USER MANUAL
VIA ARTiGO A5000
Fanless ultra-compact system with
MediaTek Genio 700 Octa-Core processor for
Edge AI applications
1.00-12092024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARTiGO A5000 and is the answer not in the manual?

Questions and answers

Summary of Contents for VIA Technologies ARTiGO A5000

  • Page 1 USER MANUAL VIA ARTiGO A5000 Fanless ultra-compact system with MediaTek Genio 700 Octa-Core processor for Edge AI applications 1.00-12092024...
  • Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
  • Page 3 VIA ARTiGO A5000 User Manual Battery Recycling and Disposal • Only use the appropriate battery specified for this product. • Do not re-use, recharge, or reheat an old battery. • Do not attempt to force open the battery. • Do not discard used batteries with regular trash.
  • Page 4 Part Number SoC Frequency Description ATG-A5000-LE08A0 MediaTek Genio 700 VIA ARTiGO A5000 system with 2.2/2.0GHz MediaTek Genio 700 Octa-Core SoC @ Octa-Core SoC, 8GB LPDDR4X DRAM, 16GB eMMC, HDMI, LVDS, 2.2GHz/2.0GHz AHD camera jack, GLAN, 2 USB 3.1, Micro USB 2.0, Audio jack,...
  • Page 5: Table Of Contents

    VIA ARTiGO A5000 User Manual Table of Contents Product Overview ............................1 Key Features ............................1 Product Specifications ........................... 1 Layout Diagram ............................. 4 Product Dimensions ..........................5 External I/O Pin Descriptions and Functionality ..................... 6 MicroSD Slot ............................6 AHD Camera Jack ..........................
  • Page 6 Figure 30: Debug system switches ........................18 Figure 31: Debug system jumpers and switches diagram .................. 19 Figure 32: Connecting the 3-pin cable between the VIA ARTiGO A5000 system and debug board ....20 Figure 33: Debug system RX/TX LEDs ......................... 20...
  • Page 7 VIA ARTiGO A5000 User Manual List of Tables Table 01: MicroSD card slot pin-outs ........................6 Table 02: LVDS port pinouts ..........................7 Table 03: Power button behavior description ..................... 7 Table 04: Micro USB 2.0 port pinouts ......................... 8 Table 05: HDMI port pinouts ..........................
  • Page 8: Product Overview

    With compact dimensions of just 118.61mm (W) x 37.6mm (H) x 82.20mm (D), the VIA ARTiGO A5000 system offers a wide variety of I/O and network connectivity options, including a MicroSD card slot, LVDS port, 2.5mm AHD camera jack, HDMI port, two USB 3.1 ports, a Micro USB 2.0 OTG port, Gigabit Ethernet port, 3.5mm...
  • Page 9 VIA ARTiGO A5000 User Manual Storage • 16GB eMMC flash memory Graphics • ARM Mali-G57 MC3 High Performance GPU • Graphics engine supporting OpenGL® ES 1.1/2.0/3.2, OpenCL ES 2.2, and Vulkan 1.0/1.1 hardware acceleration • Supports H.265 and H.264 video decoding up to 4K@75fps and video encoding up to 4K@30fps AI Processor •...
  • Page 10 VIA ARTiGO A5000 User Manual Back I/O • 1 x HDMI port • 2 x USB 3.1 ports • 1 x Micro USB 2.0 OTG port • 1 x Gigabit Ethernet port • 1 x 3.5mm headphone jack (supports Headphone-out and MIC-in) •...
  • Page 11: Layout Diagram

    VIA ARTiGO A5000 User Manual 1.3 Layout Diagram Micro SD Card Slot Figure 01: VIA ARTiGO A5000 system front panel I/O Download Button AHD Camera Jack LVDS Port Figure 02: VIA ARTiGO A5000 system right panel I/O Ethernet Reset Button...
  • Page 12: Product Dimensions

    Nano SIM card slot and UART debug connector Figure 04: VIA ARTiGO A5000 system bottom panel I/O 1.4 Product Dimensions 118.61mm 116mm Figure 05: Dimensions of the VIA ARTiGO A5000 system (back panel I/O) Figure 06: Dimensions of the VIA ARTiGO A5000 system (bottom panel I/O)
  • Page 13: External I/O Pin Descriptions And Functionality

    2.2 AHD Camera Jack The VIA ARTiGO A5000 system is equipped with a 2.5mm Analog High Definition (AHD) camera jack on the right panel, which supports AHD cameras of resolutions up to 1080P. The diagram of the AHD camera jack is shown below.
  • Page 14: Lvds Port

