LEGRAND LUXUL RT-20 Setup Manual

RT-20 Setup Guide
1.

Setting up your router:

Place your router in a rack
or on a desktop
3a.
Download the Easy Setup App
or search "Luxul Easy Setup App" on:
2.
3b.
Connect a computer to one of the LAN ports of your router.
Open a web browser and go to 192.168.0.1
Login with the default User Name and password
or
NOTE:
The WAN port will be disabled until a new password is selected
NOTE:
automatically, you'll need to set a temporary static IP address on
that device. Set the IP address of your computer to an address in
the 192.168.0.X range, then set the Gateway/router address to 192.168.0.1
Connect an Ethernet cable from your telco/ISP
modem/router to the WAN 1 port of your router.
Connect the included power cable from your router
to your power source
ISP
MODEM
User Name: admin
Password: Unique to device, found on device label
You will be required to change the default administrator password.
If your computer or device isn't set to obtain an IP address
