Tektronix MSO3000 Series User Manual

Digital phosphor oscilloscopes

Hide thumbs Also See for MSO3000 Series:

Service manual (79 pages)

Technical reference (68 pages)

Instruction manual (132 pages)

Table Of Contents

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

Table of Contents

Quick Links

Download this manual

MSO3000 and DPO3000 Series

Digital Phosphor Oscilloscopes

ZZZ

User Manual

*P071265602*

071-2656-02

Table of Contents

Troubleshooting

Need help?

Do you have a question about the MSO3000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Tektronix MSO3000 Series

Page 1 MSO3000 and DPO3000 Series Digital Phosphor Oscilloscopes User Manual *P071265602* 071-2656-02...
Page 3 MSO3000 and DPO3000 Series Digital Phosphor Oscilloscopes User Manual www.tektronix.com 071-2656-02...
Page 4 Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material.
Page 5 Warranty Tektronix warrants that the product will be free from defects in materials and workmanship for a period of three (3) years from the date of original purchase from an authorized Tektronix distributor. If the product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product.
Page 6 Warranty Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product.
Page 7 Warranty Tektronix warrants that the product will be free from defects in materials and workmanship for a period of one (1) year from the date of original purchase from an authorized Tektronix distributor. If the product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product.
Page 9: Table Of Contents
Table of Contents Table of Contents General Safety Summary ......................Compliance Information ..
Page 10 Table of Contents When and Why to Turn On MagniVu ................... Using MagniVu .
Page 11 Table of Contents Capturing a Single-Shot Signal....................Correlating Data with a TLA Logic Analyzer ..
Page 12 Table of Contents MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 13: General Safety Summary
General Safety Summary General Safety Summary Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. To avoid potential hazards, use this product only as speciﬁed. Only qualiﬁed personnel should perform service procedures. To Avoid Fire or Personal Injury Use proper power cord.
Page 14 General Safety Summary Terms in This Manual These terms may appear in this manual: WARNING. Warning statements identify conditions or practices that could result in injury or loss of life. CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other property. Symbols and Terms on the Product These terms may appear on the product: DANGER indicates an injury hazard immediately accessible as you read the marking.
Page 15: Compliance Information
EN 61000-3-2:2006. AC power line harmonic emissions EN 61000-3-3:1995. Voltage changes, ﬂuctuations, and ﬂicker European Contact. Tektronix UK, Ltd. Western Peninsula Western Road Bracknell, RG12 1RF United Kingdom This product is intended for use in nonresidential areas only. Use in residential areas may cause electromagnetic interference.
Page 16 Compliance Information Australia / New Zealand Declaration of Conformity – EMC Complies with the EMC provision of the Radiocommunications Act per the following standard, in accordance with ACMA: CISPR 11:2003. Radiated and Conducted Emissions, Group 1, Class A, in accordance with EN 61326-1:2006 and EN 61326-2-1:2006.
Page 17: Safety Compliance
Compliance Information Safety Compliance EC Declaration of Conformity – Low Voltage Compliance was demonstrated to the following speciﬁcation as listed in the Ofﬁcial Journal of the European Communities: Low Voltage Directive 2006/95/EC. EN 61010-1: 2001. Safety requirements for electrical equipment for measurement control and laboratory use. U.S.
Page 18 Compliance Information Pollution Degree Pollution Degree 2 (as deﬁned in IEC 61010-1). Note: Rated for indoor use only. Installation (Overvoltage) Category Descriptions Terminals on this product may have different installation (overvoltage) category designations. The installation categories are: Measurement Category IV. For measurements performed at the source of low-voltage installation. Measurement Category III.
Page 19: Environmental Considerations
This symbol indicates that this product complies with the applicable European Union requirements according to Directives 2002/96/EC and 2006/66/EC on waste electrical and electronic equipment (WEEE) and batteries. For information about recycling options, check the Support/Service section of the Tektronix Web site (www.tektronix.com).
Page 20: Preface
Preface Preface This manual describes the installation and operation of the following oscilloscopes: MSO3054 MSO3034 MSO3032 MSO3014 MSO3012 DPO3054 DPO3052 DPO3034 DPO3032 DPO3014 DPO3012 MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 21: Key Features
Built-in Ethernet port USB 2.0 device port for direct PC control of the oscilloscope using USBTMC protocol OpenChoice documentation and analysis software NI LabVIEW SignalExpress™ Tektronix Edition productivity and analysis software Remote viewing and control with e*Scope Remote control with VISA connectivity...
Page 22: Conventions Used In This Manual
Preface Conventions Used in This Manual The following icons are used throughout this manual. Network Sequence Step front-panel power Connect power MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 23: Installation
Before Installation Unpack the oscilloscope and check that you received all items listed as standard accessories. The following pages list recommended accessories and probes, instrument options, and upgrades. Check the Tektronix Web site (www.tektronix.com) for the most current information. Standard Accessories...
Page 24 No power cord or AC adapter (Option A99) Accessories Pouch Pouch that attaches to the handle for carrying 016-2008-00 probes and other accessories For MSO3000 series: Digital probe One, 16-channel digital probe P6316 MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 25 Installation Optional Accessories Tektronix part Accessory Description number Aerospace serial triggering and analysis This module enables triggering on DPO3AERO application module MIL-STD-1553 serial buses. Also, it provides digital views of the signal, bus views, bus decoding, search tools, and decode tables with time stamp information.
Page 26 Security Instructions DPO3000 oscilloscopes The MSO3000 and DPO3000 Series oscilloscopes work with multiple optional probes. (See page 8, Connecting Probes.) Check the Tektronix Web site (www.tektronix.com) for the most current information. Related Documentation MSO3000 and DPO3000 Series Describes commands for remote control of the...
Page 27: Operating Considerations
Height, including feet but not handle: 203.2 mm (8 in) Width, 416.6 mm (16.4 in) Depth, 147.4 mm (5.8 in) MSO3000 series Clearance: 51 mm (2 in) Temperature: Operating: 0 °C to +50 °C (+32 °F to +122 °F) Nonoperating: -40 °C to +71 °C (-40 °F to +160 °F)
Page 28 Total Probe Power: If the total probe power requirements exceed the available power from the oscilloscope, connect the external AC adapter (Tektronix part number 119-7465-XX) to the rear-panel Probe Power connector. Maximum Probe Power Available Per Channel (3 or 5 TekVPI Interfaces): 5 V ±...
Page 29 Installation Input resistance: 101 KΩ Input capacitance: 8.0 pF typical Temperature: Operating: 0 °C to +50 °C (+32 °F to +122 °F) Nonoperating: -40 °C to +71 °C (-40 °F to +160 °F) Altitude: Operating: 3,000 m (9,843 ft) maximum Nonoperating: 12,000 m (39,370 ft) maximum Pollution Degree: 2, Indoor use only Humidity:...
Page 30: Connecting Probes
Some only pass the signal and there is no other communication. 5. Digital Probe Interface (MSO3000 Series only) The P6316 probe provides 16 channels of digital (on or off state) information.
