Summary of Contents for AEG CKB6541ACM
- Page 1 EN User Manual | Cooker CKB6541ACM aeg.com\register...
- Page 2 Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................8 4. PRODUCT DESCRIPTION................11 5. BEFORE FIRST USE..................12 6.
- Page 3 be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use.
- Page 4 • Never use water to extinguish the cooking fire. Switch off the appliance and cover flames with e.g. a fire blanket or lid. • CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously.
- Page 5 suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents. 2. SAFETY INSTRUCTIONS • The appliance must be earthed. This appliance is suitable for the following • Make sure that the parameters on the markets: GB IE rating plate are compatible with the electrical ratings of the mains power...
- Page 6 • The information about the gas supply is on • Use only accessories recommended for the rating plate. this appliance by the manufacturer. • This appliance is not connected to a • Always use glass and jars approved for device which evacuates the products of preserving purposes.
- Page 7 • Be careful not to let objects or cookware • If you use an oven spray, follow the safety fall on the appliance. The surface can be instructions on the packaging. damaged. • Do not clean the catalytic enamel (if •...
- Page 8 2.9 Disposal • Disconnect the appliance from the mains supply. • Cut off the mains electrical cable close to WARNING! the appliance and dispose of it. Risk of injury or suffocation. • Flat the external gas pipes. • Contact your municipal authority for information on how to dispose of the appliance.
- Page 9 3.5 Other technical data WARNING! These instructions are only valid in the countries whose symbols appear on this booklet's cover. 180 mm Gas category: 30 mm Gas supply: G20 (2H) 20 mbar Voltage: 220-240 V Frequency: 50 Hz 3.6 Gas burners BURNER NORMAL POWER Natural Gas...
- Page 10 To light the hob burner refer to the "Ignition of the hob burners". Check if the flame is regular. Check each of the burners. 5. Turn the knob for the hob to the off position. 3.10 Checking the Lid Safety Device 1.
- Page 11 3.12 Covering terminal board • When you refit the mains terminal cover, make sure that the lower tabs are located inside the bottom edge of the aperture, before you fix the two screws into the top edge of the mains terminal cover. •...
- Page 12 4.2 Hob overview Knobs for the hob Knob for the main oven functions Display Knob for the top oven functions Temperature indicator / symbol for the top oven Temperature indicator / symbol for the main oven 4.4 Accessories • Wire shelf Steam outlet - number and position For cookware, cake tins, roasts.
- Page 13 5.3 Changing the time Only the top oven works without the set time. You cannot change the time of day if any of the functions operates. flashes when you connect the appliance to the electrical supply, when there Press again and again until the indicator was a power cut or when the timer is not set.
- Page 14 6.2 Burner overview A. Burner cap B. Burner crown C. Ignition candle D. Thermocouple 6.3 Replacing burner parts WARNING! 1. Put carefully the burner crown on the Always turn the flame down or switch it burner body. Let the crown fall freely onto off before you remove the pans from the the body.
- Page 15 WARNING! Do not put the same pan on two burners. WARNING! Do not put unstable or damaged pots on the burner to prevent spills and injuries. CAUTION! 7.2 Diameters of cookware Make sure that pot handles are not WARNING! above the front edge of the cooktop. Use cookware with diameters applicable CAUTION! to the size of burners.
- Page 16 9. OVEN - DAILY USE 9.3 Activating and deactivating the WARNING! top / main oven Refer to Safety chapters. 9.1 Top oven functions It depends on the model if your appliance has knob symbols, indicators or lamps: Off position • The indicator comes on when the The oven is off.
- Page 17 2. Put the deep pan into the oven on the recommended shelf position. You can use the trivet to grill and toast thin pieces of food in large quantities. 1. Put the trivet into the deep pan. Make sure the supports of the wire shelf point down.
- Page 18 10.2 Buttons Button Function Description MINUS To set the time. CLOCK To set a clock function. PLUS To set the time. 10.3 Clock functions Clock function Application TIME OF DAY To set, change or check the time of day. Only the top oven works without the set time. DURATION To set how long the oven works.
- Page 19 11. OVEN - HINTS AND TIPS WARNING! Refer to Safety chapters. The temperature and baking times in the tables are guidelines only. They depend on the recipes and the quality and quantity of the ingredients used. 11.1 Information for test institutes Main oven Food Function...
- Page 20 Food Function Tempera‐ Time (min) Accesso‐ Shelf po‐ ture (°C) ries sition Apple pie, 2 tins (ø 20 cm) Conventional cooking 60 - 80 Grid on the grid, diagonally shif‐ Fatless sponge cake, 1 tin Conventional cooking 20 - 30 Grid (ø...
- Page 21 The walls with catalytic coating are self- cleaning. They absorb fat which collects on the walls while the appliance operates. To support the self-cleaning procedure, heat the empty oven on a regular basis. The oven cavities must be cleaned separately. 12.3 Cleaning the top oven 1.
- Page 22 12.7 Removing and cleaning the 12.8 Replacing the lamp door glasses - main oven WARNING! Risk of electric shock. The lamp can be hot. The door glass in your product can be different in type and shape from the 1. Turn off the oven. Wait until the oven is example you see in the image.
- Page 23 13.1 What to do if... Problem Possible cause Remedy You cannot activate the appliance. The appliance is not connected to Check if the appliance is correctly an electrical supply or it is connec‐ connected to the electrical supply. ted incorrectly. You cannot activate the appliance.
- Page 24 14.3 Product Information Sheet and Product Information according to EU and UK Energy Labelling and Ecodesign Regulations for Oven Supplier's name Model identification CKB6541ACM 948905194 Top oven: 105.6 Energy Efficiency Index Main oven: 95.4 Top oven: A Energy efficiency class Main oven: A Top oven: 0.75 kWh/cycle...
- Page 25 Top oven: 39 l Volume Main oven: 77 l Type of oven Oven inside Freestanding Cooker Mass 63.0 kg IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Meth‐ ods for measuring performance. 14.4 Oven - Energy saving Cooking with fan When possible, use the cooking functions...
- Page 28 867364326-A-352024...
