USER MANUAL
VIA AMOS-3007
Ultra-compact fanless system for embedded
industrial applications ideally suited for
demanding environments
1.00-21092022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMOS-3007 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VIA Technologies AMOS-3007

Summary of Contents for VIA Technologies AMOS-3007

  • Page 1 USER MANUAL VIA AMOS-3007 Ultra-compact fanless system for embedded industrial applications ideally suited for demanding environments 1.00-21092022...
  • Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
  • Page 3 Battery Recycling and Disposal • Only use the appropriate battery specified for this product. • Do not re-use, recharge, or reheat an old battery. • Do not attempt to force open the battery. • Do not discard used batteries with regular trash. •...
  • Page 4 VIA AMOS-3007 User Manual Box Contents • AMOS-3007 system • Phoenix plug to DC jack • Screw pack for mounting • M.2 screw pack (1 screw + 1 standoff) • Rubber feet pack • Thermal pad pack for M.2 modules and DDR4 SODIMM...
  • Page 5 VIA AMOS-3007 User Manual Revision History Revision Date Description 1.00 21/09/2022 Initial release...

  • Page 6: Table Of Contents

    Installing the DDR4 SODIMM Memory ....................17 Installing the M.2 SATA SSD Module ....................20 Installing the Rubber Feet ........................21 Installing the VIA AMOS-3007 ......................21 Mounting the VIA AMOS-3007 on Wall/Table ..................22 Mounting the VIA AMOS-3007 Behind the Monitor ................23...
  • Page 7 VIA AMOS-3007 User Manual BIOS Setup ..............................24 Entering the BIOS Setup Utility ......................24 Control Keys ............................24 Getting Help ............................24 System Overview..........................25 Advanced Settings ..........................26 6.5.1 CPU Configuration ........................27 6.5.2 Hardware Health Monitor ......................27 6.5.3...
  • Page 8 Figure 30: Mounting the VIA AMOS-3007 ......................22 Figure 31: Installing the VESA mounting plate ....................23 Figure 32: Installing VIA AMOS-3007 to the VESA mounting plate ..............23 Figure 33: Illustration of the Main menu screen ....................25 Figure 34: Illustration of the Advanced Settings screen ..................26 Figure 35: Illustration of the CPU Configuration screen ..................
  • Page 9 VIA AMOS-3007 User Manual Figure 46: Illustration of the Memory Configuration screen ................34 Figure 47: Illustration of the PCH-IO Configuration screen ................35 Figure 48: Illustration of the SATA Configuration screen ..................36 Figure 49: Illustration of the HD Audio Configuration screen ................37 Figure 50: Illustration of the Security Settings screen ..................
  • Page 10 VIA AMOS-3007 User Manual List of Tables Table 01: COM port pinouts ..........................6 Table 02: Lockable USB 2.0 ports pinouts ......................7 Table 03: Gigabit Ethernet ports pinouts ......................8 Table 04: Gigabit Ethernet port LED color definition ..................8 Table 05: USB 3.0 ports pinouts ..........................

  • Page 11: Product Overview

    1.1.3 Optimized Integration with Multiple I/O Access With front and back panel I/O access, the VIA AMOS-3007 can be easily configured to support a wide variety of applications with easy integration, and quick setup. 1.1.4 Networking Support The VIA AMOS-3007 is equipped with two RJ-45 ports that support high-speed data Gigabit Ethernet.

  • Page 12: Shock And Vibration Resistant

    The VIA AMOS-3007 is shock resistant for maximum reliability. 1.1.9 Mounting Solution The VIA AMOS-3007 supports two methods for mounting the chassis securely. It can be mounted to any flat surface, or to VESA mountable surfaces with the VESA mounting kit.
  • Page 13 VIA AMOS-3007 User Manual • Fintek Super I/O F81216ED controller • Supports 4 COM ports − BIOS selectable to support adjust functionality of RS-232/422/485 mode of COM1 and COM2 ports − 5V/12V power selection by jumper JCOMV1 and JCOMV2 for COM1 and COM2 ports Expansion I/O •...

