Table of contents | en Table of contents Safety Short information Equipment overview Front view Rear view Top view Accessories Installation Delivery conditions Installation method Operation Maintenance Technical data Dimensions Bosch Security Systems B.V. 2024-10 | V1.00 | F.01U.429.438 User manual...
13. Use only the accessories/fittings specified by the manufacturer. Installation of any equipment should follow the manufacturer's instructions and should utilize the manufacturer's recommended mounting accessories. 2024-10 | V1.00 | F.01U.429.438 Bosch Security Systems B.V. User manual...
Page 5
To avoid electric shock, do not open the housing. Consult only qualified service personnel regarding maintenance matters. Warning! To prevent fire or electric shock hazard, do not expose the device to rain or moisture. Bosch Security Systems B.V. 2024-10 | V1.00 | F.01U.429.438 User manual...
Page 6
Telephone Network Voltage (TNV) circuits. The LAN port contains a SELV circuit and the WAN port contains a TNV circuit. Some LAN and WAN ports use RJ-45 connectors. Always be careful when connecting cables. 2024-10 | V1.00 | F.01U.429.438 Bosch Security Systems B.V. User manual...
Power supply status and fault status indicators. – Affixing to the cabinet tray through the screw holes. – Compact design allows 3 modules to be installed side by side at a 1U rack height. Bosch Security Systems B.V. 2024-10 | V1.00 | F.01U.429.438 User manual...
Icon Indicator and control Description Network interface Connecting to a PoE network switch Device reset button Restore factory default settings Analog audio output Balanced line level port audio output Bosch Security Systems B.V. 2024-10 | V1.00 | F.01U.429.438 User manual...
Secure the tray to the rack. Connect the network and audio cables to the module. Notice! The cabinet trays need to be configured by the installer. 2024-10 | V1.00 | F.01U.429.438 Bosch Security Systems B.V. User manual...
Page 13
PROSPERO Installation | en 105 93 Figure 5.1: Fixing the module on the cabinet tray Description Screw Nut (female component of nut and bolt) Bosch Security Systems B.V. 2024-10 | V1.00 | F.01U.429.438 User manual...
Page 14
| Installation PROSPERO Figure 5.2: Fixing a tray in a rack Figure 5.3: Network connection 2024-10 | V1.00 | F.01U.429.438 Bosch Security Systems B.V. User manual...
Page 15
Use Ultra Category 5 network cables (or higher). Figure 5.4: Analog audio output connection Use a three-pole balanced audio connection, paying attention to positive and negative polarity and grounding. Figure 5.5: Analog audio 3-pole balanced connection Bosch Security Systems B.V. 2024-10 | V1.00 | F.01U.429.438 User manual...
Page 16
| Installation PROSPERO Description Anodal Grounding Cathode Figure 5.6: Analog audio 2-pole unbalanced connection Description Anodal Grounding Negative to ground jumper 2024-10 | V1.00 | F.01U.429.438 Bosch Security Systems B.V. User manual...
Press and hold the device reset button for 5 seconds, then release it to reboot and restore to the factory default settings. Icon Indicator and control Description Device reset button Restore factory default settings Bosch Security Systems B.V. 2024-10 | V1.00 | F.01U.429.438 User manual...
| Maintenance PROSPERO Maintenance The modules do not require any special maintenance. To maintain cleanliness and a neat appearance, use a soft cloth to clean the module. 2024-10 | V1.00 | F.01U.429.438 Bosch Security Systems B.V. User manual...
Weight 465 g Color (RAL) RAL 9017 Traffic black Environmental Operating temperature (°C) -5°C — 45°C Storage and transportation temperature (°C) -40°C — 70 C Operating relative humidity, non-condensing <95% (%%) Bosch Security Systems B.V. 2024-10 | V1.00 | F.01U.429.438 User manual...
