No: 29188 – 09/24 rev. 4
Connecting LMCS-100 to a Network and Creating a Site ........................................................................................... 2
Connecting to a Network or Room ............................................................................................................................ 2
Logging in to Your Account or Requesting an Account ............................................................................................. 2
Creating a Site .......................................................................................................................................................... 3
Connecting to a Network with both Wired and Wireless Rooms .............................................................................. 4
LMBR-650 Network Setup ............................................................................................................................................. 4
Network/Device Discovery and Device Pairing Wizard .............................................................................................. 4
Switching between Static IP and DHCP ................................................................................................................... 6
Changing the Primary LMBR .................................................................................................................................... 7
Discovering and Pairing Wireless Devices ............................................................................................................... 7
Adding Unassigned Devices to a Room and Pairing Them ..................................................................................... 10
Pairing Room Devices in More Than One Room at a Time ...................................................................................... 11
Discovering Wired Devices Connected to an LMBC-650 ......................................................................................... 12
Viewing LMBR-650 and Wireless Network Information ............................................................................................ 13
Changing the Primary LMBR-650 in an existing Multi-LMBR Project ..................................................................... 15
BACnet Information Section ................................................................................................................................... 15
Using the Diagnostics Section to Check and View Network Information. ............................................................... 16
Discovering New Rooms or Devices in a Previously Discovered Network ........................................................... 16
For Wireless Networks ............................................................................................................................................ 16
Adding Devices Previously Paired with Push-to-Pair or the DLM Config App ...................................................... 16
Bringing Previously Paired Devices into LMCS ...................................................................................................... 17
If Retaining the Load Binding from PnL or the DLM Config App ............................................................................. 19
If Creating Load Binding in LMCS .......................................................................................................................... 20
If Replacing or Resetting an LMBR-650 ..................................................................................................................... 23
Replacing an LMBR-650 in a Multi-LMBR Network......................................................................................... 23
Replacing the LMBR-650 in a Single LMBR Network ..................................................................................... 24
Wattstopper
LMBR-650 Setup and Commissioning
User Guide
This document provides step-by-step details on the process needed to commission
one or more LMBR-650s and discover all wireless devices in a DLM network.
This document covers only the steps needed for commissioning and wireless
discovery. For further details on LMCS programming, including creating wireless
scenes and schedules, see the LMCS-100 Operation Manual, available at:
https://www.legrand.us/wattstopper/software.
For details on using DLM Dashboard software with the LMBR-650, see the DLM
Dashboard User Guide.
CONTENTS
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the Wattstopper LMBR-650 and is the answer not in the manual?