    2.4 LVDS Port The VIA ARTiGO A5000 system is equipped with a 40-pin LVDS port on the right panel, which supports LVDS displays and touchscreen panels of resolutions up to 1200P. The pinouts of the LVDS port are shown below.
  • Page 15: Reset Button

    2.7 Micro USB 2.0 Port The VIA ARTiGO A5000 system is equipped with a Micro USB 2.0 port on the back panel, to be used for OS image downloading. The pinouts of the Micro USB 2.0 port are shown below.
  • Page 16: Hdmi Port

    Port ® The VIA ARTiGO A5000 system is equipped with an HDMI port on the back panel, which has a Type A receptacle connector. The port allows connection to High Definition video and digital audio using a single cable. The pinouts of the HDMI port are shown below.
  • Page 17: Gigabit Lan Port

    2.11 Gigabit LAN Port The VIA ARTiGO A5000 system comes with a Gigabit LAN port on the back panel, which uses an 8 Position and 8 Contact (8P8C) receptacle connector commonly known as RJ-45, fully compliant with the IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX), and 802.3ab (1000BASE-TX) standards.
  • Page 18: Onboard Connectors

    3.1 Nano SIM Card Slot The VIA ARTiGO A5000 systems of part numbers ATG-A5000-LE48A0 and ATG-A5000-LE58A0 (for Japan only) are equipped with a Nano SIM card slot, which can be accessed by opening the cover on the bottom panel. It supports 4G LTE and 5G SIM cards.
  • Page 19: Uart Debug Connector

    3.2 UART Debug Connector The VIA ARTiGO A5000 system is equipped with a a UART debug connector, which can be accessed by opening the cover on the bottom panel. The connector's voltage level is 1.8V. The pinouts of UART debug connector are shown below.
  • Page 20: Hardware Installation

    1. Prepare a MicroSD card with the required amount of storage and ensure it is formatted with the exFAT file system. 2. Locate the MicroSD card slot on the front panel of the VIA ARTiGO A5000 system, and use a TORX® T6H Precision Screwdriver to remove the screws from the cover on the MicroSD card slot.
  • Page 21: Software And Technical Support

    VIA ARTiGO A5000 User Manual 5. Software and Technical Support 5.1 Android, Yocto and Debian Support The VIA ARTiGO A5000 system features complete software evaluation images for Android 13, Yocto 4.0, and Debian 12 operating systems. 5.2 Technical Support and Assistance •...
  • Page 22: Appendix A Optional Accessories

    2. Slide the compartment cover out to remove it. 3. Locate the Nano SIM card slot on the VIA ARTiGO A5000 system, and firmly push back to unlock it. 4. Pull up the slot and slide in the Nano SIM card, ensuring that the correct end goes in.
  • Page 23: Ahd Camera

    VIA ARTiGO A5000 User Manual A.2 AHD Camera An optional 1080P AHD camera with a plug cable is available for connecting to the VIA ARTiGO A5000 system to receive uncompressed high-quality video. Figure 23: AHD camera and plug cable Follow the instructions below to connect the AHD camera: 1.
  • Page 24: Lvds Touch Display Panel

    A.4 LVDS Touch Display Panel A 5'' 720P LVDS touch display panel with cable is available for connecting to the VIA ARTiGO A5000 system to receive high-quality display and touch input with low power consumption and heat generation. Users can tap, swipe, or use multi-touch gestures for interaction with the display.
  • Page 25: Development Kit

    ARTiGO A5000 system to a host PC for debugging. Note: Make sure that the VIA ARTiGO A5000 system is powered OFF before setting the debug board jumpers and switch, and installing the development kit. A.5.1 Debug Board Jumper and Switch Settings...
  • Page 26: Figure 31: Debug System Jumpers And Switches Diagram

    VIA ARTiGO A5000 User Manual To set the USB to UART route and UART voltage, set the debug board jumpers and switches as described below. It is recommended to use a long-nose plier or forceps for setting the jumpers and the switches.
  • Page 27: Installation

    A.5.2 Installation Follow the steps described below to connect the USB to UART debug board to the VIA ARTiGO A5000 system: 1. Locate the cover on the bottom panel of the VIA ARTiGO A5000 system, and use a Phillips Head Screwdriver #1 to remove the screw from the cover.
  • Page 28 Taiwan Headquarters Japan China 1F, 531 Zhong-zheng Road, 940 Mission Court 3-15-7 Ebisu MT Bldg. 6F, Tsinghua Science Park Bldg. 7 Xindian Dist., New Taipei City 231 Fremont, CA 94539, Higashi, Shibuya-ku No. 1 Zongguancun East Road, Taiwan Tokyo 150-0011 Haidian Dist., Beijing, 100084 Japan China...