Page 31: Securing The Oscilloscope
Installation Securing the Oscilloscope 1. Use a standard laptop computer style security lock to secure your oscilloscope to your location. Powering On the Oscilloscope Ground the Oscilloscope and Yourself Before pushing the power switch, connect the oscilloscope to an electrically neutral reference point, such as earth ground. Do this by plugging the three-pronged power cord into an outlet grounded to earth ground.
Page 32: Powering Off The Oscilloscope
Installation To connect the power cord and power on the oscilloscope: Powering Off the Oscilloscope To power off the oscilloscope and remove the power cord: Functional Check Perform this quick functional check to verify that your oscilloscope is operating correctly. 1.
Page 33 Installation 2. Power on the oscilloscope. 3. Connect the probe connector to oscilloscope channel 1 and the probe tip and reference lead to the PROBE COMP terminals on the oscilloscope front-panel. 4. Push Default Setup. 5. Push Autoset. The screen should now display a square wave, approximately 2.5 V at 1 kHz.
Page 34: Compensating A Passive Voltage Probe
Installation Compensating a Passive Voltage Probe Whenever you attach a passive voltage probe for the ﬁrst time to any input channel, compensate the probe to match it to the corresponding oscilloscope input channel. To properly compensate your passive probe: 1. Follow the steps for the functional check.
Page 35: Installing An Application Module
Installation Installing an Application Module CAUTION. To avoid damage to the oscilloscope or application module, observe ESD (electrostatic discharge) precautions. (See page 9, Powering On the Oscilloscope.) Turn off the oscilloscope power while removing or adding an application module. (See page 10, Powering Off the Oscilloscope.) Optional application module packages extend the capability of your oscilloscope.
Page 36 If the serial number of your instrument starts with C01, you will need to send your instrument to a Tektronix service center to enable the bandwidth upgrade. Arrangements for the service upgrade are made at the time an order is placed.
Page 37: Changing The User Interface Language
Installation 6. Push Install Option. Install Option 7. Enter the Option Key number using Enter Character multipurpose knob a and push Enter Character on the lower menu. Alternatively, you may use a USB keyboard. 8. Push OK Accept on the side menu. Accept Following a successful installation of the option key, a message will be displayed...
Page 38: Changing The Date And Time
Installation 4. Push Language from the resulting lower Utility Language Set Date & TekSecure About Manage Page Modules & Time English menu. Erase Options Conﬁg Memory 5. Turn multipurpose knob a and select the desired language. Choose among: English, French, German, Italian, Spanish, Brazilian Portuguese, Russian, Japanese, Korean, Simpliﬁed Chinese, and Traditional Chinese.
Page 39: Changing The Font Appearance
Installation 3. Turn multipurpose knob a and select Conﬁg. Conﬁg 4. Push Set Date & Time. Utility Language About Manage Set Date & TekSecure Page Time Modules & English Erase Options Conﬁg Memory 5. Push the side menu buttons and turn both Set Date &...
Page 40 Installation 2. Push Utility Page. Utility Page 3. Turn multipurpose knob a and select Utility Page Display. Display 4. Push Font. Utility Backlight Graticule Screen Trigger Font Page Intensity Annotation Frequency Full Readout Display High 5. On the side menu, push Regular or Bold. Font Regular Bold...
Page 41: Signal Path Compensation
Installation Signal Path Compensation Signal Path Compensation (SPC) corrects for DC inaccuracies caused by temperature variations and/or long-term drift. Run the compensation whenever the ambient temperature has changed by more than 10 °C (18 °F) or once a week if you use vertical settings of 5 mV/division or less. Failure to do so may result in the instrument not meeting warranted performance levels at those volts/div settings.
Page 42: Upgrading Firmware
Service personnel use the factory calibration functions to calibrate the internal voltage references of the oscilloscope using external sources. Refer to your Tektronix ﬁeld ofﬁce or representative for assistance with factory calibration. NOTE. Signal Path Compensation does not include calibration to the probe tip. (See page 12, Compensating a Passive Voltage Probe.)
Page 43 Installation 2. Power off your oscilloscope. 3. Insert the USB ﬂash drive into the front-panel USB port on your oscilloscope. MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 44 Installation 4. Power on the oscilloscope. The instrument automatically recognizes the replacement ﬁrmware and installs it. If the instrument does not install the ﬁrmware, rerun the procedure. If the problem continues, try a different model of USB ﬂash drive. Finally, if needed, contact qualiﬁed service personnel.
Page 45 Installation 6. Power on the oscilloscope. 7. Push Utility. 8. Push Utility Page. Utility Page 9. Turn multipurpose knob a and select Conﬁg. Conﬁg 10. Push About. The oscilloscope displays the Utility Language Set Date & TekSecure About Manage Page Time Modules &...
Page 46: Connecting Your Oscilloscope To A Computer
1. Load the VISA drivers on your computer. You will ﬁnd the drivers on the appropriate CD that comes with your oscilloscope or at the Tektronix software ﬁnder Web page (www.tektronix.com/software). 2. Connect the oscilloscope to your computer with the appropriate USB or Ethernet cable.
Page 47 Installation 3. Push Utility. 4. Push Utility Page. Utility Page 5. Turn multipurpose knob a and select I/O. 6. If you are using USB, the system sets itself Utility Ethernet Socket GPIB Page Network Server up automatically for you, if USB is enabled. Computer Settings Check USB on the lower menu to be sure...
Page 48 Installation 10. Run your application software on your computer. Quick Tips The CD that is shipped with your oscilloscope includes a variety of Windows-based software tools designed to ensure efﬁcient connectivity between your oscilloscope and your computer. There are toolbars that speed connectivity with Microsoft Excel and Word.
Page 49 Installation 3. Push Utility Page. Utility Page 4. Turn multipurpose knob a and select I/O. 5. Push Ethernet Network Settings. Utility Ethernet Socket GPIB Page Network Server Computer Settings 6. On the side menu, if you are on a DHCP Change Instrument Ethernet network and using dynamic...
Page 50: Connecting A Usb Keyboard To Your Oscilloscope
Installation 8. You should now see the e*Scope screen showing the oscilloscope display, on your Web browser. If e*Scope does not work, rerun the procedure. If it still does not work, contact qualiﬁed service personnel. Connecting a USB Keyboard to Your Oscilloscope You can connect a US-style USB keyboard to a USB Host port on the rear or front-panel of the oscilloscope.
Page 51: Get Acquainted With The Instrument
Get Acquainted with the Instrument Get Acquainted with the Instrument Front-Panel Menus and Controls The front-panel has buttons and controls for the functions that you use most often. Use the menu buttons to access more specialized functions. Using the Menu System To use the menu system: 1.
Page 52 Get Acquainted with the Instrument 3. Push a side menu button to select an item. If the menu item contains more than one choice, push the side menu button repeatedly to cycle through the choices. If a pop-out menu appears, turn multipurpose knob a to select the desired choice.
Page 53 Get Acquainted with the Instrument 5. Certain menu choices require you to set a numeric value to complete the setup. Use the upper and lower multipurpose knobs a and b to adjust values. 6. Push Fine to turn off or on the ability to make smaller adjustments.