  • Page 14: Layout Diagram

    VIA AMOS-3007 User Manual Shock During Operation • With mSATA flash drive: 50G, IEC 60068-2-27, half sine, 11ms duration Mechanical Construction • Aluminum top chassis housing • Metal chassis housing • Removable front and rear metal face plates Mounting •...

  • Page 15: Product Dimensions

    VIA AMOS-3007 User Manual 1.4 Product Dimensions WiFi1 WiFi2 ���� COM1 COM2 USB2.0 USB2.0 AMOS - 3007 170.00mm Figure 03: Dimensions of the VIA AMOS-3007 (front view) Figure 04: Dimensions of the VIA AMOS-3007 (top view)

  • Page 16: External I/O Pin Descriptions & Functionality

    ���� Figure 05: Power ON/OFF button diagram 2.2 LED Indicators There are two LEDs on the front panel of the VIA AMOS-3007 that indicates the status of the system: • The green LED indicates the status of the system’s power.

  • Page 17: Lockable Usb 2.0 Ports

    2.4 Lockable USB 2.0 Ports The VIA AMOS-3007 is equipped with two lockable USB 2.0 ports on the front panel which gives complete Plug and Play and hot swap capability for external devices. The USB 2.0 interface complies with USB UHCI, Rev. 2.0.

  • Page 18: Usb 3.0 Ports

    2.6 USB 3.0 Ports The VIA AMOS-3007 is equipped with two USB 3.0 ports. Each USB 3.0 port has a maximum data transfer rate of up to 5Gb/s and is backwards compatible with the USB 2.0 specification. The USB 3.0 ports provides complete Plug and Play and hot swap capabilities for external devices.

  • Page 19: Hdmi® Port

    2.7 HDMI® Port The VIA AMOS-3007 is equipped with 2 Type A receptacle HDMI ports on the back panel to provide connection to High Definition video and digital audio using a single cable. The pinouts of the HDMI ports are shown below.

  • Page 20: Dc-In Jack

    Table 08: DC-in jack pinouts 2.10 DIO Port The VIA AMOS-3007 is equipped with a DIO port located on the back panel. The DIO port offers a Digital I/O communication interface to support 8-bit GPIO. The pinouts of the DIO port are shown below.

  • Page 21: Onboard I/O

    3.1 M.2 Slots The VIA AMOS-3007 is equipped with 3 M.2 slots for storage and wireless networking options such as a 5G/4G LTE and Wi-Fi modules. The M2_1 slot is an M key (2242) mSATA slot. The M2_2 slot is a B key (3052) LTE slot.

  • Page 22: Sata Connector

    3.4 SIM Card Slot The VIA AMOS-3007 comes with an onboard SIM card slot that supports 5G/4G SIM cards. SIM card usage on the VIA AMOS-3007 requires that a 5G/4G module is installed in the M2_2 slot, enabling the 5G/4G functionality, otherwise the SIM card slot will be disabled.

  • Page 23: Onboard Jumper

    VIA AMOS-3007 User Manual 4. Onboard Jumper Jumper Description A jumper consists of a pair of conductive pins used to close in or bypass an electronic circuit to set up or configure a particular feature using a jumper cap. The jumper cap is a small metal clip covered by plastic. It performs like a connecting bridge to short (connect) the pair of pins.

  • Page 24: Com Voltage Jumpers

    VIA AMOS-3007 User Manual 4.1 COM Voltage Jumpers The COM ports on the front panel can be configured to carry +5V or +12V power, or the Ring Indicator (RI) signal by setting the COM voltage jumpers (JCOMV1 ~ JCOMV2). 4.1.1 JCOMV1 Voltage Jumper The voltage jumper “JCOMV1”...

  • Page 25: Jcomv2 Voltage Jumper

    VIA AMOS-3007 User Manual 4.1.2 JCOMV2 Voltage Jumper The voltage jumper “JCOMV2” is set to determine the input carry voltage or Ring Indicator (RI) signal of COM2 port on the front panel. The control signal Ring Indicator (RI) is the default setting. The jumper settings are shown below.

