Page 3
Piezo Operating and Electrical Specifications ................... 12 Using the Inductive Encoder ......................... 13 A.2.1 Encoder Operating and Electrical Specifications ................13 A.2.2 Output Signals ............................13 Legacy 2 Phase Piezo Motor Wiring Diagram ..................... 13 MICRONIX USA,LLC www.micronixsusa.com Rev: 1.5...
Page 4
• Low profile, 10 mm height, 17 mm wide Piezo Motor – (PM-001) Carriage Base Figure 1-A. PPS-18, Piezo Motor Recommended Controllers The following controller that is available from MICRONIX USA for piezo stages: • MMC-100 • MMC-110 • NanoDrive Technical Data See Datasheet.
Page 5
Relative humidity between 20 - 80%. • Locate away from water, heat, and electrical noise. Package Contents If the product is damaged or there are missing components, contact MICRONIX USA immediately. Do not discard product packaging in case of return shipment. Package Should Contain: •...
Page 6
Please note, it is possible to move the carriage manually without damaging the stage. 2x M2 Socket Head Cap Screws 2x M1.5 x 6mm Dowel Pins Customer supplied base plate or mounting surface Direction of Travel Figure 4-A. PP-18 Installation MICRONIX USA,LLC www.micronixsusa.com Rev: 1.5...
Page 7
Reference Manual 4.1.2 X-Y Mounting An adapter plate is required for PP-18 XY mounting. Contact MICRONIX USA for additional or custom adapter brackets. A. Install the bottom stage to the mounting surface as shown in Section 4.1.1. B. Install the XY Bracket (PN: 430757, L20 shown) to the top of the stage using two M2 x 4 mm Phillips flat head screws at 0.22 Nm recommended torque.
Page 8
PP-18 Piezo Positioner Stage Reference Manual 5. Dimensions Note: Dimensions in millimeters Recommended General Mounting Pattern It is recommended to use a slot-hole dowel pin pattern for alignment. MICRONIX USA,LLC www.micronixsusa.com Rev: 1.5...
Page 9
(additional configurations available upon request) • Additional configurations available upon request • Positioning according to: Using Z-Bracket (P/N: 430753) and XY-Bracket (P/N: 430757) X-Y-Z PP-18 Accessories 430753 430757 Z-Bracket Adapter Plate L20mm XY Bracket L20mm MICRONIX USA,LLC www.micronixsusa.com Rev: 1.5...
Page 10
No other cables or components are needed. Connect the stage as shown below. Cable Descriptions: A. Motor Cable (Male Dsub 9 Pin, 1.5m PVC Black Cable) Figure 7-A. PP-18, Open Loop, Atmospheric Wiring Diagram MICRONIX USA,LLC www.micronixsusa.com Rev: 1.5...
Page 11
Motor Cable (Female Dsub HD 15 Pin to Male Dsub 9 Pin, 6” PVC Black Cable) C. Encoder Cable (Female Dsub HD 15 Pin to Female Dsub 9 Pin, 6” PVC Black Cable) Figure 7-B. PP-18, Open Loop, Atmospheric Wiring Diagram MICRONIX USA,LLC www.micronixsusa.com Rev: 1.5...
Page 12
Piezo Motor Atmospheric Open Loop Pinout 8. Supplementary Information Maintenance and Personal Safety The PP-18 series of linear piezo stages utilizes a maintenance free design. Do not modify • the stage or perform any maintenance unless specifically instructed to do so by MICRONIX USA personal.