Page 54 Get Acquainted with the Instrument 8. Save / Recall Menu. Push to save and recall setups, waveforms, and screen images to internal memory or a USB ﬂash drive. 9. Channel 1,2,3, or 4 Menu. Push to set vertical parameters for input waveforms and to display or remove the corresponding waveform from the display.
Page 55 Get Acquainted with the Instrument 1. Turn the upper multipurpose knob a, when activated, to move a cursor, to set a numerical parameter value for a menu item, or to select from a pop-out list of choices. Push Fine to toggle between coarse and ﬁne adjustment.
Page 56 Get Acquainted with the Instrument 7. Zoom button. Push to activate zoom mode. 8. Pan (outer knob). Turn to scroll the zoom window through the acquired waveform. 9. Zoom (inner knob). Turn to control the zoom factor. Turning it clockwise zooms in further.
Page 57 Get Acquainted with the Instrument 16. Run/Stop. Push to start or stop acquisitions. 17. Single. Push to make a single acquisition. 18. Autoset. Push to automatically set the vertical, horizontal, and trigger controls for a usable, stable display. 19. Trigger Level. Turn to adjust the trigger level.
Page 58 29. D15 - D0. Push to display or remove the digital channels from the display, and to access the digital channel setup menu (MSO3000 Series only). MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 59 Get Acquainted with the Instrument 30. Menu Off. Push to clear a displayed menu from the screen. Identifying Items in the Display The items shown to the right may appear in the display. Not all of these items are visible at any given time.
Page 60 Get Acquainted with the Instrument 2. The trigger position icon shows the trigger position in the acquisition. 3. The expansion point icon (an orange triangle) shows the point that the horizontal scale expands and compresses around. To make the expansion point the same as the trigger point, push Acquire and set the lower menu Delay item to Off.
Page 61 Get Acquainted with the Instrument 7. The trigger level icon shows the trigger level on the waveform. The icon color corresponds to the trigger source color. 8. The trigger readout shows the trigger source, slope, and level. The trigger readouts for other trigger types show other parameters.
Page 62 (ignoring the effect of offset). The icon colors correspond to the waveform colors. 16. For digital channels (MSO3000 Series only), the baseline indicators point to the high and low levels. The indicator colors match the color code used on the physical probe channels.
Page 63: Front-Panel Connectors
Get Acquainted with the Instrument 17. The group icon indicates when digital channels are grouped (MSO3000 Series only). 18. The bus display shows decoded packet level information for serial buses or for parallel buses (MSO3000 Series only). The bus indicator shows the bus number and bus type.
Page 64: Side Panel Connector
Get Acquainted with the Instrument Side Panel Connector 1. Ground strap connector. This is a receptacle for a grounding strap. Rear-Panel Connectors 1. Cal. This is for use by authorized service personnel only. 2. Aux Out. Use this output to synchronize other test equipment with your oscilloscope.
Page 65 Get Acquainted with the Instrument 6. Device. Use the USB 2.0 High speed device port to control the oscilloscope through USBTMC or GPIB with a TEK-USB-488 Adapter. The USBTMC protocol allows USB devices to communicate using IEEE488 style messages. This lets you run your GPIB software applications on USB hardware.
Page 66: Acquire The Signal
Acquire the Signal Acquire the Signal This section describes concepts of and procedures for setting up the oscilloscope to acquire the signal as you want it to. Setting Up Analog Channels Use front-panel buttons and knobs to set up your instrument to acquire signals using the analog channels. 1.
Page 67 Acquire the Signal 5. Push the desired channel button. Then adjust the vertical position and scale. 6. Adjust the horizontal position and scale. The horizontal position determines the number of pretrigger and posttrigger samples. The horizontal scale determines the size of the acquisition window relative to the waveform.
Page 68 Acquire the Signal 2. Push Label on the lower menu to create a Label label, such as for channel 1 or B1. 3. Push Select Preset Label to view a list of Select Preset labels. Label 4. Turn multipurpose knob b to scroll through the list to ﬁnd a suitable label.
Page 69: Using The Default Setup
Acquire the Signal 7. Turn multipurpose knob a to scroll through the list of letters, numbers, and other characters to ﬁnd the character in the name that you want to enter. ABCDEFGHIJKLMNOPQRSTUVWXYZ abcdefghijklmnopqrstuvwxyz 0123456789_=+-!@#$%^&*()[]{}<>/~'”\|:,.? 8. Push Select or Enter Character to let the oscilloscope know that you have picked the proper character to use.
Page 70: Using Autoset
Acquire the Signal 2. If you change your mind, push Undo Undo Default Default Setup to undo the last default Setup setup. Using Autoset Autoset adjusts the instrument (acquisition, horizontal, trigger, and vertical controls) such that it displays four or ﬁve waveform cycles for analog channels with the trigger near the midlevel, and ten cycles for digital channels.
Page 71: Acquisition Concepts
Acquire the Signal 3. Release Menu Off, and then release Autoset. 4. Select the desired side menu setting. Autoset Enabled Autoset Disabled Quick Tips To position the waveform appropriately, Autoset may change the vertical position. Autoset always sets vertical offset to 0 V.
Page 72: How The Analog Acquisition Modes Work
Acquire the Signal Waveform Record The instrument builds the waveform record through use of the following parameters: Sample interval: The time between recorded sample points. Adjust this by turning the Horizontal Scale knob or changing the record length with the menu buttons.
Page 73: Changing The Acquisition Mode, Record Length, And Delay Time
Acquire the Signal Hi Res mode calculates the average of all the samples for each acquisition interval. This mode only works with real-time, noninterpolated sampling. Hi-Res provides a higher-resolution, lower bandwidth waveform. Envelope mode ﬁnds the highest and lowest record points over all acquisitions. Envelope uses Peak Detect for each individual acquisition.
Page 74 Acquire the Signal 3. Then choose the acquisition mode on the Acquisition Mode side menu. You can chose from: Sample, Peak Detect, Hi Res, Envelope, or Average. Sample NOTE. Peak Detect and Hi Res modes take advantage of sample points that the oscilloscope would have discarded at lower Peak sweep speeds.
Page 75: Using Roll Mode
Acquire the Signal 7. Push Delay on the lower menu to select On when you want to delay the acquisition relative to the trigger event. With Delay set to On, turn the Horizontal Position knob counterclockwise to increase the delay. The trigger point will move to the left and ultimately outside of the acquired waveform.
Page 76: Setting Up A Serial Or Parallel Bus
Acquire the Signal Setting Up a Serial or Parallel Bus Your oscilloscope can decode and trigger on signal events or conditions that occur on: Bus type With this setup Parallel MSO3000 oscilloscope C and SPI DPO3EMBD application module. MSO3000 or DPO3000 oscilloscope RS-232, RS-422, RS-485, and DPO3COMP application module.
Page 77 Inputs Display Table Parallel scroll through the list of bus types and select the desired bus: Parallel (MSO3000 Series only), I C, SPI, RS-232, MIL-STD-1553, CAN, LIN, FlexRay, or Audio. The actual menu items shown will depend on your model oscilloscope and the application modules installed.
Page 78 Acquire the Signal Alternately, you can set the threshold to a speciﬁc value for the signals that make up the serial bus. To do so, push Select on the side menu and turn multipurpose knob a to select a Bit or a Channel number (Signal name). Then, turn multipurpose knob b to deﬁne the voltage level above which the oscilloscope treats the signal as a logic high and below...