  • Page 26: Usb 2.0 Power Type Jumper

    VIA AMOS-3007 User Manual 4.2 USB 2.0 Power Type Jumper The USB 2.0 power type jumper labeled as “VUSB_SEL1” controls the power type delivered to the lockable USB 2.0 ports (USB0 and USB1) on the front panel and to the onboard USB pin header (JUSB2_1). The power can be set either on +5VSUS (Standby power) or +5V.

  • Page 27: Hardware Installation

    VIA AMOS-3007 User Manual 5. Hardware Installation This chapter provides information about the hardware installation procedures. It is recommended to use a grounded wrist strap before handling computer components. Electrostatic discharge (ESD) can damage some components. 5.1 Installing the DDR4 SODIMM Memory...

  • Page 28: Figure 24: Installing The System Side Ddr4 Sodimm Module Thermal Pad

    VIA AMOS-3007 User Manual Step 3 Peel off the remaining protective (plastic) cover of the M.2 SATA SSD thermal pad. Figure 24: Installing the system side DDR4 SODIMM module thermal pad Step 4 Align the notch on the DDR4 SODIMM memory module with the counterpart on the DDR4 SODIMM slot. Then insert the DDR4 SODIMM memory module at a 30°...

  • Page 29: Figure 26: Installing The Top Side Ddr4 Sodimm Module Thermal Pad

    VIA AMOS-3007 User Manual Step 5 Prepare the top side DDR4 SODIMM thermal pad included in the package. Paste the thermal pad onto the four memory chips on the DDR4 SODIMM memory module. Step 6 Peel off the remaining protective (plastic) cover of the M.2 SATA SSD thermal pad.

  • Page 30: Installing The M.2 Sata Ssd Module

    VIA AMOS-3007 User Manual 5.2 Installing the M.2 SATA SSD Module Step 1 Remove the bottom plate from the VIA AMOS-3007 as described in Step 1 of section 5.1. Step 2 Align the notch on the M.2 SATA SSD module with the counterpart on the M2_1 slot., then insert the drive at a 30°...

  • Page 31: Installing The Rubber Feet

    1. Make sure to remove the rubber feet before mounting the VIA AMOS-3007. The rubber feet are not required when securing the system onto walls or tables. 2. Do not use other types of screws when mounting the VIA AMOS-3007 aside from the provided screws to avoid any damage.

  • Page 32: Mounting The Via Amos-3007 On Wall/Table

    5.5 Mounting the VIA AMOS-3007 on Wall/Table Step 1 Find a suitable surface to mount the VIA AMOS-3007. Drill four holes on a flat surface (wall/table). Ensure the diameter of the holes and the distance between the holes perfectly match with the mounting screws and holes of the VIA AMOS-3007.

  • Page 33: Mounting The Via Amos-3007 Behind The Monitor

    Fasten the VESA mounting plate with four screws at the back of the display. Figure 31: Installing the VESA mounting plate Step 3 Install the VIA AMOS-3007 to the VESA mounting plate and connect all necessary cables. Figure 32: Installing VIA AMOS-3007 to the VESA mounting plate...

  • Page 34: Bios Setup

    VIA AMOS-3007 User Manual 6. BIOS Setup This chapter gives a detailed explanation of the BIOS setup functions. 6.1 Entering the BIOS Setup Utility Power on the computer and press Delete during the beginning of the boot sequence to enter the BIOS Setup Utility.

  • Page 35: System Overview

    VIA AMOS-3007 User Manual 6.4 System Overview The System Overview screen is the default screen that is shown when the BIOS Setup Utility is launched and contains pertinent system information. This screen can be accessed by traversing the navigation bar to the “Main”...

