock Generator Configuration... -
Page 41: Acpi Settings
VIA AMOS-3006 User Manual 6.5.1 ACPI Settings ACPI grants the operating system direct control over system power management. The ACPI Configuration screen can be used to set a number of power management related functions. Figure 40: Illustration of the ACPI Settings screen 6.5.1.1 Enable Hibernation Enable or Disable system ability to Hibernate. 6.5.1.2 ACPI Sleep State Select ACPI sleep state the system will enter when the SUSPEND button is pressed. Available options are: Suspend Disabled/S1 only (CPU Stop Clock)/S3 only (Suspend to RAM)/Both S1 and S3 available for OS to choose from. -
Page 42: S5 Rtc Wake Settings
VIA AMOS-3006 User Manual 6.5.2 S5 RTC Wake Settings The S5 RTC Wake Settings screen enables system to wake from S5 using RTC alarm. Figure 41: Illustration of the S5 RTC Wake Settings screen 6.5.2.1 Wake system with Fixed Time Enable or Disable system wake on alarm event. When enabled, system will wake on the date/ hr:min:sec specified. '0' means everyday. 6.5.2.2 Wake system with Dynamic Time Enable or Disable system wake on alarm event. When enabled, system will wake on the current time + Increase minutes. Available options are 1 – 5. -
Page 43: Cpu Configuration
VIA AMOS-3006 User Manual 6.5.3 CPU Configuration The CPU Configuration screen shows detailed information about the built-in processor. Figure 42: Illustration of the CPU Configuration screen... -
Page 44: Sata Configuration
VIA AMOS-3006 User Manual 6.5.4 SATA Configuration The SATA Configuration screen allows the user to view and configure the SATA configuration settings. Figure 43: Illustration of the SATA Configuration screen 6.5.4.1 SATA Mode This option allows the user to manually configure SATA controller for a particular mode. Set this value to change the SATA to IDE mode. AHCI Set this value to change the SATA to AHCI mode. -
Page 45: Usb Configuration
VIA AMOS-3006 User Manual 6.5.5 USB Configuration The USB Configuration screen shows the number of connected USB devices. Figure 44: Illustration of the USB Configuration screen 6.5.5.1 Legacy USB Support The Legacy USB Support feature enables environments that do not have native USB support to use USB devices. This feature has three options. Enabled The Enabled option keeps the Legacy USB Support feature on at all times. Disabled The Disabled option keeps the Legacy USB Support feature off at all times. Auto The system automatically disables legacy support if no USB Devices are connected. 6.5.5.2 USB 3.0 Support Enable or Disable USB3.0 (XHCI) Controller support. 6.5.5.3 XHCI Hand-off This is a workaround for Operating Systems without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. -
Page 46: Ehci Hand-Off
VIA AMOS-3006 User Manual 6.5.5.4 EHCI Hand-off This is a workaround feature for Operating Systems without EHCI hand-off support. The EHCI ownership change must be claimed by EHCI Driver. Enabled This option enables EHCI hand-off support. Disabled This option disables EHCI hand-off support. 6.5.5.5 USB Mass Storage Driver Support Enable or Disable USB Mass Storage Driver Support. -
Page 47: F81865 Super Io Configuration
VIA AMOS-3006 User Manual 6.5.6 F81865 Super IO Configuration The F81865 Super IO Configuration screen allows the user to set system Super IO Chip parameters. Figure 45: Illustration of the F81865 Configuration screen 6.5.6.1 Serial Port 1 Configuration Set parameters of Serial Port 1 (COM1). 6.5.6.1.1 Serial Port Enable or Disable Serial Port (COM). 6.5.6.1.2 Uart Transmission Mode Change the serial port transmission mode. This feature has 3 options: RS232/RS422/RS485. 6.5.6.2 Serial Port 2 Configuration Set parameters of Serial Port 2 (COM2). 6.5.6.2.1 Serial Port Enable or Disable Serial Port (COM). 6.5.6.2.2 Uart Transmission Mode Change the serial port transmission mode. This feature has 3 options: RS232/RS422/RS485. 6.5.6.3 Serial Port 3 Configuration Set parameters of Serial Port 3 (COM3). 6.5.6.3.1 Serial Port Enable or Disable Serial Port (COM). -