Page 79 Acquire the Signal 7. Push Event Table and select On to display a Event Table list of bus packets with timestamps. |Off Save Event Table For a clocked parallel bus, the table lists the value of the bus at each clock edge. For an unclocked parallel bus, the table lists the value of the bus whenever any one of its bits changes.
Page 80 Acquire the Signal 9. Push B1 or B2 and turn multipurpose knob a to move the bus display up or down on the screen. C Bus To acquire data from an I C bus, you need to also set up these items: 1.
Page 81 Acquire the Signal 3. Push SCLK to set the edge of the signal to SCLK match the SPI bus being acquired. 4. Set the level of the SS, MOSI, and MISO Active signals to match the SPI bus. High Active Low Active High means that a signal is considered MOSI active when the signal is greater than the...
Page 82 Acquire the Signal 2. Push Bit Rate, and turn multipurpose knob a Bit Rate 9600 bps to select the appropriate bit rate. 3. Push Data Bits and select the number to Data Bits match the bus. 4. Push Parity and turn multipurpose knob a to Parity (a) None match the polarity used by the bus as None,...
Page 83 Acquire the Signal 3. Push either Polarity Normal or Polarity Inverted on the size menu to match the bus being acquired. 4. Push Thresholds to set the Channel Thresh- olds Thresholds or choose a Preset value. 752mV Turn multipurpose knob a to set the high 22.0mV threshold level.
Page 84 Acquire the Signal 5. Push Bit Rate and turn multipurpose knob a Deﬁne Thresholds Bit Rate B1 Label Event Display Table Inputs 500 Kbps to select from the list of predeﬁned bit rates. Alternately, you can set the bit rate to a speciﬁc value.
Page 85 Acquire the Signal 6. Push Bit Rate, and turn multipurpose knob a Bit Rate to select from the list of predeﬁned bit rates. 19.2K bps Alternately, you can set the bit rate to a speciﬁc value. To do so, select Custom, and then turn multipurpose knob b to set the bit rate from 800 bps to 100,000 bps.
Page 86 Acquire the Signal 5. Push Bit Rate and turn multipurpose knob a Deﬁne Thresholds Bit Rate B1 Label Event FlexRay Display Table Inputs FlexRay 786mV 1000000 to select from the list of predeﬁned bit rates. 22.00 V Alternately, you can set the bit rate to a speciﬁc value.
Page 87 Acquire the Signal 2. Push Type, and turn multipurpose knob Audio Bus Type a to select the type of audio bus data conﬁguration on which to trigger. 3. Select I2S to trigger on the standard Inter-IC Sound, or Integrated Interchip Sound, electrical serial bus interface standard stereo format.
Page 88: Setting Up Digital Channels
Acquire the Signal Setting Up Digital Channels Use front-panel buttons and knobs to set up your instrument to acquire signals using the digital channels. 1. Connect the P6316 16-channel digital probe to the input signal source. 2. Connect the ground lead or leads to the circuit ground.
Page 89 Acquire the Signal 7. Turn multipurpose knob a to scroll through the list of digital channels. Turn multipurpose knob b to position the selected channel. As you position channels close to each other on the display, the oscilloscope groups the channels, and adds the group to the pop-up list.
Page 90: When And Why To Turn On Magnivu
When and Why to Turn On MagniVu For MSO3000 Series only, MagniVu allows you to have higher resolution to accurately determine edge placement. This helps you to make precise timing measurements on digital edges. You can see up to 16 times more detail than with normal digital channel sampling.
Page 91 Acquire the Signal 2. Push MagniVu and select On. D15 – D0 Thresholds Label MagniVu Height On/Off |Off | M L Quick Tips If you think you need more timing resolution, turn on MagniVu to increase the resolution. MagniVu is always acquired. If the oscilloscope is in a stopped state, you can turn on MagniVu and still get the resolution without taking another acquisition.
Page 92: Trigger Setup
Trigger Setup Trigger Setup This section contains concepts and procedures for setting up the oscilloscope to trigger on your signal. Triggering Concepts Trigger Event The trigger event establishes the time-reference point in the waveform record. All waveform record data is located in time with respect to that point.
Page 93 Trigger Setup Trigger Holdoff Adjust holdoff to obtain stable triggering when the instrument is triggering on undesired trigger events. Trigger holdoff can help stabilize triggering, since the oscilloscope does not recognize new triggers during the holdoff time. When the instrument recognizes a trigger event, it disables the trigger system until acquisition is complete.
Page 94 Trigger Setup 1. Adjust the position (delay) time by rotating the Horizontal Position knob. 2. Turn horizontal SCALE to acquire the detail that you need around the position (delay) expansion point. The part of the record that occurs before the trigger is the pretrigger portion. The part that occurs after the trigger is the posttrigger portion.
Page 95: Choosing A Trigger Type
2. Push Type to bring up the Trigger Type Trigger Type side menu. Sequence NOTE. The bus trigger in the MSO3000 Series (B Trigger) works on parallel buses even without an Pulse application module. Using the bus trigger on Width...
Page 96: Selecting Triggers
Trigger Setup Selecting Triggers Trigger Type Trigger Conditions Edge Trigger on a rising or falling edge, as deﬁned by the slope control. Coupling choices are DC, AC, LF Reject, HF Reject, and Noise Reject. Edge triggers are the simplest and most commonly used trigger type, with both analog and digital signals.
Page 97 You can use up to 20 channels for a Setup and Hold trigger (4 analog and 16 digital) with MSO3000 Series oscilloscopes. Use Clock on the side menu to select the clock channel.
Page 98: Triggering On Buses
S, Left Justiﬁed (LJ), Right Justiﬁed (RJ), and TDM buses, if you have the appropriate DPO3AERO, DPO3AUDIO, DPO3AUTO, DPO3COMP, DPO3EMBD, or DPO3FLEX application module installed. The MSO3000 Series can trigger on parallel buses without an application module. The oscilloscope can display both physical layer (as analog waveforms) and protocol level information (as symbolic waveforms).
Page 99 Trigger Setup 3. Push Type. Type Source Trigger On Address Direction Mode Write Auto Address B1 (I2C) & Holdoff 4. Turn multipurpose knob a to scroll through the trigger type side menu until you select Bus. 5. Push Source Bus and turn multipurpose B1 (I2C) knob a to scroll through the source bus side B2 (CAN)
Page 100 Trigger Setup Then push Number of Bytes and enter the number of bytes using multipurpose knob a. If you select MOSI & MISO, push Data on the lower menu and enter the parameters of interest on the side menus. RS-232 Bus Trigger If you are using the RS-232 bus trigger, you can trigger on Tx Start Bit, Rx Start Bit, Tx End of Packet, Rx End of Packet,Tx Data, or Rx Data.
Page 101 Trigger Setup LIN Bus Trigger If you are using the LIN bus trigger, you can trigger on Sync, Identiﬁer, Data, Id & Data,Wakeup Frame, Sleep Frame, or Error. If you are setting up an LIN trigger and have made a Trigger On selection of Identiﬁer, Data, or Identiﬁer & Data, push Identiﬁer or Data on the lower menu and enter the parameters of interest on the resulting side menu.
Page 102 You can also trigger on a speciﬁc data value for other buses. Parallel Bus Trigger Data Matching Optimum parallel bus trigger performance is achieved by using only analog channels or only digital channels (MSO3000 Series only). MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 103: Checking Trigger Settings
