Setting TributaryPDH Receive Parameters
To change receive and transmit settings so that they are no longer
coupled:
Press Menu
Button
RECEIVE
Notice that the signal status icons, in the upper-right corner of the
display, changed to indicate that the settings are no longer coupled.

Setting the Receive Level

To specify the receive level for electrical signals:
Press Menu
Button
RECEIVE
H Select Normal to set the line level to normal.
H Select Monitor to set the line level to the monitor level.
H Select Bridge to set the line level to the bridged level.

Setting the Framing

When receiving a tributary signal you can specify the framing of the
signal.
www.valuetronics.com 3–124
Select Menu Highlight
Page Parameter
RECEIVE
Tx/Rx Settings
SETTINGS
Select Menu Highlight
Page Parameter
RECEIVE Receive Level
SETTINGS
CTS 710 SONET Test Set User Manual
Select Choice
Independent
Select Choice
Normal
Monitor
Bridge