Page 48: Serial Port 4 Configuration
VIA AMOS-3006 User Manual 6.5.6.4 Serial Port 4 Configuration Set parameters of Serial Port 4 (COM4). 6.5.6.4.1 Serial Port Enable or Disable Serial Port (COM). 6.5.6.5 Serial Port 5 Configuration Set parameters of Serial Port 5 (COM5), which is dedicated to Renesas MCU R5F10268. 6.5.6.5.1 Serial Port Enable or Disable Serial Port (COM), which is dedicated to Renesas MCU R5F10268. -
Page 49: F81865 H/W Monitor
VIA AMOS-3006 User Manual 6.5.7 F81865 H/W Monitor The F81865 screen shows the PC Health Status. Figure 46: Illustration of the F81865 H/W Monitor screen... -
Page 50: Clock Generator Configuration
VIA AMOS-3006 User Manual 6.5.8 Clock Generator Configuration The Clock Generator Configuration screen enables access to the Spread Spectrum Setting feature. Figure 47: Illustration of the Clock Generator Configuration screen 6.5.8.1 CPU Spread Spectrum The Spread Spectrum Setting feature enables the BIOS to modulate the clock frequencies originating from the mainboard. The settings are in percentages of modulation. Higher percentages result in greater modulation of clock frequencies. This feature has 3 options: Disabled, +-0.25% and -0.5%. 6.5.8.2 PCIe Spread Spectrum Select PCIe Spread Spectrum. This feature has 2 options: Disabled and -0.5%. -
Page 51: Chipset Settings
VIA AMOS-3006 User Manual Chipset Settings The Chipset Settings screen shows a list of categories that can provide access to a sub-screen. Sub-screen links can be identified by the preceding right-facing arrowhead. Figure 48: Illustration of the Chipset Settings screen The Chipset Settings screen contains the following links: ● DRAM Configuration ● Video Configuration ● PMU-ACPI Configuration ● HDAC Configuration ● Others Configuration... -
Page 52: Dram Configuration
VIA AMOS-3006 User Manual 6.6.1 DRAM Configuration The DRAM Configuration screen has two features for controlling the system DRAM. All other DRAM features are automated and cannot be accessed. Figure 49: Illustration of the DRAM Configuration screen 6.6.1.1 DRAM Clock The DRAM Clock option enables the user to determine how the BIOS handles the memory clock frequency. The memory clock can either be dynamic or static. This feature has four options. By SPD By SPD option enables the BIOS to select a compatible clock frequency for the installed memory. 400 MHz The 400MHz option forces the BIOS to be fixed at 400MHz (DDR3-800) for DDR3 memory modules. 533 MHz The 533MHz option forces the BIOS to be fixed at 533MHz (DDR3-1066) for DDR3 memory modules. 667 MHz The 667MHz option forces the BIOS to be fixed at 667MHz (for DDR3-1333) for DDR3 memory modules. 6.6.1.2 VGA Share Memory (Frame Buffer) The VGA Share Memory feature enables the user to choose the amount of the system memory to reserve for use by the integrated graphics controller. The selections of memory amount that can be reserved are 256MB and 512MB. -
Page 53: Video Configuration
VIA AMOS-3006 User Manual 6.6.2 Video Configuration The Video Configuration screen has features for controlling the integrated graphics controller in the VX11 chipset. Figure 50: Illustration of the Video Configuration screen 6.6.2.1 Select Display Device Control Select VX11 Display Device Control. Available options are: Auto and Manual. 6.6.2.2 Select Display Device 1 and 2 The Select Display Device feature enables the user to choose a specific display interface. This feature has two options: CRT and HDMI. If both Select Display Device 1 and Select Display Device 2 are set to the same interface, then any display device connected to the other interface will not function. For example, if both Select Display 1 and 2 are set to CRT, then no data will be sent to the HDMI port. -
Page 54: Pmu_Acpi Configuration