Trigger Setup Checking Trigger Settings To quickly determine the settings of some key trigger parameters, check the Trigger readout at the bottom of the display. The readouts differ for edge and the advanced triggers. 1. Trigger source = channel 1. Edge trigger readout 2.
Page 104 Trigger Setup Push a side menu button to select Time (a) 8 ns sequencing the B trigger after the A as Time or as Events. B Events Set to Minimum 5. Set the other Sequence Trigger parameters on the related side and lower menus. B Trigger After Delay Time The A trigger arms the instrument.
Page 105: Starting And Stopping An Acquisition
Trigger Setup Starting and Stopping an Acquisition After you have deﬁned the acquisition and trigger parameters, start the acquisition with Run/Stop or Single. Push Run/Stop to start acquisitions. The oscilloscope acquires repeatedly until you push the button again to stop the acquisition.
Page 106: Display Waveform Data
Display Waveform Data Display Waveform Data This section contains concepts and procedures for displaying the acquired waveform. Adding and Removing a Waveform 1. To add or remove a waveform from the display, push the corresponding front-panel channel button or the D15-D0 button.
Page 107 Display Waveform Data 3. Push Dots Only on the side menu. Dots on Waveform Display will display the waveform record points as dots on the screen. Dots off connects the dots with vectors. Dots Only |Off 4. Push Persist Time, and turn multipurpose Persist Time knob a to have waveform data remain on...
Page 108 Display Waveform Data 2. Push Utility Page. Utility Page 3. Turn multipurpose knob a and select Display Display. 4. Push Graticule on the lower menu. Utility Backlight Graticule Screen Trigger Page Intensity Annotation Frequency Full Readout Display High MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 109 Display Waveform Data 5. Select the desired style on the resulting side menu. The Frame graticule provides a clean screen on which you can most easily read automatic measurement results and other screen text. The Full graticule can help you make cursor measurements on hard copies.
Page 110: Setting Waveform Intensity
Display Waveform Data 4. Push Backlight Intensity. Utility Backlight Graticule Screen Page Intensity Annotation Full Display High 5. Select the intensity level on the resulting Backlight Intensity side menu. Choices are: High, Medium, and Low. High Medium Setting Waveform Intensity 1.
Page 111: Scaling And Positioning A Waveform
Display Waveform Data Scaling and Positioning a Waveform Use the horizontal controls to adjust the time base, adjust the trigger point, and to examine waveform details more closely. You can also use the Wave Inspector Pan and Zoom controls to adjust the display of waveforms. (See page 118, Using Wave Inspector to Manage Long Record Length Waveforms.) Original waveform Scaled horizontally...
Page 112: Setting Input Parameters
Display Waveform Data Quick Tips Preview. If you change the Position or Scale controls when the acquisition is stopped or when it is waiting for the next trigger, the oscilloscope rescales and repositions the relevant waveforms in response to the new control settings. It simulates what you will see when you next push RUN.
Page 113 Display Waveform Data 5. Push Bandwidth, and select the desired bandwidth on the resulting side menu. The set choices are: Full and 20 MHz. Additional choices may appear, depending on the probe that you use. Select Full to set the bandwidth to the full oscilloscope bandwidth.
Page 114 This is especially important when using a current probe in conjunction with a voltage probe. For best results, use a deskew ﬁxture, such as the Tektronix 067-1686-xx. MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 115 Display Waveform Data If you do not have a deskew ﬁxture, you can use the controls in the Deskew menu to set the oscilloscope's deskew parameters to recommended values, based on the normal propagation delay of each probe. The oscilloscope automatically loads the nominal propagation delay values of TekVPI and TekProbe II (requires use of a TPA-BNC adapter) probes.
Page 116: Positioning And Labeling Bus Signals
Display Waveform Data Positioning and Labeling Bus Signals Positioning bus signals. Push the appropriate front-panel bus button and turn multipurpose knob a to adjust the vertical position of the selected bus. (See page 54, Setting Up a Serial or Parallel Bus.) 1.
Page 117: Positioning, Scaling, And Grouping Digital Channels
Display Waveform Data Labeling bus signals. To label a bus, do the following steps: 1. Push the appropriate front-panel bus button. 2. Push Label. Bus (B1) Deﬁne Thresholds Include (B1) Label Event Inputs R/W in Display Table (See page 45, Labeling Channels and Buses.) address Positioning, Scaling, and Grouping Digital Channels 1.
Page 118 Display Waveform Data 4. Turn multipurpose knob a to select the channel to move. 5. Turn multipurpose knob b to move the selected channel. NOTE. The display of the channel (or group) only moves after you stop rotating the knob. 6.
Page 119: Viewing Digital Channels
Display Waveform Data Viewing Digital Channels The various ways of displaying data from the digital channels help you analyze the signals. Digital channels store a high or low state for each sample. Logic high levels are displayed in green. Logic low levels are displayed in blue. When a single transition occurs during the time represented by one pixel column, the transition (edge) is displayed in gray.
Page 120: Viewing The Trigger Frequency
Display Waveform Data 3. Turn multipurpose knob a and select Display Display. 4. Push Screen Annotation on the resulting Utility Backlight Graticule Screen Page Intensity Annotation lower menu. Full Display High 5. Push Display Annotation to select On on the side menu. The annotation window now appears.
Page 121 Display Waveform Data 3. Turn multipurpose knob a and select Display Display. 4. Push Trigger Frequency Readout from the Utility Backlight Graticule Screen Trigger Page Intensity Annotation Frequency resulting lower menu. Full Readout Display High 5. Push On on the side menu. The trigger frequency now appears in the Trigger readout, towards the lower right of the display.
Page 122: Analyze Waveform Data
Analyze Waveform Data Analyze Waveform Data After having properly set up the acquisition, triggering, and display of your desired waveform, you can then analyze the results. Select from features such as cursors, automatic measurements, statistics, math, and FFT. Taking Automatic Measurements To take an automatic measurement: 1.
Page 123: Selecting Automatic Measurements
Analyze Waveform Data Selecting Automatic Measurements The following tables list each automatic measurement by category: time or amplitude. (See page 100, Taking Automatic Measurements.) Time Measurements Measurement Description Period The time required to complete the ﬁrst cycle in a waveform or gated region. Period is the reciprocal of frequency and is measured in seconds.
Page 124 Analyze Waveform Data Amplitude Measurements Measurement Description Positive This is measured over the entire waveform or gated region and is expressed as: Overshoot Positive Overshoot = (Maximum – High) / Amplitude x 100%. Negative This is measured over the entire waveform or gated region and is expressed as: Overshoot Negative Overshoot = (Low –...
Page 125 Analyze Waveform Data Amplitude Measurements (cont.) Measurement Description The true Root Mean Square voltage over the entire waveform or gated region. Cycle RMS The true Root Mean Square voltage over the ﬁrst cycle in the waveform or the ﬁrst cycle in the gated region. Miscellaneous Measurements Measurement Description...
Page 126: Customizing An Automatic Measurement
