- Page 1 SPECIAL EDITION WIRELESS CONTROLLER USER MANUAL...
- Page 2 TABLE OF CONTENTS ENGLISH • Controller Button Map . . . . • Connecting . . . . . . . . . . . . . . •...
- Page 3 CONTROLLER BUTTON MAP Battery View Xbox Button / Menu Status Sync Reset Button LED Indicator Button Port Button Pinhole Right Left Bumper Bumper Right Trigger Left Trigger A/B/X/Y Left Buttons Trigger Trigger Thumbstick Lock Right Lock Left Right D-Pad Thumbstick AGR 1 AGL 1 AGR 2...
- Page 4 BOX CONTENTS • Controller • 2 .4 GHz USB Wireless Adapter • 1 0 ft. / 3 m USB-C® • User Manual to USB-A Cable CONNECTING VIA WIRED USB MODE 1. Connect the included USB-C Cable to the USB-C port at the top of the controller and connect the other end to an available USB port on the Xbox Series X|S console or Windows 10/11 PC.
- Page 5 CONNECTING VIA WIRELESS MODE: 2.4 GHZ 1. Insert the wireless USB adapter into an available USB port on the Xbox Series X|S console or Windows 10/11 PC. 2. If controller is off, press the Xbox button (icon) to turn on (LED will flash WHITE). 3. 2.4 GHz should be paired to the Xbox Wireless Controller by default. If it is not paired, please follow the instructions below to sync the controller to the adapter: a.
- Page 6 CHARGING CONTROLLER VIA USB TRIGGER LOCK ADJUSTMENT For best results, fully charge controller prior to first use. 1. Connect the included USB-C cable to the USB-C port at the top of the controller and connect the other end to an available USB port on the Xbox Series X|S console or Windows 10/11 PC. 2. When charging, the Battery Status LED on the top housing will flash AMBER.
- Page 7 PROGRAMMING THE ADVANCED GAMING BUTTONS RESETTING THE ADVANCED GAMING BUTTONS A. Press the MAP AGB Button on the back of the controller for 3 seconds. B. The Xbox Button LED ring will flash, signaling the controller is in assign mode. A. Hold the MAP AGB Button down for 2-3 seconds. The Xbox button LED will C. Press the button (A/B/X/Y/LT/RT/LB/RB/Left Stick Press/Right Stick Press/D-pad) you wish to slowly flash, signaling the controller is in assign to an Advanced Gaming Button. assign mode. D. Then press the Advanced Gaming Button (AGR1/AGR2 or AGL1/AGL2) that you wish B. Press the previously assigned to perform that function. The Xbox Button LED ring will turn solid WHITE, signaling the Advanced Gaming Button for 5 seconds, Advanced Gaming Button has been set. Repeat for the remaining Advanced Gaming Buttons. and the function will be cleared. NOTE: Advanced Gaming Button assignments will remain in memory even after disconnected. 1,2,3...
- Page 8 PROFILE SETTINGS A. Quick-tap the MAP AGB button to cycle through profile settings for T1/T2/T3 trigger locks. The Xbox Fortnite Wireless Controller can store up to 3 profiles at a time locally. The first 3 profiles set by default adjust the deadzone settings for the triggers. • Profile 1 is 99% deadzone and is the quickest maximum value setting (use for T1 trigger lock). • Profile 2 is 50% deadzone (use for T2 trigger lock). • Profile 3 is no deadzone / full-throw trigger pull (use for T3 trigger lock). Each press of the PRO/MAP button will change to the next profile > > > and then repeat the cycle: 3 — 2 — 1 — B. The Xbox button LED ring will quickly flash 3 times in the corresponding profile color to signal a profile has been changed and then return to the current LED mode and color settings. C. To clear the profiles or change the settings, please use the PowerA Gamer HQ app. The above 3 default settings will be saved as legacy settings (Profile 1 / Profile 2 / Profile 3) in the PowerA Gamer HQ app. The app can store hundreds of custom profile settings that can be pushed to the controller, but the controller can only store 3 at any given time chosen from the app.
