PERCo FP-01C Instruction Manual

Front panel for st-01 speed gate

Advertisement

Quick Links

CONTENTS:
1
APPLICATION ...................................................................................................................... 1
2
TECHNICAL SPECIFICATIONS ............................................................................................ 2
3
DELIVERY SET .................................................................................................................... 2
4
PRODUCT DESCRIPTION.................................................................................................... 3
4.1
Main features .................................................................................................................... 3
4.2
Card capture reader mechanism control ............................................................................ 3
4.3
Removal and installation of the card container ................................................................... 4
5
INSTALLATION..................................................................................................................... 5
5.1
Installation instructions ...................................................................................................... 5
5.2
Connection layouts of a built-in card capture reader .......................................................... 6
5.3
Troubleshooting ................................................................................................................ 8
5.4
Card capture reader settings ............................................................................................... 8
6
PERCO WARRANTY .......................................................................................................... 18

1 APPLICATION

FP-01C Front panel for ST-01 Speed gate with a built-in card capture reader (hereinafter -
FP-01C panel) is designed for installation on ST-01 speed gate and has a built-in card capture
reader for reading and withdrawing proximity cards, issued to the visitors and meant for return at
exit (hereinafter - guest cards) through the speed gate.
Built-in card capture reader should work together with a proximity card reader and an
ACS-controller. Card reader can be installed inside the panel, in this case reading of the card to be
withdrawn will take place during insert of the card into the card capture reader slot. Card capture
reader also allows to capture the cards with standard badge clips.
Card capture reader can be used as a part of PERCo access control systems, in this case data is
transferred via RS-485 interface from a built-in reader of the card capture reader to the PERCo
ACS-controller. Card capture reader can also work with third-party controllers, in this case, data is
transferred from a built-in reader of the card capture reader to the controller via Wiegand interface.
Attention!
Product is supplied as a part of ST-01 speed gate but to be ordered separately.
Built-in reader is not included in a delivery set and has to be purchased separately by the
customer. Reader has to comply with the following characteristics:
overall dimensions (length × width × height) ....................... not more than 155×68×28 mm
identifiers reading range ................................................................... not less than 40 mm
Product is a constructional part of ST-01 speed gate and is not supposed to be used separately.
Climatic operation conditions of the product are the same as for ST-01 speed gate
(GOST 15150-69, category U4, operation in premises with climate control). Installers should also
consider operation conditions of built-in optional equipment.
Label on the inner side of housing contains product name, type, manufacture date and serial
number.
Product in a standard delivery set is packed in transportation crate, which preserves its
components from any damages during transportation and storage.
Overall dimensions of the transportation crate ....................................................... 106×22×18 cm
Crate weight ................................................................................................................ max 18 kg
Product in the original package should be transported only in closed type cargo transport units (in
railroad cars, containers, closed cars, under decks, by plane, etc.). During transportation and
storage, crates can be stacked no more than 6 layers high.
FP-01C Front panel for ST-01 Speed gate
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FP-01C and is the answer not in the manual?

Questions and answers

Summary of Contents for PERCo FP-01C

  • Page 1: Table Of Contents

    Card capture reader can be used as a part of PERCo access control systems, in this case data is transferred via RS-485 interface from a built-in reader of the card capture reader to the PERCo ACS-controller.
  • Page 2: Technical Specifications

    Certificate & Operation Manual The storage of FP-01C panel in the original package is allowed indoors at ambient temperature from -40°C to +50°C and at relative air humidity up to 80% at +15°C. In the storage room should also be no acid fumes and gases, causing the corrosion.
  • Page 3: Product Description

    FP-01C Front panel for ST-01 Speed gate 4 PRODUCT DESCRIPTION Main features • In the front panel of the card capture reader there is a container with a lock for card collection. • Card reader (to be purchased separately) can be built in the panel, it should be installed inside at the upper part of the card capture reader panel using the double-sided tape.
  • Page 4: Removal And Installation Of The Card Container

    ХT6 – connector for connection of the power supply of the card capture reader (PWR and GND contacts). • ХT8 – connector for connecting the PERCo reader of the card capture reader to the lines with RS-485 interface (A and B contacts). •...
  • Page 5: Installation

    FP-01C panel installed increases by 68 mm (see Fig. 1). FP-01C panel should be installed on the ST-01 speed gate instead of the standard front panel (see Fig. 1 and ST-01 Operation Manual, Sect. 8.9.2). Before mounting (removing) the panel it is necessary to remove the glass cover from the turnstile (see ST-01 Operation Manual, Sect.
  • Page 6: Connection Layouts Of A Built-In Card Capture Reader