Analyze Waveform Data Customizing an Automatic Measurement You can customize automatic measurements by using gating, modifying measurement statistics, adjusting the measurement reference levels, or taking a snapshot. Gating Gating conﬁnes the measurement to a certain portion of a waveform. To use: 1.
Page 127 Analyze Waveform Data Statistics Statistics characterize the stability of measurements. To adjust statistics: 1. Push Measure. 2. Push More as many times as needed to Add Mea- Remove Indicators Bring surement Measure- Cursors select Statistics from the resulting pop-up More ment On Screen menu.
Page 128 Analyze Waveform Data 3. Turn multipurpose knob a to select the desired Source channel. 4. Turn multipurpose knob b to select the Measurement Type of Snapshot. 5. Push OK Snapshot All Measurements. Snapshot All Mea- surements MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 129 Analyze Waveform Data 6. View results. Snapshot on 1 Period : 312.2μs Freq : 3.203kHz +Width : 103.7μs –Width : 208.5μs Burst W : 936.5μs Rise : 1.452μs Fall : 1.144μs +Duty : 33.23% –Duty : 66.77 % +Over : 7.143% –Over : 7.143 % High...
Page 130: Taking Manual Measurements With Cursors
Analyze Waveform Data 3. Set the levels using the side menu. Reference Levels Set Levels |Units Use High and Low reference to calculate High Ref (a) 90.0 % rise and fall times. Use Mid reference primarily for Mid Ref 50.0 % measurements between edges, such 50.0 % as pulse widths.
Page 131 Analyze Waveform Data 2. With cursors on, push Select. This turns the cursor linking on and off. If linking is on, turning multipurpose knob a moves the two cursors together. Turning multipurpose knob b adjusts the time between the cursors. 3.
Page 132 Analyze Waveform Data 8. View the cursor and the cursor readout. NOTE. On digital channels, you can take timing measurements with cursors, but not amplitude measurements. 9. Display multiple waveforms on the screen by pushing one or more of the channel 1 through 4 buttons or, if you are using an MSO3000B, by pushing D15 –...
Page 133 Analyze Waveform Data 14. Turn multipurpose knob a and take cursor measurements on the alternate waveform. Using Cursor Readouts Cursor readouts supply textual and numeric information relating to the current cursor positions. Readouts appear in the upper right corner of the graticule. If Zoom is on, the readout appears in the upper right corner of the zoom window.
Page 134: Using Math Waveforms
Analyze Waveform Data Using Math Waveforms Create math waveforms to support the analysis of your channel and reference waveforms. By combining and transforming source waveforms and other data into math waveforms, you can derive the data view that your application requires. NOTE.
Page 135: Using Fft
Analyze Waveform Data Using FFT An FFT breaks down signals into component frequencies, which the oscilloscope uses to display a graph of the frequency domain of a signal, as opposed to the oscilloscope's standard time domain graph. You can match these frequencies with known system frequencies, such as system clocks, oscillators, or power supplies.
Page 136 Analyze Waveform Data 7. The FFT will appear on the display. Quick Tips Use short record lengths for faster instrument response. Use long record lengths to lower the noise relative to the signal and increase the frequency resolution. If desired, use the zoom feature along with the horizontal Position and Scale controls to magnify and position the FFT waveform.
Page 137: Using Advanced Math
Analyze Waveform Data Description Window Hanning This is a very good window for measuring amplitude accuracy but less so for resolving frequencies. Use Hanning for measuring sine, periodic, and narrow band random noise. This window works on transients or bursts where the signal levels before and after the event are signiﬁcantly different.
Page 138: Using Reference Waveforms
Analyze Waveform Data For example, to use Edit Expression to take the integral of a square wave: 1. Push Clear on the lower menu. 2. Turn multipurpose knob a to select Intg(. 3. Push Enter Selection. 4. Turn multipurpose knob a to select channel 1.
Page 139 Analyze Waveform Data 3. Use the side menu and the multipurpose knobs to adjust the vertical and horizontal settings of the reference waveform. Vertical 0.00 div 100 mV/div Horizontal 0.00 s 4.00 μs/div Quick Tips Selecting and Displaying Reference Waveforms. You can display all the reference waveforms at the same time. Push the appropriate screen button to select a particular reference waveform.
Page 140: Using Wave Inspector To Manage Long Record Length Waveforms
Analyze Waveform Data Using Wave Inspector to Manage Long Record Length Waveforms The Wave Inspector controls (zoom/pan, play/pause, marks, search) help you to efﬁciently work with long record length waveforms. To magnify a waveform horizontally, turn the Zoom knob. To scroll through a zoomed waveform, turn the Pan knob.
Page 141 Analyze Waveform Data 3. Examine the zoomed view of the waveform that appears on the larger, lower portion of the display. The upper portion of the display will show the position and size of the zoomed portion in the waveform, within the context of the overall record.
Page 142 Analyze Waveform Data 3. Change the play direction by reversing the direction that you are turning the pan knob. 4. During play, up to a point, the more you turn the ring, the faster the waveform accelerates. If you rotate the ring as far as it can go, the play speed does not change, but the zoom box quickly moves in that direction.
Page 143 Analyze Waveform Data To manually set and clear (delete) marks: 1. Move (the zoom box) to the area on the waveform where you want to set (or clear) a search mark by turning the pan (outer) knob. Push the next ( →) or previous (←) arrow button to jump to an existing mark.
Page 144 Analyze Waveform Data 4. On the screen, hollow triangles show the location of automatic marks and solid triangles show the custom (user-deﬁned) locations. These appear on both normal and zoomed waveform views. 5. You can quickly investigate your waveform by moving from search mark to search mark with the next ( →) and previous (←) arrow buttons.
Page 145: Analyzing Power
Search for rising and/or falling edges that are >, <, =, or ≠ a user speciﬁed time. Parallel: Search for a binary or hex value (MSO3000 Series only). C: Search for Start, Repeated Start, Stop, Missing Ack, Address, Data, or Address and Data.
Page 146: Save And Recall Information
Save and Recall Information Save and Recall Information The oscilloscope provides permanent storage for setups, waveforms, and screen images. Use the internal storage of the oscilloscope to save setup ﬁles and reference waveform data. Use external USB ﬂash drives, to save setups, waveforms, and screen images. Use the external storage to carry data to remote computers for further analysis and for archiving.
Page 147 Save and Recall Information 2. Push Save Screen Image, Save Waveform, Save Save Save Recall Recall Assign File Waveform Setup Utilities Screen Waveform Setup or Save Setup. Save| to Image Setup 3. For waveform or setup ﬁles, enter the ﬁle To File manager by pushing the side menu To File item.
Page 148: Saving A Screen Image
Save and Recall Information Saving a Screen Image A screen image consists of a graphical image of the oscilloscope screen. This is different from waveform data, which consists of numeric values for each point in the waveform. To save a screen image: 1.
Page 149: Saving And Recalling Waveform Data
Save and Recall Information Saving and Recalling Waveform Data Waveform data consists of the numeric values for each point in the waveform. It copies the data, as opposed to a graphical image of the screen. To save the current waveform data or to recall previously stored waveform data: 1.
