- Page 1 NPort 6100-G2/6200-G2 Series Quick Installation Guide Version 1.1, September 2024 Technical Support Contact Information www.moxa.com/support 2024 Moxa Inc. All rights reserved. P/N: 1802061501011 *1802061501011*...
- Page 2 Package Checklist • NPort 6150-G2 or NPort 6250-G2 • Power adapter (does not apply to -T models) • 2 wall-mounting ears • Quick installation guide (this guide) NOTE Please notify your sales representative if any of the above items are missing or damaged. For optional accessories, like power adapters for a wide-temperature environment or side-mounting kits, refer to the Accessories section in the datasheet.
- Page 3 Powering the Device Unbox the device server and power it up using the power adapter provided in the box. The location of the DC outlet on the device server is indicated in the following figures: NPort 6150-G2 NPort 6250-G2 - 3 -...
- Page 4 If you are connecting the DC outlet to a DIN-rail power supply, you will need a separate power cable, CBL-PJ21NOPEN-BK-30 w/Nut, to convert the terminal block output to the DC outlet on the NPort. If you are using a DIN-rail power supply or another vendor’s power adapter, ensure that the ground pin is properly connected.
- Page 5 LED Indicators Color LED Function Steady Power is on and the NPort is booting up Indicates an IP conflict, or the DHCP or BOOTP server did not respond properly or a relay output occurred. Check the relay output first. If the Ready LED Blinking continues to blink after resolving the relay output, there may be an IP conflict...
- Page 6 When the device is ready, connect an Ethernet cable to the NPort 6100- G2/6200-G2 directly with computer’s Ethernet port or an Ethernet port of a switch. Serial Ports The NPort 6150 models come with 1 serial port while the NPort 6250 models have 2 serial ports.
- Page 7 Software Installation The default IP address of the NPort is 192.168.127.254. There is no default username or password. You will need to complete the following first-login process as part of the basic settings. 1. Set up the first administrator's account and password for your NPort.
- Page 8 Mounting Options The NPort 6100-G2/6200-G2 device servers include a wall-mount kit in the box, which can be used to mount the NPort to a wall or the inside of a cabinet. You can order a DIN-rail kit or side-mount kit separately for different placement options.
- Page 9 Wall Mounting 壁掛式安裝 - 9 -...
- Page 10 DIN-rail Mounting (plastic) 塑膠配件的導軌式安裝 - 10 -...
- Page 11 Side Mounting 側掛式安裝 - 11 -...
- Page 12 DIN-rail Mounting (metal) With Side-mounting Kit 鐵件的導軌式安裝 - 12 -...
- Page 13 The mounting kit packages include screws. However, if you prefer to buy your own, refer to the dimensions below: • Wall-mounting kit screws: FMS M3 x 6 mm • DIN-rail mounting kit screws: FTS M3 x 10.5 mm • Side-mounting kit screws: FMS M3 x 6 mm •...
- Page 14 RoHS Compliance All Moxa products are marked with the CE logo to indicate that our electronic products have met the RoHS 2 Directive’s requirements. All Moxa products are marked with the UKCA logo to indicate that our electronic products have met the UK RoHS Regulation.
- Page 15 Restricted Bands of Operation for Wireless device The 5150-5350 MHz frequency band is restricted to indoor use for EU member states. As countries and regions have different regulations regarding the use of frequency bands to avoid interference, please check local regulations before using this device.
- Page 16 Operation is subject to the following two conditions: 1. This device must not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. It is understood that each unit marketed is identical to the device as tested, and any changes to the device that could adversely affect the emission characteristics will require retest.
- Page 17 Product Warranty Statement Moxa warrants this product to be free from manufacturing defects in materials and workmanship, starting from the date of delivery. The actual warranty period of Moxa’s products varies with product category. Complete details can be found here: http://www.moxa.com/support/warranty.htm NOTE The warranty statement on the above web page supersedes any statements in this printed document.
- Page 18 Repaired or replaced products are warranted for ninety (90) days from the date of repair or replacement, or for the remainder of the original product’s warranty period, whichever is longer. 产品保修声明 Moxa 自产品出货日起提供产品保修。保修期间，如因零件损坏或生产不良而导致 产品故障，将提供免费维修服务。 Moxa 根据产品类别提供不同保修期限，完整细节可在以下网页查看： http://www.moxa.com.cn/support/warranty_policy.htm 注 上述网页的保修声明可取代本声明的任何陈述。 从 Moxa 出货三个月之内，在正常安装与使用下，如产品发生故障，Moxa 将提供 换货服务。产品因雷击、洪水、地震等天灾所造成的损坏，其他外部力量（比如电...
