Instructions – Parts List
Parts
AIR MOTOR
REPLACEMENT KIT 233099
For replacing air motor 215963 on 1:1 ratio Fast–Flor Pumps,
Models 226940, 226941, 226942, 226943, 226944, 226945,
226947, 226948, 226951, 226952 and 226953.
NOTE: For detailed repair instructions, see Fast–Flo Pump
instruction manual 307427.
Read warnings and instructions.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
Copyright 1989, Graco Inc. is registered to I.S. EN ISO 9001
307977B