Page 150 Save and Recall Information Saving an analog waveform to reference memory. To save an analog waveform to nonvolatile memory inside the oscilloscope, select the waveform that you want to save, push Save Waveform, and then select one of the reference waveform locations.
Page 151: Saving And Recalling Setups
Save and Recall Information Saving and Recalling Setups Setup information includes acquisition information, such as vertical, horizontal, trigger, cursor, and measurement information. It does not include communications information, such as GPIB addresses. To save the setup information: 1. Push Save / Recall Menu. 2.
Page 152: Saving With One Button Push
Save and Recall Information Push Menu Off to cancel the save operation, or select a Save to Selected File item on the side menu to complete the operation. 5. Save the ﬁle. Save to Selected File Quick Tips Recalling the Default Setup. Push Default Setup on the front-panel to initialize the oscilloscope to a known setup. (See page 47, Using the Default Setup.) Saving with One Button Push After you have deﬁned the save/recall parameters with the Save/Recall Menu button and menu, you can save ﬁles with a...
Page 153: Managing Drive, Directories, And Files
Save and Recall Information 4. From now on, when you push Save the oscilloscope will perform the action that you just speciﬁed rather than requiring you to navigate through the menus each time. Managing Drive, Directories, and Files You can manage drives, directories, and ﬁles from the oscilloscope user interface. 1.
Page 154: Printing A Hard Copy
Save and Recall Information Printing a Hard Copy To print an image of what appears on the oscilloscope screen, do the following procedure. Connect a Printer to Your Oscilloscope Connect a non-PictBridge printer to a USB port on the rear or front-panel of the oscilloscope. Alternatively, connect a PictBridge printer to the USB device port on the rear panel or hook up a networked printer through the Ethernet port.
Page 155 Save and Recall Information 5. Select the image orientation (portrait or landscape). Landscape Portrait 6. Choose Ink Saver On or Off. The On selection will print out a copy with a clear (white) background. Ink Saver on Ink Saver off MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 156 Save and Recall Information Printing to a PictBridge Printer To set up the oscilloscope to print to a PictBridge printer: 1. Push Utility. 2. Push Utility Page. Utility Page 3. Turn multipurpose knob a and select I/O. 4. Push USB. Utility Ethernet GPIB...
Page 157 Save and Recall Information Printing Over Ethernet To set up the oscilloscope to print over Ethernet: 1. Connect an Ethernet cable to the rear-panel Ethernet port. 2. Push Utility. 3. Push Utility Page. Utility Page 4. Turn multipurpose knob a and select Print Print Setup Setup.
Page 158 Save and Recall Information 7. Turn multipurpose knob a to scroll through the list of letters, numbers, and other characters to ﬁnd the ﬁrst character in the printer name that you want to enter. If you are using a USB keyboard, use the arrow keys to position the insertion point and type in the printer name.
Page 159: Erasing Oscilloscope Memory
Save and Recall Information NOTE. If you have multiple printers connected to the oscilloscope at the same time, the oscilloscope will print to the printer listed in the Utility> Utility Page> Print Setup> Select Printer menu item. Printing with One Button Push Once you have connected a printer to your oscilloscope and set up print parameters, you can print current screen images with a single push of a button: Push the printer icon button in the lower left...
Page 160 Save and Recall Information 4. Push TekSecure Erase Memory. Utility Language Set Date & TekSecure About Page Time Erase English Memory Conﬁg 5. Push OK Erase Setup and Ref Memory Erase on the side menu. Setup & Ref Memory To cancel the procedure, push Menu Off. 6.
Page 161: Using Application Modules
Some modules are described in the following list. Additional modules may be available. Contact your Tektronix representative or visit our Web site at www.tektronix.com for more information. Also, refer to Contacting Tektronix at the beginning of the manual.
Page 162: Application Examples
Application Examples Application Examples This section contains ways to use your instrument in both common and advanced troubleshooting tasks. Taking Simple Measurements If you need to see a signal in a circuit, but you do not know the signal amplitude or frequency, connect the probe from channel 1 of the oscilloscope to the signal.
Page 163 Application Examples 1. Push Measure. 2. Push Add Measurement. Add Mea- Remove Indicators Bring surement Measure- Cursors More ment On Screen 3. If needed, on the side menu, push Source and turn multipurpose knob a to select the channel from which you want to measure. Turn multipurpose knob b to select the Frequency measurement.
Page 164 Application Examples 5. Observe that the measurements appear on the screen and update as the signal changes. Measuring Two Signals In this example, you are testing a piece of equipment and need to measure the gain of its audio ampliﬁer. You have an audio generator that can inject a test signal at the ampliﬁer input.
Page 165 Application Examples To display the signals connected to channels 1 and 2: 1. Push channel 1 and channel 2 to activate both channels. 2. Push Autoset. To select measurements for the two channels: 1. Push Measure to see the measurement menu.
Page 166 Application Examples 4. Calculate the ampliﬁer gain using the following equations: Gain = (output amplitude ÷ input amplitude) = (3.155 V ÷ 130.0 mV) = 24.27 Gain (dB) = 20 x log(24.27) = 27.7 dB Customizing Your Measurements In this example, you want to verify that the incoming signal to digital equipment meets its speciﬁcations.
Page 167 Application Examples To select the Rise Time measurement: 1. Push Measure. 2. Push Add Measurement. Add Mea- Remove Indicators Bring surement Measure- Cursors More ment On Screen 3. If needed, on the side menu, push Source and turn multipurpose knob a to select the channel from which you want to measure.
Page 168 Application Examples Reference Levels 5. Push Set Levels in to select units. Set Levels |Units 6. Push High Ref and turn multipurpose knob High Ref (a) 2.00 V a to enter 2.00 V. If needed, push Fine to change the sensitivity of the multipurpose knob.
Page 169: Analyzing Signal Detail
Application Examples 3. Push Add Measurement. Add Mea- Remove Indicators Bring surement Measure- Cursors More ment On Screen 4. If needed, on the side menu, push Source and turn multipurpose knob a to select the channel from which you want to measure. Turn multipurpose knob b to select the Positive Pulse Width measurement.
Page 170 Application Examples Looking at a Noisy Signal The signal appears noisy. You suspect that noise is causing problems in your circuit. To better analyze the noise: 1. Push Acquire. 2. Push Mode on the lower menu. Mode Record Delay Set Horiz. Waveform XY Display Length...
Page 171 Application Examples Separating the Signal from Noise Now you want to analyze the signal shape and ignore the noise. To reduce random noise in the oscilloscope display: 1. Push Acquire. 2. Push Mode. Mode Record Delay Set Horiz. Waveform XY Display Length Position to Display...
Page 172 Application Examples Taking Cursor Measurements You can use the cursors to take quick measurements on a waveform. To measure the ring frequency at the rising edge of the signal: 1. Push channel 1 to select the channel 1 signal. 2. Push and hold Cursors to turn on cursors and display the Cursor menu.
Page 173: Triggering On A Video Signal
Application Examples 9. Place the other cursor on the next peak of the ring using multipurpose knob b. 10. The cursor Δ readout shows the measured ring frequency is 227 kHz. Triggering on a Video Signal The oscilloscope supports triggering on NTSC, SECAM, and PAL signals. In this example, you are testing the video circuit in a piece of medical equipment and need to display the video output signal.