VIA AMOS-3006 User Manual 6.6.3 PMU_ACPI Configuration The PMU_ACPI Configuration screen can be used to set a number of power management related functions. Figure 51: Illustration of the PMU_ACPI Configuration screen 6.6.3.1 USB S4 WakeUp The USB S4 WakeUp enables the system to resume through the USB device port from S4 state. There are two options: Enabled and Disabled. -
Page 55: Hdac Configuration
VIA AMOS-3006 User Manual 6.6.4 HDAC Configuration HDAC Configuration Parameters. Figure 52: Illustration of the HDAC Configuration screen 6.6.4.1 OnChip HDAC Device This feature has 2 options: Enable or Disable HDAC Control. -
Page 56: Other Configuration
VIA AMOS-3006 User Manual 6.6.5 Other Configuration The Others Configuration screen can be used to set Watchdog Timer Configuration. Figure 53: Illustration of the Other Configuration screen 6.6.5.1 WATCHDOG Timer Enable The WATCHDOG Timer Enable feature unlocks three other features that enable the BIOS to monitor the state of the system. This feature has two options: Enabled or Disabled. 6.6.5.2 WATCHDOG Timer RUN/STOP The WATCHDOG Timer RUN/STOP feature controls if the WATCHDOG timer is active or dormant. This feature has two options: Stop and Run. 6.6.5.3 WATCHDOG Timer ACTION The WATCHDOG Timer ACTION feature determines the action the WATCHDOG timer should take if the timer counts down to zero. This feature has two options: Reset and Power off. 6.6.5.4 WATCHDOG Timer COUNT The WATCHDOG Timer COUNT feature determines the length of time the timer should count when the timer is first triggered. This feature has four options: 72, 389, 706, and 1023 seconds. -
Page 57: Boot Settings
VIA AMOS-3006 User Manual Boot Settings The Boot Settings screen has a single link that goes to the Boot Configuration and Boot Option Priorities screens. Figure 54: Illustration of the Boot Settings screen 6.7.1 Boot Configuration The Boot Settings Configuration screen has several features that can be run during the system boot sequence. 6.7.2 Setup Prompt Timeout Number of seconds to wait for setup activation key. Minimum: 1 second, Maximum: 10 seconds. 6.7.3 BootupNumLock State Select the keyboard NumLock state from On and Off. 6.7.4 Display Logo Enables or Disables to display full screen logo. 6.7.5 Boot Option Priorities The Boot Option Priorities screen lists all bootable devices. 6.7.6 Launch PXE OpROM policy Controls the execution of UEFI and Legacy PXE OpROM. Do not launch Prevent the option for Legacy Network Device. -
Page 58: Security Settings
VIA AMOS-3006 User Manual Security Settings The Security Settings screen provides a way to restrict access to the BIOS or even the entire system. Figure 55: Illustration of the Security Settings screen 6.8.1 Administrator Password This option is for setting the administrator password for accessing the BIOS setup utility. When the password has been set, a password prompt will displayed whenever the BIOS setup utility is launched. 6.8.2 User Password This option is for setting the user password for accessing the BIOS setup utility or to boot up the operating system. -
Page 59: Save & Exit
VIA AMOS-3006 User Manual Save & Exit The Save & Exit Configuration screen has the following features: Figure 56: Illustration of the Save & Exit Settings screen 6.9.1 Save Changes and Exit Save all changes to the BIOS and exit the BIOS Setup Utility. The 'F4' hotkey can also be used to trigger this command. 6.9.2 Discard Changes and Exit Exit the BIOS Setup Utility without saving any changes. The 'Esc' hotkey can also be used to trigger this command. 6.9.3 Save Changes and Reset Save all changes to the BIOS and reboot the system. The new system configuration parameters will take effect. 6.9.4 Discard Changes and Reset This command reverts all changes to the settings that were in place when the BIOS Setup Utility was launched. Save Options 6.9.5 Save Changes Save Changes done so far to any of the setup options. -
Page 60: Restore Default
