Hollyland Solidcom C1 Pro User Manual page 37

4. Web Configuration
Web Configuration
4.1 Logging into the Web Interface
Power on the hub and connect one end of an Ethernet cable to the RJ45 (LAN)
port on the hub and the other end to the computer's network port. Set the
computer's network segment to the same as the hub. Open a browser on the
computer and enter the following IP address.
Master device: 192.168.218.10
Remote device: 192.168.218.11
On the web interface, you can upgrade the hub, group the headsets, and
configure headset status.
4Connecting the Hub and Computer
Power on the hub and connect one end of an Ethernet cable to the RJ45 (LAN)
port on the hub and the other end to the computer's network port.
Logging into the Webpage
Press and hold the menu button to access the menu interface, select
Network to view the IP address, login name, and password.
Ethernet Cable
EN-36
