Ascent Gas Pizza Oven
Steel Trolley
Gloss powder coated steel outer body & chimney
Galvanised steel inner fire body
Single 15MJ/h stainless steel gas burner
Stainless steel door & fascia
Trolley Stand With Wheels
AGA Gas Certified
Hose And Regulator Included
Universal LPG Only
Dimensions:700Lx650Wx1585Hmm
Stainless
steel
Enamel Coated
Oven Racks
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jumbuck HS-PZ002
Summary of Contents for Jumbuck HS-PZ002
- Page 1 Ascent Gas Pizza Oven Steel Trolley Gloss powder coated steel outer body & chimney Galvanised steel inner fire body Single 15MJ/h stainless steel gas burner Stainless steel door & fascia Trolley Stand With Wheels AGA Gas Certified Hose And Regulator Included Universal LPG Only Dimensions:700Lx650Wx1585Hmm Stainless...
- Page 2 ASSEMBLY & OPERATION INSTRUCTIONS JUMBUCK ASCENT GAS PIZZA OVEN (HS-PZ002) 0256532 FOR YOUR SAFETY FOR YOUR SAFETY Do not store or use gasoline or If you smell gas: Shut off gas to the appliance. other flammable vapours or liquids in the vicinity of this or 2.
-
Page 3: Important Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT: READ THE ASSEMBLY INSTRUCTIONS IN THIS BOOKLET BEFORE REMOVING THE CONTENTS OF THIS CARTON IMPORTANT SAFETY INSTRUCTIONS This gas oven should not be located under This appliance must only be used in an above overhead combustible construction and ground open-air situation with natural ventilation, proper clearances must be maintained at all without stagnant areas, where gas leakage and... -
Page 4: Other Considerations
WARNING OTHER CONSIDERATIONS A strong gas smell or the hissing sound of gas Strong winds and low temperatures can indicates a serious problem with your gas oven or affect the heating and performance of your the gas cylinder. Failure to immediately follow the gas oven so factor in these elements when steps listed below could cause serious bodily positioning your gas oven outdoors for... - Page 5 PLACEMENT OF GAS OVEN ANY ENCLOSURE IN WHICH THE APPLIANCE IS USED PLACEMENT OF GAS OVEN This product is meant for outdoor use only! Do not MUST COMPLY WITH ONE OF THE FOLLOWING: An enclosure with walls on all sides, but at least one store petrol or any inflammable liquids near this permanent opening at ground level and no overhead product.
-
Page 6: Gas Connection
GAS CYLINDER SAFETY INFORMATION GAS TYPE HOSE AND REGULATOR REPLACEMENT Note the labelling of appropriate gases listed on In the case of a problem arising with the hose and your gas oven and ascertain that the gas you have regulator please contact your gas oven supplier for is suitable for your gas oven. -
Page 7: Leak Testing
LEAK TESTING Please check for gas leakage the first time you are connecting the gas oven to the gas cylinder, and also each time you are replacing the gas cylinder or disconnecting/reconnecting any fittings. Inspect 1. Add soap and water to spray bottle or the hose before each use. -
Page 8: Lighting Procedure
CONTROLLING THE FLAMES LIGHTING PROCEDURE The knobs have three basic positions. You can achieve Lighting the gas oven is easy, but must be done any flame height between low and high by rotating the with due care. knob between these positions. ... -
Page 9: While Cooking
CARING FOR THE GAS OVEN WHILE COOKING Your gas oven should be kept clean to prevent Flames caused by fat dripping from the food could deterioration and it will look better and last longer if damage the food, causing the food to burn easily. you keep the gas oven clean. - Page 10 GAS OVEN MAINTENANCE IMPORTANT INFORMATION This product is for outdoor use only. Apart from cleaning, your gas oven is a fairly low Do not use indoors. maintenance appliance. Below are a couple of Do not use below ground level. things worth looking at though.Remember to turn ...
