Installation and Maintenance Instructions
AMA306
AMA306D
technical data
Inlet Connection
Working Pressure Range
Operating Temperature Range
Flow Rate
Basin / Sink Cut Out Size
Maximum Bench Thickness
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00424_29 Aug 2024
1300 369 273 | info@enware.com.au | enware.com.au
Amara Basin Mixer
®
15mm (1/2" BSP)
100 - 800 kPa
Hot and cold water inlet pressures should be balanced
0 - 70°C
5.7 L/min Laminar (5 Star WELS) - Fitted
5.5 L/min (5 Star WELS), 3 L/min (6 Star WELS) -
Supplied in carton
34 - 37 mm diameter
55 mm (35mm with stabilising washer)
Rev. A.1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Watts ENWARE Wellbeing Amara AMA306
Summary of Contents for Watts ENWARE Wellbeing Amara AMA306
- Page 1 Wellbeing Amara Basin Mixer ® Installation and Maintenance Instructions AMA306 AMA306D technical data Inlet Connection 15mm (1/2” BSP) Working Pressure Range 100 - 800 kPa Hot and cold water inlet pressures should be balanced Operating Temperature Range 0 - 70°C Flow Rate 5.7 L/min Laminar (5 Star WELS) - Fitted 5.5 L/min (5 Star WELS), 3 L/min (6 Star WELS) -...