  • Page 36: Advanced Settings

    VIA AMOS-3007 User Manual 6.5 Advanced Settings The Advanced Settings screen shows a list of categories that can provide access to sub-screens. Sub-screens can be selected by using the Up and Down arrows on the number pad. Aptio Setup - AMI...

  • Page 37: Cpu Configuration

    VIA AMOS-3007 User Manual 6.5.1 CPU Configuration The CPU Configuration screen shows detailed information about the built-in processor. Aptio Setup - AMI Advanced CPU Configuration Type Intel Atom(R) x6413E Processor @ 1.5GHz 0X90661 Speed 1500 MHz L1 Data Cache 32 KB x 4...

  • Page 38: S5 Rtc Wake Settings

    VIA AMOS-3007 User Manual 6.5.3 S5 RTC Wake Settings The S5 RTC Wake Settings screen provides settings to enable/disable the system to wake from S5 using the RTC alarm. Aptio Setup - AMI Advanced Wake system from S5 [Disabled] enable or disable System wake on alarm event.

  • Page 39: Sio Configuration

    VIA AMOS-3007 User Manual 6.5.5 SIO Configuration The SIO (Super IO) Configuration screen shows a list of categories that can provide access to sub-screens. Sub- screens can be selected by using the Up and Down arrows on the number pad.

  • Page 40: Serial Port Configuration

    VIA AMOS-3007 User Manual 6.5.5.1 Serial Port Configuration The Serial Port Configuration screen allows for the configuration of individual serial ports. Aptio Setup - AMI Advanced Serial Port 1 Configuration Enable or Disable this Logical Device. Use This Device [Enabled]...

  • Page 41: Wake-Up Configuration

    VIA AMOS-3007 User Manual 6.5.6 Wake-up Configuration The Wake-up Configuration screen provides options to wake the system. Aptio Setup - AMI Advanced Wake-up Configuration Wake on USB S3/S4 Wake on USB S3/S4 [Enabled] Wake on GLAN & M.2 devices [Disabled]...

  • Page 42: Realtek Pcie Gbe Family Controller

    VIA AMOS-3007 User Manual 6.5.7 Realtek PCIe GBE Family Controller The Realtek PCIe GBE Family Controller screen provides driver information and the Realtek Ethernet controller information. Aptio Setup - AMI Advanced Driver Information Driver Name: Realtek UEFI UNDI Driver Driver Version: 2.058...

  • Page 43: Chipset Settings

    VIA AMOS-3007 User Manual • Change Admin Password − Passwords must be between 8-32 characters in length and include at least one: lowercase letter, uppercase letter, a number, and a symbol. 6.6 Chipset Settings The Chipset Settings screen shows a list of categories that can provide access to a sub-screen. Sub-screens can be selected by using the Up and Down arrows on the number pad.

  • Page 44: System Agent (Sa) Configuration

    VIA AMOS-3007 User Manual 6.6.1 System Agent (SA) Configuration The System Agent (SA) Parameters screen shows support for VT-d (Virtualization for directed IO) as well as a link to the Memory Configuration settings. Aptio Setup - AMI Chipset System Agent (SA) Configuration...

  • Page 45: Pch-Io Configuration

    VIA AMOS-3007 User Manual 6.6.2 PCH-IO Configuration The PCH-IO (Platform Control Hub IO) Configuration screen shows a list of categories that can provide access to sub-screens. Sub-screens can be selected by using the Up and Down arrows on the number pad.

  • Page 46: Sata Configuration

    VIA AMOS-3007 User Manual 6.6.2.1 SATA Configuration This SATA Configuration screen shows options for configuring the SATA devices. Aptio Setup - AMI Advanced SATA Configuration Enable/Disable SATA Device. SATA Controller(s) [Enabled] SATA Mode Selection [AHCI] Serial Port 0 Empty Port 0...

  • Page 47: Hd Audio Configuration

    VIA AMOS-3007 User Manual 6.6.2.2 HD Audio Configuration This screen shows the HD Audio Configuration and allows for the HD Audio to be enabled or disabled. Aptio Setup - AMI Advanced HD Audio Subsystem Configuration Settings Control Detection of the HD-Audio device.