    ACS-controller – cable for the built-in reader and control cable for the card capture reader (10). 3. Install the FP-01C panel on the ST-01 speed gate by using the fixing hooks (5). 4. Install back the speed gate glass cover.
  • Page 7 FP-01C Front panel for ST-01 Speed gate Figure 5. Diagram for connecting the card capture reader to the ACS-controller via Wiegang interface (list of components mentioned in the Table 1)
  • Page 8: Troubleshooting

    * equipment is not included in the standard delivery set. 5.3 Troubleshooting Possible faults to be corrected by the customers themselves are listed in Table 2. For faults not listed in Table 2 we advise to consult PERCo Technical Support Department. Table 2. Possible failures and troubleshooting Fault...
  • Page 9 FP-01C Front panel for ST-01 Speed gate 4. Click "Edit" button on the page toolbar. The "Device properties" window will be opened. 5. In the opened window select "Additional outputs" tab. 6. In the window working area, select "Additional output No..." (number of the output must match the controller output that is physically connected to “Capture card”...
  • Page 10 Certificate & Operation Manual 10. If necessary, configure the system response to the "Fault" signal sent by the card capture reader. To do this: select "Additional input No..." (number of the input must match the input of the controller that is physically connected to the “Fault” output of the card capture reader) and set the following parameters by using the drop-down menu: •...
  • Page 11 FP-01C Front panel for ST-01 Speed gate 13. Click "Edit" button on the page toolbar. The "Device properties" window will be opened. 14. Switch to "Reader No... " tab (number of the reader must match the reader, which is controlled by the card capture reader).
  • Page 12: Ct/L14, Ct13 Configuration In Web-Interface For Working With The Card Capture Reader

    Certificate & Operation Manual 17. In the left part of the tab select ‘Withdraw the visitors’ identifiers after the passage” parameter and check the box: 18. Click “Save and close” button. The "Device properties" window will be closed; the settings are saved.
  • Page 13 FP-01C Front panel for ST-01 Speed gate and directions number that is controlled by the card capture reader. Set the following parameters for this direction: • in "Verification" parameters group for "Visitor pass external device verification:" parameter – value "Yes" and also set the necessary values of parameters "Visitor external device verification activation:"...
  • Page 14 Certificate & Operation Manual − "Source direction:" – "1" or "2" (depending on the passage direction that is controlled by the card capture reader), − "Receiver type:" – "Activate output", − "Receiver number:" - "1" - (number of the output that is physically connected to the “Capture card”...
  • Page 15: Ct/L04.2, Ct03.2 Configuration In Web-Interface For Working With The Card Capture Reader

    Attention! By using Web-interface it’s possible to set only the simplest visitor’s card withdrawal algorithm, to amplify the setting range, use PERCo-Web software. The CT/L04 (CT03) controllers are not compatible with configuration via Web-interface. 1. In "Configuration" → "Edit" → "Operating devices" section, select the OD that is physically connected to the card capture reader, then select "Reader 1"...
  • Page 16 Certificate & Operation Manual 3. Add the following Internal response in "Configuration" → "Edit" → "Internal response" section: − "Source type:" – "Visitor ID card presentation", − "Source number:" – "1" (number of OD that is physically connected to the card capture reader), −...
  • Page 17 FP-01C Front panel for ST-01 Speed gate Example of a overview of the sections "Internal response" and "Physical contacts" after configuration (template – "Turnstile" card capture reader controls the direction number "1", "Input 6" and "Output 3" are used to control the card capture reader, "Input 5" is used receive the "Alarm"...
  • Page 18: Perco Warranty

    Certificate & Operation Manual 6 PERCO WARRANTY PERCo (the Manufacturer) warrants that the FP-01C Front panel (the Product) complies with applicable statutory safety requirements, electromagnetic compatibility provided that the instructions on storage, installation and operation, given in the Assembly & Operation Manual, are observed.
  • Page 19 SOPHISTICATED PRODUCTS THAT, IF NOT FAULTY, CANNOT BE RETURNED BACK IF BY SOME REASON THE CUSTOMER DEEMS THEM UNSATISFACTORY The PERCo FP-01C Front panel is in conformity with the essential requirements of the EU’s Machinery, Low-Voltage and EMC Directives and carries the CE marking accordingly.
  • Page 20 WARRANTY CARD FP-01C Front panel with a built-in card capture reader for ST-01 Serial number Date of manufacture: ____________________ 20___ Quality Control Seal: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ «...