VIA AMOS-3006 User Manual 6.9.7 Restore Default Restore/Load Default values for all the setup options. 6.9.8 Save as User Defaults Save the changes done so far as User Defaults. 6.9.9 Restore User Defaults Restore the User Defaults to all the setup options. Boot Override 6.9.10 Launch EFI Shell from filesystem device Attempts to Lauch the EFI Shell application (Shellx64.efi) from one of the available filesystem devices. -
Page 61: 7. Software And Technical Support
VIA AMOS-3006 User Manual 7. Software and Technical Support Microsoft Windows and Linux Support The VIA AMOS-3006 features a complete software evaluation image featuring Microsoft Windows 10/8.1/8/7, Windows 10 IoT, Windows Embedded Standard 7, and Linux operating systems. VIA Smart ETK The VIA AMOS-3006 features a complete software evaluation image featuring VIA Smart ETK. Technical Support and Assistance • For utilities downloads, latest documentation and new information about the VIA AMOS-3006, please visit our website at https:/www.viatech.com/en/systems/amos/amos-3006 • For technical support and additional assistance, always contact your local sales representative or system distributor, or go to https://www.viatech.com/en/support/technical-support/ for technical support. • For OEM clients and system integrators developing a product for long term production, other code and resources may also be made available. Please visit our website at https://www.viatech.com/en/about/contact/... -
Page 62: Appendix A. Installing Wireless Accessories
VIA AMOS-3006 User Manual Appendix A. Installing Wireless Accessories This chapter provides information on how to install the USB Wi-Fi and miniPCIe mobile broadband modules in the VIA AMOS-3006. A.1. Installing the VIA EMIO-1542 USB Wi-Fi Module Step 1 Remove the bottom plate cover and the front panel plate. Step 2 Connect the VIA EMIO-1542 module to the USB Wi-Fi connector labeled as 'JWLAN1' or 'JWLAN2' on the VIA EMIO-3006 daughterboard, and then secure it with the two screws provided. Figure 57: Installing the VIA EMIO-1542 module Step 3 Remove the two Wi-Fi antenna holes covers from the front panel plate. The antenna holes are labeled as 'WLAN1'. To facilitate removing the covers, use a pair of needle-nose pliers to depress both locking clips... -
Page 63: Figure 59: Installing The Wi-Fi Antenna Cables And Antennas
VIA AMOS-3006 User Manual Step 4 Insert the Wi-Fi antenna cables into the antenna holes from inside of the front panel plate. Insert the washers, fasten it with the nuts, and install the antennas. Insert the other end of the antenna cables into the available space going down to the bottom side of the system. Stretchout the cables to reach the installed VIA EMIO-1542 module. Figure 59: Installing the Wi-Fi antenna cables and antennas... -
Page 64: Figure 60: Connecting The Wi-Fi Antenna Cables To Via Emio-1542 Module
VIA AMOS-3006 User Manual Step 5 Connect the other end of the Wi-Fi antenna cables to the micro-RF connectors labeled 'CON0' and 'CON1' respectively on the VIA EMIO-1542 module. Then reinstall the front panel plate. Figure 60: Connecting the Wi-Fi antenna cables to VIA EMIO-1542 module Step 6 Reinstall the bottom plate cover. -
Page 65: A.2. Installing The Via Emio-2531 Minipcie Wi-Fi & Bt Module
VIA AMOS-3006 User Manual A.2. Installing the VIA EMIO-2531 MiniPCIe Wi-Fi & BT Module Step 1 Remove the bottom plate cover and front panel plate. Step 2 Align the notch on the VIA EMIO-2531 module with its counterpart on the miniPCIe slot on the VIA EMIO-3006 daughterboard. Then insert the module at a 30° angle. Figure 61: Inserting the VIA EMIO-2531 module Step 3 Once the VIA EMIO-2531 module has been fully inserted, push down the module until the screw hole align with the standoff hole, and then secure the module with the provided screw. Figure 62: Securing the VIA EMIO-2531 module... -
Page 66: Figure 63: Removing The Wi-Fi & Bt Antenna Hole Cover