- Page 19 技术支持与服务联络窗口 邮箱：Support.mcn@moxa.com 联系人：Moxa 技术支持部 返修服务联络窗口 邮箱：rma.mcn@moxa.com 联系人：Moxa 客服部 - 19 -...
- Page 20 产品中有害物质的名称及含量 产品：联网设备(串口联网设备/接口转换器/USB转串口集线器/浪涌保护器/现场总线) 有害物质 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 外壳 ○ ○ ○ ○ ○ ○ × 印刷电路板及其电子组件 ○ ○ ○ ○ ○ × ○ ○ ○ ○ ○ 电缆/电线/连接器 × 电源设备/电源适配器 ○ ○...
- Page 21 Moxa 产品注意事项 1. 请于使用产品前，详读本注意事项。 2. 请保存本注意事项以便后续参考。 3. 请于进行清洁工作前，将产品断电并且从电源端拔除。进行清洁工作时，请 勿直接将清洁用溶剂倾倒或喷洒于产品上，请透过清洁布进行清洁工作。 4. 本产品应使用于受限区域 (例如受人员管制的计算机室)，授权人员须了解并 知悉于碰触发热的金属机壳前, 应有妥善的安全防护。产品外部的金属件可 能会有一定热度，在接触产品前，请操作人员执行特别防护措施以免操作人 员的手或身体遭受伤害。 5. 若产品为需插电产品，请勿将产品摆放于电源插座太远的位置，并且确认操 作人员可以无阻碍地接近电源插座端。 6. 请让产品远离高湿环境。 7. 请将产品安装于稳固的环境。产品的掉落可能会造成损坏。 8. 产品开口处为力于产品内部空气对流。为确保产品不会过热，请不要阻塞开 口处。 9. 连接电源时，请确保电源端的电压输入正确。 10. 请将电源线放置于不会被人员踩踏以及物品重压的位置。 11. 请注意产品上或相关文件中所标示的警告。 12. 若产品不会长时间使用，请断电以避免电源端瞬间压升或压降。 13. 请勿倾倒任何异体于产品开口处，以避免火灾或触电。 14. 请勿自行拆卸产品。就安全考虑，请由合格的技术人员进行拆卸。 15. 若下列任一情形发生，请由合格的技术人员进行确认： 16.
- Page 22 19. 产品运作不良，或是您无法透过使用手册进行操作。 产品掉落并且造成损坏。 20. 产品有明显破损。 21. 任何未经验证的零配件可能造成产品非预期的损害。为确保安装的正确性， 请使用配件包所附之零配件进行安装。 22. 工业计算机产品内含有电池供电之实时时钟电路，请依制造商指示进行更 换。 23. 请于执行硬件工作时将机壳与电源断开联结。请勿于电源钮为启动状态时连 接电源，高感度电子零件可能会因瞬间浪涌电流而造成损伤。 24. 有关产品规格, 等级与符合之法规请参考产品本体之标示。 知识产权声明 随附本产品发行的文书或档案为 Moxa 版权所有，并保留相关权利。未经 Moxa 许 可，所有内容不得透过任何途径以任何形式复制、翻印或者传输。 产品保固相关信息 有关 Moxa 产品保固政策，请参照 Moxa 官网 http://www.moxa.com.cn/support/warranty_policy.htm。 限制责任声明 保修条款得取代其它无论是明示或暗喻、书面或口头的保修协议。Moxa 在产品制 造、销售、供应及使用上所担负的责任，无论是基于保修条款、合约、过失、产品 责任 或其它项目，均不应超过产品的原始成本。对于非蓄意或必然的客户损失， 包括因产品的制造、销售或供货所导致的利益损失及使用损坏，Moxa 不负任何赔 偿责任。 - 22 -...
- Page 23 Limitation of Liability The provisions of the warranty are in lieu of any other warranty, whether expressed or implied, or written or oral. Moxa’s liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original cost of the product.
- Page 24 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：RS-232/422/485 安全終端伺服器 型號（型式） NPort 6150-G2, NPort 6150-G2-T, NPort 6250-G2, NPort 6250-G2-T 限用物質及其化學符號 單元Ｕnit 鉛 汞 鎘 六價鉻 多溴聯苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr+6) (PBB) (PBDE) 外殼 ○ ○ ○ ○...
- Page 25 警告 為避免電磁干擾，本產品不應安裝或使用於住宅環境。 CAUTION Risk of Explosion if the battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. - 25 -...
