Wellbeing
Installation and Maintenance Instructions
AMA308L
technical data
Inlet Connection
Working Pressure Range
Operating Temperature Range
Wall Depth
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00426_29 Aug 2024
1300 369 273 | info@enware.com.au | enware.com.au
Amara Shower Mixer
®
15mm (1/2" BSP)
100 - 800 kPa
Hot and cold water inlet pressures should be balanced
0 - 85 °C
45 - 65 mm
Rev. A.1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Watts ENWARE Wellbeing Amara AMA308L
Summary of Contents for Watts ENWARE Wellbeing Amara AMA308L
- Page 1 Wellbeing Amara Shower Mixer ® Installation and Maintenance Instructions AMA308L technical data Inlet Connection 15mm (1/2” BSP) Working Pressure Range 100 - 800 kPa Hot and cold water inlet pressures should be balanced Operating Temperature Range 0 - 85 °C Wall Depth 45 - 65 mm Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
-
Page 2: Before Installation
BEFORE INSTALLATION • All supply lines must be flushed thoroughly to remove debris prior to the installation of this product, as per AS/NZS 3500.1. Strainers (40 mesh) are recommended if debris is an ongoing problem. • A pressure reduction valve may be required to comply with the recommended maximum supply pressure and/or balanced pressure requirements. -
Page 3: Installation
installation IN-WALL BODY COMPONENT 1. Secure the shower body [10] to the internal cavity within the wall. Wall depth recommended: minimum 45mm – maximum 65mm from finished wall surface. This shower mixer cannot be installed sideways, or upside down. The mixer body must be installed in the correct direction, with the shower outlet aligned in the vertical plane facing up, to ensure the handle points downwards. -
Page 4: Maintenance
maintenance CLEANING Enware products should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. Do not use cream cleaners, as they are abrasive. Use of unsuitable cleaning agents may damage the surface. -
Page 5: Troubleshooting
troubleshooting Refer to the following troubleshooting chart for specific problems and solutions. PROBLEM CAUSE RECTIFICATION Leaking from outlet. Cartridge is damaged or split. Check pressure and install a pressure reduction valve. Supply pressures too high. Replace cartridge. Cartridge retaining nut has Incorrect installation. -
Page 6: Spare Parts
spare parts DESCRIPTION PART CODE Lever Handle - Amara (Red/Blue) with AMAS-003 grub screw and handle plug Parts: [1] [3] [4] Lever Handle - Amara (Yellow/Blue) AMAS-004 with grub screw and handle plug Parts: [1] [3] [4] Handle grub screw and handle plug AMAS-005 (pack of 10) Parts: [3] [4]... - Page 7 dimensions OUTLET 1/2" BSP 90° 45 - 65 RECOMMENDED DEPTH OF BODY IN WALL FROM FINISHED WALL HOT INLET COLD INLET 1/2" BSP 1/2" BSP All measurements are in millimetres. www.enware.com.au Page 7 © Enware Pty Ltd...
-
Page 8: Product Warranty Statement
- WATTS AUSTRALIA EFFECTIVE FROM 20 November 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662...
