• PS unit – power supply unit; • SPS unit – standby power supply unit. 1 APPLICATION The WMD-05S Motorized electromechanical swing gate is designed for managing pedestrian flows at checkpoints of industrial facilities, banks, administrative buildings, retail outlets, railway terminals, airports, etc.
Page 4
WMD-05S Motorized electromechanical swing gate Swing gate post ....................IP41 (EN 60529) Control unit ....................... IP40 (EN 60529) Overall dimensions (L × W × H): Swing gate with AG-650 swing panel ............773×145×1007 mm Swing gate with AG-900 swing panel ............1023×145×1007 mm Swing gate with AG-1100 swing panel ............
Page 5
The swing panel is a separate item in the price list and is to be purchased separately. The swing panel type is selected by the customer when ordering the gate. Three types of swing panels are available for the WMD-05S swing gate: − AG-650 for a passageway width of 700 mm, −...
Page 6
WMD-05S Motorized electromechanical swing gate automatically recharged; when the power supply is off, the gate automatically starts to work on battery power. • The swing gate is a normally-closed device, i.e., when all the power supplies are off, the closed swing gate is locked in the closed position.
Page 7
Assembly and Operation Manual The WMD-05S swing gate consists of a rotary post (1), stationary post with a flange (2), as well as a swing panel (3) with a filler panel (4). The filler (4) is embedded in the swing panel with the use of clips.
Page 8
WMD-05S Motorized electromechanical swing gate CU design The CU is intended to supply electrical power to the swing gate’s internal equipment and implement the control algorithm. It is a separate device in a closed metal housing with a top cover (see Figure 4), which can be wall-mounted and fixed so that it cannot be pulled off.
Page 9
Assembly and Operation Manual Figure 4 . Control unit...
Page 10
WMD-05S Motorized electromechanical swing gate Figure 5 . Arrangement of elements on the processor module board 5.5 Control of swing gate The swing gate can be controlled: • by an operator using an RC panel or WRC (see section 5.5.1);...
Page 11
Assembly and Operation Manual When the passage mode is set, the swing panel (3) will turn in the chosen direction. The swing panel’s speed and turning direction are controlled by signals of the motor drive encoder. The PASS R1(R2) and PASS L1(L2) contacts of the CU’s ACS connector (see Figure 6) are open in the initial state.
Page 12
WMD-05S Motorized electromechanical swing gate 6 MARKING AND PACKAGING The swing gate has the following marking: on the swing gate itself – the label is located inside the rotary post under the top cover (5) • (Figure 2). To find the label, the top cover of the rotary post needs to be removed by unscrewing 3 set screws in the upper part of the swing gate post.
Page 13
Assembly and Operation Manual 8 ASSEMBLY AND INSTALLATION When installing the electrical device, please observe safety measures specified in Section 7.1. Attention! The manufacturer shall not be liable for damage resulting from incorrect installation and declines any claims if the installation works are not performed in compliance with the instructions specified herein.
Page 14
WMD-05S Motorized electromechanical swing gate Figure 7 . Connection layout of the swing gate Legend is given in Table 1.
Page 15
Assembly and Operation Manual 8.4 Installation procedure All item numbers in the installation procedure are given according to Figure 2. Unpack the box with equipment, check carefully the delivery set in accordance with the Delivery Set section of the swing gate certificate. Make the marking for installation of the swing gate on the floor in accordance with Figure 8 and marking of cable ducts for laying the control cable and power cable.
Page 16
For additional information, please contact the PERCo Technical Support Department. 15. Set jumpers on the XP3, XP4, and XP5 connectors of the processor module to the required positions (see Figure 5).
Page 17
Assembly and Operation Manual 9 OPERATION When installing the electrical device, please observe safety measures specified in Section 7.2. Warning! • Do not use substances for cleaning of the swing gate that may cause mechanical damage of its surfaces or corrosion of its parts; •...
Page 18
WMD-05S Motorized electromechanical swing gate The following shall be taken into account: any operation mode is set by pressing buttons on the RC panel (or WRC fob) in the • respective combination; • when the STOP button is pressed, the swing gate switches to the Passage denial operation mode, automatically returning the swing panel to its initial position, when it blocks the passageway;...
Page 19
Section 9.3 of the Manual – Operation from built-in SPS unit. 9.5 Troubleshooting Possible faults to be corrected by the user themselves are listed in Table 3. In an unlikely event of other faults, please consult the PERCo Technical Support Department. Table 3. Troubleshooting Fault...
Page 20
WMD-05S Motorized electromechanical swing gate Fault Most possible cause Remedy The CU indicators Power and 24V/2A De-energize the CU, remove The =24V/2A fuse is burnt are on, but the 24V indicator on the CU the short circuit, and replace out due to possible...