Questions and answers

Related Manuals for LEGRAND Wattstopper LMBR-650

Summary of Contents for LEGRAND Wattstopper LMBR-650

  • Page 1 This document covers only the steps needed for commissioning and wireless discovery. For further details on LMCS programming, including creating wireless scenes and schedules, see the LMCS-100 Operation Manual, available at: https://www.legrand.us/wattstopper/software. For details on using DLM Dashboard software with the LMBR-650, see the DLM Dashboard User Guide.
  • Page 2 CONNECTING LMCS-100 TO A NETWORK AND CREATING A SITE Connecting to a wireless network requires creating a site, so that the network is secure and accessible only to those with proper permissions. The following is a basic summary of these steps: •...
  • Page 3 Register Dialog 2. Enter information in all fields. Passwords must follow these rules: at least 8 characters long, containing at least one capital letter and one number. 3. After requesting an account, an email will be sent to the address entered here once the account has been authorized. LMCS will not provide any indication that the account has been authorized.
  • Page 4 Connecting to a Network with both Wired and Wireless Rooms In the case of a network with both wired and wireless rooms, the wired rooms will include an LMBC-650 network bridge. The process of connecting to this network is identical to the process for an all wireless network. However, during the wireless discovery process, for rooms with wired devices you will only discover the wireless bridge in each room.
  • Page 5 Discover Networks 3. Select one or more of the LMBR-650s. Click Add. NOTE: Wattstopper recommend that you select all the LMBRs that will be used in the site, to simplify the commissioning process 4. A new dialog pops up that allows you to select the Network ID and Channel the LMBR will use to communicate with the wireless DLM devices.
  • Page 6 Added Networks 7. Click Close to exit the Network Discovery wizard. IMPORTANT: Wattstopper strongly recommends that you update the firmware in the LMBRs to the most current version, if they are not current. There are two different methods for updating the firmware - update a single LMBR, or update multiple LMBRs in the same process.
  • Page 7 IP Configuration Set To DHCP IP Configuration Set To Static IP 4. Change the values of the different parameters, if needed. Note that the default IP address will be different from the value assigned through DHCP. Click OK to change the LMBR to the new values. 5.
  • Page 8 Config Button Config Button (Behind Switch Plate) Once woken up, the battery devices will remain awake for five minutes while the LMBR establishes contact. However, once you begin the next series of steps, LMCS takes control of the devices and they will remain awake for as long as is needed for LMCS to complete the process of moving the devices to the LMBR’s network and pairing the devices in rooms.
  • Page 9 3. The right side of the dialog allows you to create areas and rooms, using the Add button. If you add an Area and then add a Room while the area is highlighted, the room will be placed within that area. You can name the rooms or areas as they are added. NOTE: You can work on adding rooms and areas while the device discovery process is going on—LMCS continues searching for devices while this dialog is open.
  • Page 10 7. Once everything is completed, click Close. If there are further LMBRs that need to have devices assigned to them, highlight the wireless network of that LMBR and repeat the entire process. 8. If you click the Devices tab and expand the Tree now, you will see the rooms you created and the devices assigned to those rooms.
  • Page 11 Clicking the Discover Devices button will allow you to discover devices that were previously paired using the manual Push-to-Pair method or the DLM Config App, so you can re-pair them. NOTE: It is also possible to move previously paired devices from one room to another, by using the same process of dragging them to the new room and then clicking Wireless Device Pairing.
  • Page 12 Pairing Status DISCOVERING WIRED DEVICES CONNECTED TO AN LMBC-650 If you have one or more LMBC-650 bridges in your network, the wired devices connected to those bridges are not discovered during the wireless discovery process. There are two possible methods for discovering the wired devices. •...
  • Page 13 VIEWING LMBR-650 AND WIRELESS NETWORK INFORMATION If you select the Networks tab, each LMBR-650 that has been discovered will display in the Networks tree. LMBR-650 Information You can enter a Description and it will display in the tree. The IP Address can be edited, but if you do so, it would need to be changed on the LMBR, so it is recommended you do not change it here.
  • Page 14 LMBR-650 Status The Enable Device Harvesting button is a way to manually run the device harvesting process if something happens and it fails to run after a firmware update of the LMBR. The Device Harvesting process is what allows the LMBR websocket to push updates to LMCS. Device Harvesting Clicking the Run Multi-LMBR Config button will reestablish the Primary LMBR as primary, for situations in which that info has been lost by the LMBRs.
  • Page 15 Wireless Network Information Battery device must be woken up before running diagnostics or they will return an error. You can enter a Description for the network and it will display in the tree. The Network ID and Channel used for wireless communication are set during the wireless configuration wizard and cannot be changed here.
  • Page 16 Using the Diagnostics Section to Check and View Network Information. The bottom section of the window provides the ability to check network information for one or more devices in the network. 1. Choose a network test to run. These include: •...
  • Page 17 Bringing Previously Paired Devices into LMCS There are two different situations that apply when adding an existing network: • You want to retain the load binding programming in the room originally created using Push n’ Learn or Quick Pair in the DLM Config App.
  • Page 18 6. LMCS will then attempt to obtain the network key from the room controller and a message displays showing the status. When complete, click Next. 7. The prompt now informs you that the devices will need to be discovered. Before that can occur, the devices must exit Push-to-Pair mode.
  • Page 19 9. The Discovering Commissioned Devices dialog opens. The window will populate with all devices in the room. If any switch or sensor devices are not awake, you must wake them by pressing the Config button before they will appear in the list. Once all devices have been found, click Next.
  • Page 20 4. Go to the Devices view. Add a new room in the tree (if needed, add an area and a room within that area). Then select all the devices under Unassigned devices and drag them into the new room. 5. Highlight the new room in the tree and click Read All Devices. A pop-up dialog shows the status of reading in the parameters from the devices.
  • Page 21 2. Highlight the room then select the devices to be moved to that room. If you created more than one room and selected only some of the devices, when you select the next room only the unselected devices will be available to move into the second room. Once all devices have been selected.
  • Page 22 4. The new devices will now appear under the network of the temporary LMBR you used to add the existing network in the Networks view. They will also appear under the newly created room in the Devices view. 5. Now that the room has been added to LMCS, you will need to move the devices to a different LMBR before you can discover and bring in the next network (room).
  • Page 23 IF REPLACING OR RESETTING AN LMBR-650 If you need to replace a commissioned LMBR-650 for any reason (or if that LMBR was reset), highlight that specific LMBR in the tree, then click Replace Router if it is a multi-LMBR site or Add Existing Network if it is a single LMBR site. For a multi-LMBR site, you can replace either the primary or any secondary LMBR.
  • Page 24 NOTE: If you are replacing the primary LMBR, the new LMBR will automatically become the primary. NOTE: You can use this same process if an LMBR was reset but not replaced. The only difference is that the same MAC address will display for the original and “replacement”...
  • Page 25 5. Click Create. You return to the Discover Networks dialog. Click Close. 6. Return to the Networks view. Select the LMBR and click Add Existing Network. 7. A wizard opens that walks through the steps necessary to reconnect the LMBR to your devices. Click Next. 8.
  • Page 26 9. The wizard display the status at it attempts to set the LMBR to default. When complete, click Next. 10. At this point a prompt appears informing you that you must put the room controller into Push-to-Pair mode, by pressing the Config button on any device in the room three times (within three seconds).
  • Page 27 14. The Discovering Commissioned Devices dialog opens. The window will populate with all devices in the room. If any switch or sensor devices are not awake, you must wake them by pressing the Config button before they will appear in the list. Once all devices have been found, click Next.
  • Page 28 16. The dialog will close and all of the devices will be assigned to the Unassigned Devices category in the tree. Go to the Devices area. Then select all the devices under Unassigned devices drag them into the room that they were originally placed in. 17.
  • Page 29 19. LMCS reads in all the pairing and binding info. Once complete, click Finish. Then click Send All Devices to send the wireless scene information back to the devices. You must repeat the last three steps for each room in the project. NOTE: Instead of clicking Send All Devices separately for each room, you may instead highlight the Building in the tree and click the same button from there to send to all devices in all rooms.
  • Page 30 In order to enhance the security of our products, Legrand ships its products with all insecure ports closed and insecure protocols disabled. You are free to configure your device as needed, but in doing so note that you may be decreasing the security of your device and any information contained in the device.