VIA AMOS-3006 User Manual Step 4 Remove the Wi-Fi & BT antenna hole cover from the front panel plate. The antenna hole is labeled as 'WLAN1'. To facilitate removing the cover, use a pair of needle-nose pliers to depress both locking clips simultaneously. Figure 63: Removing the Wi-Fi & BT antenna hole cover Step 5 Insert the Wi-Fi & BT antenna cable into the antenna hole from inside of the front panel plate. Insert the washer, fasten it with the nut, and install the antenna. Insert the other end of the antenna cable into the available space going down to the bottom side of the system. Stretchout the cable to reach the installed VIA EMIO-2531 module. Figure 64: Installing the Wi-Fi & BT antenna cable and antenna... -
Page 67: Figure 65: Connecting The Wi-Fi & Bt Antenna Cable To Via Emio-2531 Module
VIA AMOS-3006 User Manual Step 6 Connect the other end of the Wi-Fi & BT antenna cable to the micro-RF connector on the VIA EMIO-2531 module. Then reinstall the front panel plate. Figure 65: Connecting the Wi-Fi & BT antenna cable to VIA EMIO-2531 module Step 7 Reinstall the bottom plate cover. -
Page 68: Installing The Via Emio-2550 Minipcie Mobile Broadband Module
VIA AMOS-3006 User Manual A.3. Installing the VIA EMIO-2550 MiniPCIe Mobile Broadband Module Step 1 Remove the bottom plate cover and front panel plate. Step 2 Remove the 4G and GPS antenna holes covers from the front panel plate. The antenna holes are labeled as 'WWAN1' and 'GPS1'. To facilitate removing the covers, use a pair of needle-nose pliers to depress both locking clips simultaneously. Figure 66: Removing the 4G and GPS antenna holes covers Step 3 Insert the 4G and GPS antenna cables into the antenna holes from inside of the front panel plate. Insert the... -
Page 69: Figure 68: Reinstalling The Front Panel Plate
VIA AMOS-3006 User Manual Step 4 Insert the other end of the 4G and GPS antenna cables into the available space going down to the bottom side of the system. Stretchout the cables to reach where to intall the VIA EMIO-2550 module. Figure 68: Reinstalling the front panel plate Step 5 On the bottom side of the VIA EMIO-2550 module, install the 4G SIM card on the SIM card slot. Figure 69: Installing the 4G SIM card on the VIA EMIO-2550 module Note: Another option is to install the 4G SIM card into the SIM card slot on the VIA EMIO-3006 daughterboard. For 4G SIM card installation, please refer to section 5.3 for details. -
Page 70: Figure 70: Connecting The Gps Antenna Cable To Via Emio-2550 Module
VIA AMOS-3006 User Manual Step 6 Connect the other end of the 4G antenna cable to the micro-RF connector labeled as 'GPS' on the bottom side of the VIA EMIO-2550 module. Figure 70: Connecting the GPS antenna cable to VIA EMIO-2550 module Step 7 Flip over the VIA EMIO-2550 module. Align the notch on the module with its counterpart on the miniPCIe slot on the VIA EMIO-3006 daughterboard. Then insert the module at a 30° angle. Figure 71: Inserting the VIA EMIO-2550 module Reminder: Make sure you have connected the GPS antenna cable first on the VIA EMIO-2550 module before installing it to the miniPCIe slot. -
Page 71: Figure 72: Securing The Via Emio-2550 Module
VIA AMOS-3006 User Manual Step 8 Once the VIA EMIO-2550 module has been fully inserted, push down the module until the screw holes align with the standoff holes and then secure it with the two screws provided. Figure 72: Securing the VIA EMIO-2550 module Step 9 Connect the other end of the 4G antenna cable to the micro-RF connector labeled as 'MAIN' on the VIA EMIO- 2550 module. Figure 73: Connecting the 4G antenna cable to VIA EMIO-2550 module Step 7 Reinstall the bottom plate cover. -
Page 72: Installing The Via Emio-2551 Minipcie Mobile Broadband Module
