120cm Steel Chimenea
I/N 0403640
•
Provides the warmth & atmosphere of an open fire to your outdoor area
•
Ideal for burning wood & charcoal
•
Hardened steel construction for long-lasting durability
•
Dimensions: 44cm diameter x 120 Height cm
Important: Please retain these instructions for future use
12
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Jumbuck 0403640
Summary of Contents for Jumbuck 0403640
- Page 1 120cm Steel Chimenea I/N 0403640 • Provides the warmth & atmosphere of an open fire to your outdoor area • Ideal for burning wood & charcoal • Hardened steel construction for long-lasting durability • Dimensions: 44cm diameter x 120 Height cm...
- Page 2 Contents Thank you ..........Page 1 Safety Warnings ........Page 2 Parts List ..........Page 3 Assembly Instructions ......Page 4 Operating Considerations ...... Page 7 First Time Use ......... Page 8 Operating Instructions......Page 9 Care Instructions ........Page 10 Product Warranty ........
- Page 3 You can rest assured that all Jumbuck products are manufactured to high standards of safety and quality, backed by a 12-month warranty. A lot of thought and development goes into every Jumbuck product, and we truly hope you are satisfied with this Jumbuck product.
- Page 4 Safety Warnings IMPORTANT: Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. Outdoor use only. DO NOT use the chiminea indoors. DO NOT use this chiminea inside ...
- Page 5 Assembly Instructions Parts Qty. Top flue (same as C) Decorated flue Base flue (same as A) 1 Top body Mesh body Legs Log Grate Mesh door Bolts (m6*15mm) Washer Chiminea cover Poker Hex Spanner Hex Key Page 3...
- Page 6 Assembly Instructions A hex key and spanner have been provided to assist with assembly. TIP: Hand tighten all bolts first, then use hex key and spanner to tighten fully. We recommend wearing gloves during assembly to prevent injuries from sharp edges. Step 1: Assemble the Legs (F) to Mesh Body (E) with 6 x Bolts (T), 6 x Washers (U), 6 x Nuts (V).
- Page 7 Assembly Instructions Step 3: Assemble the Top body (D) to Mesh Body (E) with 3 x Bolts (T), 3 x Washers (U), 3 x Nuts (V). a. Line up the holes on the Top body (D) b. Ensure the rear weld marks from with the holes on the Mesh Body (E) the Top Body (D) and Mesh Body (E) align Step 4:...
- Page 8 Assembly Instructions Step 5: Put Log grate (G) into Mesh Body (E). Fully Assembled Set up on a flat surface, ensure your chiminea is positioned on a level surface and positioned at least 2 metres distance from any side or overhead combustible materials.
- Page 9 Operating Instructions Considerations Before Use 1. Check with your fire department for information on burning bans and chimenea & fire pit regulations in your area. Chimenea’s can remain hot and smoulder for several hours after the visible fire has been extinguished.
- Page 10 Operating Instructions First Time Use: Curing, or firing as it is sometimes referred to as, is an important step that is often overlooked. What you’ll need: • Kindling • Fire Starters & Matches • Firewood 1. Put the grate inside the chiminea and ensure the top flue is open. 2.
- Page 11 Operating Instructions Subsequent Use: Preparation To get the fire started, you will need material that can be readily ignited or kindling and you will need firewood to fuel the fire. Gather these materials before attempting to light the fire so you are prepared. If the available firewood is too large, cut, trim or split the firewood to fit in the chimenea without overhang.
- Page 12 Operating Instructions Care and Maintenance Allow the fire pit to cool before cleaning. Always empty the residual ash after each use. To extend the life of your chimenea, protect it from the elements when not in use. The use of harsh, chemical cleaners or rough scourers can severely damage the external surfaces of your fire pit.
- Page 13 Conditions Thank you for purchasing one of our This warranty is given by Bunnings quality Jumbuck products. Please Group Limited keep your receipt as proof of purchase, as this will authenticate your ABN 26 008 672 179, Botanicca 3, Level warranty.