  • Page 48: Boot Settings

    VIA AMOS-3007 User Manual • Administrator Password/User Password − This option is for setting a password for accessing the BIOS setup utility. When a password has been set, a password prompt will be displayed whenever the BIOS setup utility is launched. This prevents an unauthorized person from changing any part of the system configuration.

  • Page 49: Save & Exit

    VIA AMOS-3007 User Manual 6.9 Save & Exit The Save & Exit Configuration screen has the following features: Aptio Setup - AMI Main Advanced Chipset Security Boot Save & Exit Save Options Exit system setup after saving Save Changes and Exit the changes.
  • Page 50 VIA AMOS-3007 User Manual Default Options • Restore Defaults − Restore/Load Default values for all the setup options. • Save as User Defaults − Save the changes done so far as User Defaults. • Restore User Defaults − Restore the User Defaults to all the setup options.

  • Page 51: Software And Technical Support

    7.1 Windows and Linux Support The VIA AMOS-3007 is fully compatible with Windows and Linux operating systems. 7.2 Technical Support and Assistance • For utility downloads, latest documentation, drivers and new information about the VIA AMOS-3007, go to http://www.viatech.com/en/systems/amos/amos-3007 •...

  • Page 52: Appendix A Installing Wireless Accessories

    Appendix A Installing Wireless Accessories This chapter provides you with information on how to install the optional VIA wireless modules into the VIA AMOS-3007. It is recommended to use a grounded wrist strap before handling computer components. Electrostatic discharge (ESD) can damage some components.

  • Page 53: Figure 54: Installing And Securing The Via Emio-8530 Module

    VIA AMOS-3007 User Manual Step 3 Remove the screw from the onboard standoff, then align the notch on the VIA EMIO-8530 module with its counterpart on the M.2_3 slot on the mainboard. Insert the module at a 30° angle and align the mounting hole on the VIA EMIO-8530 module with the mounting hole-on the standoff.

  • Page 54: Figure 56: Installing The Antennas And Connecting The Usb Wi-Fi Cables (Via Emio-8530)

    VIA AMOS-3007 User Manual Step 6 Insert the Wi-Fi antenna cables into the antenna holes (labeled as WIFI1 and WIFI2) from the inside of the front panel I/O plate. Insert the washers, fasten them with the nuts, and install the external antennas. Connect the other ends of the corresponding Wi-Fi antenna cables to the micro-RF connectors (I-PEX), labeled “1”...

  • Page 55: Inserting The Sim Card

    VIA AMOS-3007 User Manual A.2 Inserting the SIM Card Step 1 Remove the bottom plate from the VIA AMOS-3007 as described in Step 1 of section 5.1. Step 2 Firmly push back the SIM card slot to unlock the opening.

  • Page 56: Installing The Via Emio-8570 4G Lte & Gps M.2 Module Kit

    VIA AMOS-3007 User Manual A.3 Installing the VIA EMIO-8570 4G LTE & GPS M.2 Module Kit Step 1 Remove the bottom plate from the VIA AMOS-3007 as described in Step 1 of section 5.1 and the front panel I/O plate as described in Step 2 of section A.1.

  • Page 57: Figure 59: Installing Via Emio-8570 Module

    VIA AMOS-3007 User Manual Figure 59: Installing VIA EMIO-8570 module Step 4 Peel off the bottom protective (plastic) cover of VIA EMIO-8570 module thermal pad included in the package. Paste the thermal pad onto the shielding on the VIA EMIO-8570 module.

  • Page 58: Figure 62: Installing The Antennas And Connecting The Gps Antenna (Via Emio-8570)

    VIA AMOS-3007 User Manual Step 7 Insert the GPS antenna cable into the other unlabeled antenna hole from the inside of the front panel I/O plate. Insert the washer, fasten it with the nut, and install the external antenna. Connect the other end of the GPS antenna cable to the micro-RF connector (I-PEX), labeled “G”...