Page 174 Application Examples 2. Push Type. Type 3. Turn multipurpose knob a to scroll through Video the trigger type side menu until you select Video. 4. Push Video Standard, and turn Type Video Source Trigger On Mode Standard Video All Lines Auto multipurpose knob a to scroll through the 525/NTSC...
Page 175 Application Examples Triggering on Lines Triggering on Lines. To look at the video lines in the ﬁeld: 1. Push Trigger Menu. 2. Push Type. Type 3. Turn multipurpose knob a to scroll through Video the trigger type side menu until you select Video.
Page 176: Capturing A Single-Shot Signal
Application Examples 7. Observe the results. Capturing a Single-Shot Signal In this example, the reliability of a reed relay in a piece of equipment has been poor, and you need to investigate the problem. You suspect that the relay contacts arc when the relay opens. The fastest you can open and close the relay is about once per minute, so you need to capture the voltage across the relay as a single-shot acquisition.
Page 177 Application Examples 8. Push Single (single sequence). MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 178 Application Examples When the relay opens, the oscilloscope triggers and captures the event. The Single sequence button disables auto triggering so that only a valid triggered signal is acquired. Optimizing the Acquisition The initial acquisition shows the relay contact beginning to open at the trigger point. This is followed by large spikes that indicate contact bounce and inductance in the circuit.
Page 179: Correlating Data With A Tla Logic Analyzer
The iView External Oscilloscope Cable Kit allows you to connect your logic analyzer to a Tektronix oscilloscope. This enables communication between the two instruments. The Add External Oscilloscope wizard, which is available from the TLA application System menu, guides you through the process of connecting the iView cable between your logic analyzer and oscilloscope.
Page 180 System menu. 2. Select your model of oscilloscope. 3. Follow the on-screen instructions, and then click Next. 4. See your Tektronix Logic Analyzer documentation for more information on correlating data between your Tektronix oscilloscope and logic analyzer. MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 181: Tracking Down Bus Anomalies
Right Justiﬁed, and TDM bus signals requires use of an appropriate DPO3AERO, DPO3EMBD, DPO3AUTO, DPO3COMP, DPO3AUDIO, or DPO3FLEX Serial Triggering and Analysis Module. Triggering on Parallel bus signals requires use of an MSO3000 Series oscilloscope. 1. Connect the channel 1 probe to the clock line.
Page 182 Application Examples 5. Push Trigger Menu. 6. Push Type to select Bus. Enter trigger Type Source Trigger On Address Direction Mode Read Auto parameters in the resulting screen menus. Address B1 (I2C) & Holdoff 7. Analyze the physical layer. For example, you can use the cursors for manual measurements.
Page 183: Troubleshooting An Rs-232 Bus
Application Examples Troubleshooting an RS-232 Bus In this example, you are looking at analog characteristics of a digital signal in a digital circuit. You are doing this to analyze the signal integrity of a signal. For example, you might be testing RS-232 bus signals. Basic Strategy First, you will display and acquire the digital signal.
Page 184 Application Examples 6. Push Bus Display on the lower menu, push Bus and Waveforms on the side menu, and then push ASCII on the side menu. 7. Turn the Horizontal Scale knob to adjust the timebase. As you increase the time per division, you will see more data appear in the Bus display.
Page 185: Troubleshooting Circuits Using Parallel Buses
In this example, you are monitoring a parallel bus with your oscilloscope. You can use your MSO3000 Series oscilloscope with its 16 digital channels to analyze the bus. The MSO3000 Series will not only let you see the on-off status of the signals, but will also decode the parallel bus signals for you.
Page 186 Application Examples 5. Push Autoset. 6. Push B1, and select Parallel as the bus type. On the lower menu, push Deﬁne Inputs and enter the parameters for your bus for Clocked Data, Clock Edge, the Number of Bits, and Deﬁne Bits. 7.
Page 187: Appendix: Warranted Specifications
Appendix: Warranted Speciﬁcations Appendix: Warranted Speciﬁcations Analog bandwidth, The limits stated below are for ambient temperature of ≤30 °C and the bandwidth selection set to FULL. 50 Ω Reduce the upper bandwidth frequency by 1% for each °C above 30 °C. Instrument Bandwidth 10 mV/div to...
Page 188 Appendix: Warranted Speciﬁcations Offset accuracy ±[0.005 × | offset – position | + DC Balance] NOTE. Both the position and constant offset term must be converted to volts by multiplying by the appropriate volts/div term. Long-term sample ±10 ppm over any ≥ 1 ms time interval rate and delay time accuracy Auxiliary output...
Page 189 Appendix: Warranted Speciﬁcations Assumes that error due to aliasing is insigniﬁcant. The term under the square-root sign is the stability, and is due to TIE (Time Interval Error). The errors due to this term occur throughout a single-shot measurement. The second term is due to both the absolute center-frequency accuracy and the center-frequency stability of the timebase and varies between multiple single-shot measurements over the observation interval (the amount of time from the ﬁrst single-shot measurement to the ﬁnal single-shot measurement).
Page 190 Appendix: Warranted Speciﬁcations MSO3000 and DPO3000 Series Oscilloscopes User Manual...
Page 191: Index
Index Index Symbols and Numbers Button Acquire, 31, 51, 84, 148, 149 50 Ω protection, 93 B trigger, 82 Autoset, 11, 31, 35, 44, 48, 140 B1 / B2 button, 54, 55, 76 B1 / B2, 32, 54, 76 Backlight intensity, 88 B1 / B2 bus, 55 Bandwidth, xiii, 91 bus, 54, 55, 76...
Page 192 Index CAN trigger, 78 Deskew, 92 Changing the Font Appearance, 17 Digital channels, 97 Blackman-Harris, 115 Channel button, 32 Baseline indicators, 40 controls, 113 Channel readout, 40 Group icon, 41 Hamming, 114 Channel vertical menu, 90 scaling, positioning, grouping, Hanning, 115 Cleaning, 7 and labeling, 95 Rectangular, 114...
Page 193 Index Ground strap, 9 How to Icon Ground strap connector, 42 compensate a voltage Expansion point, 38 Ground yourself to discharge probe, 12 Trigger level, 39 static, 9 compensate the signal path, 19 Trigger position, 38 connect probes and Image orientation, 126, 133 Group icon, 41 Grouping channels, 67 adapters, 8...
Page 194 Dual waveform, 112 Network printing, 135 measurement, 102 FFT, 113 Next button, 34 Positive Pulse Count menu, 32 NI SignalExpress Tektronix Edition measurement, 103 waveforms, 112 software, xiii Positive Pulse Width Max measurement, 102 Normal trigger mode, 70 measurement, 101...
Page 195 Index RS-232, 32, 54, 76 Setup bus example, 161 default, 36, 44, 47, 130 Rackmount, 4 cursor readout, 111 Setup and Hold trigger, deﬁned, 75 Readout decoding, 65 Side panel connector, 42 Acquisition, 37 Signal path compensation, 19 trigger, 78 Auxiliary, 40 RS-422, 32 Single button, 35, 83, 146, 155...
Page 196 Index Trigger Trigger menu, 31, 73, 81, 151 View B trigger after delay time, 82 button, 73, 151 digital channels, 97 Bus, deﬁned, 76 Trigger modes waveform record, 38 buses, 76 Auto, 70 VISA, 24 byte matching, 80 Normal, 70 Voltage, Input CAN bus, 78 Trigger types, deﬁned, 74...

This manual is also suitable for:

Dpo3000 series Mso3054 Mso3012 Dpo3032 Mso3034 Dpo3054 ... Show all

Tektronix MSO3000 Series User Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tektronix MSO3000 Series

Summary of Contents for Tektronix MSO3000 Series

This manual is also suitable for:

Table of Contents