-
Page 11: Burner Maintenance
BURNER MAINTENANCE You should check the burner periodically for any sort Use a bottle brush with a flexible handle. Run the brush of blockage. To do this, remove and inspect them. If through the burner tube and inside the burner several any of theholes are clogged, gently tap the burner times, removing any debris. -
Page 12: Exploded View
EXPLODED VIEW... - Page 13 PARTS CODE Part Numbers Parts Name Parts Code Chimney cover PZ002-01 Chimney PZ002-02 Body asm (assembly) PZ002-03 Door asm PZ002-04 Temperature gauge PZ002-05 Hinge PZ002-06 Door handle PZ002-07 Knob PZ002-08 Door buckle PZ002-09 Drip tray PZ002-10 Cart handle PZ002-11 Body support plate PZ002-12 Left front leg PZ002-13...
-
Page 14: Carton Contents
CARTON CONTENTS 20. Door buckle - 1pc... -
Page 15: Hardware Pack Contents
HARDWARE PACK CONTENTS Bolt Nut M6 M6 x 12 mm Bolt Nut M10 M6 x 20 mm Flat washer Nut M8 Bolt Bolt M8 x 100 mm M4 x 12 mm 4pcs... - Page 16 ASSEMBLY INSTRUCTIONS Remove all contents from packaging, and make sure all the parts are present before attempting to assemble! Tighten all bolt connections by hand first. When the gas oven is fully assembled, retighten the screws, nuts and bolts by using a wrench and screw driver. STEP 1 Assemble the left front leg (part 11) and the left back leg (part 10) onto body support plate (part 9) as shown.
- Page 17 STEP 3 Assemble the cart handle (part 14) onto the cart as shown. STEP 4 Assemble the cart front plate (part 15) onto the cart as shown.
- Page 18 STEP 5 Assemble the cart bottom plate (part 16) onto the cart as shown. STEP 6 Assemble the wheel axle (part 17) and the wheel (part 18) onto the cart as shown. Ex2 Dx2...
- Page 19 STEP 7 Assemble the leg plug (part 19) onto the cart as shown. STEP 8 Assemble the door handle (part 2) and door buckle (part 20) onto the body asm (part 1) as shown.
- Page 20 STEP 9 Assemble the chimney cover (part 3) and the chimney (part 4) together as shown. Adjustable height STEP 10 Assemble the chimney asm onto the body asm (part 1) as shown.
- Page 21 STEP 11 Assemble the body asm onto the cart asm as shown. STEP 12 Place the grill (part 5), the ceramic plate (part 6), the oven rack (part 7) and drip tray (part 8) into the body.
- Page 22 Fully-Assembled Your gas oven is now ready for use. Please take care when lighting your gas oven. Always keep children away from this gas oven at all times.
-
Page 23: Specification
1/71 Truganina Road, Malaga, Western Australia, 6090, AUSTRALIA Phone: 61-8-9248 9822 Fax: 61-8-92488986 MODELS: HS-PZ002 - 1 burner pizza oven (gas oven) FEATURES: Black powder coated steel trolley, 2 directional wheels, high temp. lacquered grill body, S/S tube type burner... -
Page 24: Warranty
The warranty for New Zealand is given by : the operating manual. Any repair does not extend the warranty period. Bunnings NZ Limited Any parts other than original Jumbuck parts will PO Box 14436, void this warranty. Panmure, Auckland, 1471... - Page 25 WARRANTY For New Zealand Customer For Australian Customers Any claim under this warranty must be made To make a claim under the warranty, please within 12 months of the date of purchase of the contact Genesis International at product. To make a claim under the warranty, take service@genesiscorp.com.au or return the product the product (with proof of purchase) to any...
- Page 26 Liability will only be accepted for loss or damage technical issues with your JUMBUCK GAS OVEN, in the first instance review the instructions manual or during transit if at the time the product was being...