VIA AMOS-3006 User Manual A.4. Installing the VIA EMIO-2551 MiniPCIe Mobile Broadband Module Step 1 Remove the bottom plate cover and front panel plate. Step 2 Align the notch on the VIA EMIO-2551 module with its counterpart on the miniPCIe slot on the VIA EMIO-3006 daughterboard then insert the module at a 30° angle. Figure 74: Inserting the VIA EMIO-2551 module Reminder: Make sure you have installed the 4G SIM card first into the respective SIM card slot before installing the VIA EMIO- 2551 module. For 4G SIM card installation, please refer to section 5.3 for details. Step 3 Once the VIA EMIO-2551 module has been fully inserted, push down the module until the screw holes align with the standoff holes and then secure it with the two screws provided. Figure 75: Securing the VIA EMIO-2551 module... -
Page 73: Figure 76: Removing The 4G And Gps Antenna Holes Covers
VIA AMOS-3006 User Manual Step 4 Remove the 4G and GPS antenna holes covers from the front panel plate. The antenna holes covers are labeled as 'GPS1' and WWAN1'. To facilitate removing the covers, use a pair of needle-nose pliers to depress both locking clips simultaneously. Figure 76: Removing the 4G and GPS antenna holes covers Step 5 Insert the 4G and GPS antenna cables into the antenna holes from inside of the front panel plate. Insert the... -
Page 74: Figure 78: Connecting The 4G And Gps Antenna Cables To Via Emio-2551 Module
VIA AMOS-3006 User Manual Step 6 Connect the other end of the 4G and GPS antenna cables to the micro-RF connectors labeled as 'MAIN' and 'GNSS' respectively on the VIA EMIO-2551 module. Then reinstall the front panel plate. Figure 78: Connecting the 4G and GPS antenna cables to VIA EMIO-2551 module Step 7 Reinstall the bottom plate cover. -
Page 75: Installing The Via Emio-2573 Minipcie Mobile Broadband Module
VIA AMOS-3006 User Manual A.5. Installing the VIA EMIO-2573 MiniPCIe Mobile Broadband Module Step 1 Remove the bottom plate cover and front panel plate. Step 2 Align the notch on the VIA EMIO-2573 module with its counterpart on the miniPCIe slot on the VIA EMIO-3006 daughterboard then insert the module at a 30° angle. Figure 79: Inserting the VIA EMIO-2573 module Reminder: Make sure you have installed the 4G SIM card first into the respective SIM card slot before installing the VIA EMIO- 2573 module. For 4G SIM card installation, please refer to section 5.3 for details. Step 3 Once the VIA EMIO-2573 module has been fully inserted, push down the module until the screw holes align with the standoff holes and then secure it with the two screws provided. Figure 80: Securing the VIA EMIO-2573 module... -
Page 76: Figure 81: Removing The 4G Antenna Hole Cover
VIA AMOS-3006 User Manual Step 4 Remove the 4G antenna hole cover from the front panel plate. The antenna hole cover is labeled as 'WWAN1'. To facilitate removing the cover, use a pair of needle-nose pliers to depress both locking clips simultaneously. Figure 81: Removing the 4G antenna hole cover Step 5 Insert the 4G antenna cable into the antenna hole from inside of the front panel plate. Insert the washer, fasten it with the nut, and install the antenna. Insert the other end of the antenna cable into the available space going down to the bottom side of the system. Stretchout the cable to reach the installed VIA EMIO-2573 module. Figure 82: Installing the 4G antenna cable and antenna... -
Page 77: Figure 83: Connecting The 4G Antenna Cable To Via Emio-2573 Module
VIA AMOS-3006 User Manual Step 6 Connect the other end of the 4G antenna cable to the micro-RF connector labeled as 'MAIN' on the VIA EMIO- 2573 module. Then reinstall the front panel plate. Figure 83: Connecting the 4G antenna cable to VIA EMIO-2573 module Step 7 Reinstall the bottom plate cover. - Page 78 Taiwan Headquarters Taiwan Headquarters Japan Japan China China 1F, 531 Zhong-zheng Road, 940 Mission Court 3-15-7 Ebisu MT Bldg. 6F, Tsinghua Science Park Bldg. 7 Xindian Dist., New Taipei City 231 Fremont, CA 94539, Higashi, Shibuya-ku No. 1 Zongguancun East Road, Taiwan Tokyo 150-0011 Haidian Dist., Beijing, 100084...
