Q-ew27 VESA adapter
Assembly
This VESA adapter is compatible with the following BENQ monitors :
EW277HDR
⚠ WARNING
To minimize the risk of injury, it is important to read all instructions
carefully before installation. We accept no liability for personal or
material damage caused by improper use of this product.
Also, be sure to pay attention to the technical specifications of the
product.
1. Read all instructions thoroughly.
2. A faulty installation can lead to damage or serious injury. Ensure that the
product and the monitor are securely mounted before use.
3. Make sure that the mount to which the product is attached can easily support
the total weight of the monitor, computer, and adapter.
support@3idee.eu | +352 661 26 72 76 | help.3idee.eu
instructions
Advertisement
Related Manuals for 3idee Q-ew27
Summary of Contents for 3idee Q-ew27
- Page 1 3. Make sure that the mount to which the product is attached can easily support the total weight of the monitor, computer, and adapter. support@3idee.eu | +352 661 26 72 76 | help.3idee.eu...
- Page 2 Assembly instructions Technical Specifications Maximum monitor weight: 7 kg / 15.4 lbs VESA standard compatibility: 75x75 mm Material: plastic Pivot angle: not compatible Maximum operating temperature: 35°C / 95°F Maximum ambient temperature: 35°C / 95°F ⚠ WARNING Exceeding the maximum load capacity, operating temperature or ambient temperature can lead to serious injury or damage.
- Page 3 Assembly instructions Important Safeguards Please read this manual carefully and keep it for future reference. If you pass the product on to third parties, this manual should always be included. Ignoring these instructions may result in injuries or damage to people and products, for which we cannot accept any liability.
- Page 4 For the disposal of this product we recommend to contact the responsible local authorities or disposal services. They can provide you with detailed information on available disposal options and recycling centers in your area. 4. Manufacturer Information 3idee S.à r.l. 19 Rue de Bitbourg L-1273 Luxembourg Luxembourg mail: info@3idee.eu...
- Page 5 Assembly instructions Scope of Delivery Accessories 4x M4x14 countersunk screw with cross slot (SP2) ⚠ NOTE: Please check before assembly that all accessory parts are complete. If anything is missing, please contact our customer service immediately via email or phone. We are happy to assist you.
- Page 6 Assembly instructions Horizontal / Vertical Alignment Please note: Not all VESA adapters and monitors are designed for vertical (upright) orientation. This limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information, as the load limit of the adapter can quickly be exceeded if not installed properly. We are continuously working on developing monitors and adapters that are also suitable for vertical orientation.
- Page 7 Place your BenQ monitor on a safe, soft surface to avoid damaging it during installation. Remove the original foot from your BenQ monitor. Now insert the 3idee VESA adapter as shown. (Figure 1) Figure 1 Make sure that the mounting screw in the monitor is loosened as shown.
- Page 8 Assembly instructions Step 4 Please make sure that all 4 screws are tight. (Figure 4) Figure 4...