- Page 9 Gamer HQ The Gamer HQ app can be used to test, calibrate, and customize settings on your controller. With your controller connected to Xbox or Windows 10/11 PC via USB-C cable you can: • Update firmware to the to the latest version • Test your controller’s buttons and analog controls, vibration functionality, and audio • Recalibrate analog inputs for proper control response • Set trigger and thumbstick deadzone/active area • Set game-chat volume balance and vibration intensity • Control all RGB LED settings • Remap buttons (including Advanced Gaming Buttons) You can also create custom profiles to use for different games or players, and push up to three profiles to your controller for convenient access via the PROFILES button while you are gaming. You can download the Gamer HQ app from the Windows Store using Xbox or a Windows 10/11 PC.
- Page 10 PC USB port. Press and period with proof of purchase by the original purchaser only. Expenses associated hold the SYNC button on the top of the wireless with a warranty claim are the responsibility of the consumer. Conditions of this adapter. The LEDs on controller and adapter should warranty are on our website: PowerA.com/warranty-ANZ each flash several times and then when successfully This warranty is provided in addition to other rights or remedies available to you paired stay solid WHITE. under the law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a PROBLEM: My wireless controller is not pairing.
- Page 11 FCC STATEMENT CAN ICES-003(B)/NMB-003(B) This device complies with Part 15 of the FCC Rules. Operation is subject This device contains license-exempt transmitter(s)/receiver(s) that to the following two conditions: (1) this device may not cause harmful comply with Innovation, Science and Economic Development Canada’s interference, and (2) this device must accept any interference received, license-exempt RSS(s). Operation is subject to the following two including interference that may cause undesired operation. conditions: CAUTION: Changes or modifications not expressly approved by the party (1) This device may not cause interference. responsible for compliance could void the user’s authority to operate the (2) This device must accept any interference, including interference that equipment. may cause undesired operation of the device. NOTE: This equipment has been tested and found to comply with the limits This equipment complies with IC RSS-102 radiation exposure limits set for a Class B digital device, pursuant to Part 15 of the FCC Rules. These forth for an uncontrolled environment. limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in RF EXPOSURE STATEMENT accordance with the instructions, may cause harmful interference to radio This equipment complies with IC RSS-102 radiation exposure limits set communications. However, there is no guarantee that interference will not forth for an uncontrolled environment. This transmitter must not be co- occur in a particular installation. located or operating in conjunction with any other antenna or transmitter. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...
- Page 12 EU/UK DECLARATION OF CONFORMITY Hereby, ACCO Brands USA LLC declares the wireless controller is in More information available via web-search of each symbol name. compliance with Directive 2014/53/EU and UK Radio Equipment Regulation Waste Electrical and Electronic Equipment (WEEE): Electrical and 2017, as well as other essential requirements and relevant provisions of EU electronic devices and batteries contain materials and substances directives and UK legislation. The full text of the declaration of conformity that can have damaging effects on human health and the environment. is available at the following internet address: PowerA.com/compliance This symbol indicates that this device and the battery must not be treated as household waste and must be collected separately. Dispose of the device via a collection point for the recycling of waste electrical WARNING: READ BEFORE PLAYING and electronic equipment within the EU, UK and in other European A very small percentage of individuals may experience epileptic seizures when countries that operate separate collection systems for waste electrical exposed to certain light patterns or flashing lights. Exposure to certain patterns and electronic equipment and batteries. By disposing of the device and...
- Page 13 • Discarded batteries may cause fire. Do not heat the controller or battery, or stop and rest for several hours before playing again. place either in or near fire. • If you continue to have any of the above symptoms or other discomfort MANUFACTURED FOR during or after play, stop playing and see a doctor. ACCO Brands USA LLC, 4 Corporate Drive, Lake Zurich, IL 60047 BATTERY WARNING ACCOBRANDS.COM | POWERA.COM | MADE IN CHINA • Do not attempt to repair the Li-ion battery yourself—you may damage the battery, which could cause overheating, fire, and injury. ADDITIONAL LEGAL • The Li-ion battery in your device should be serviced or recycled by PowerA © 2024 ACCO Brands. All Rights Reserved. PowerA and PowerA Logo are or an authorized provider and must be recycled or disposed of separately trademarks of ACCO Brands. from household waste. © 2025 Epic Games, Inc. All rights reserved. Fortnite and its logo are trademarks •...
- Page 14 ACCO Brands, 4 Corporate Drive, Lake Zurich, IL 60047 accobrands.com | powera.com | Made in China MODEL: XBGPSWLI...
