MULTI-DECK MERCHANDISER

INSTALLATION & OPERATIONS MANUAL

PF-48-SC/PF-51-SC/

BAKERY/BEVERAGE/CHEESE/DELI

Technical References .......................................2-17

General Information .............................................18

Installation ..................................................... 19-21

Case Connections .......................................... 22-23

Lighting & Power Supplies ............................. 24-25

To ensure proper functionality and optimum performance, it is STRONGLY recommended that Hillphoenix specialty cases be installed/serviced by qualiﬁ ed tech-

nicians who have experience working with commercial refrigerated display merchandisers and storage cabinets. For a list of Hillphoenix-authorized installation/

service contractors, please visit our website at www.hillphoenix.com.

PF-54-SC/PF-72-SC

Table of Contents

Pre-Power Checklist ............................................26

Airﬂ ow & Defrost ..................................................27

Case Cleaning ................................................ 28-29

Parts Ordering ......................................................30

Appendices

03/22

Need help?

Do you have a question about the Hillphoenix PF-48-SC and is the answer not in the manual?

Questions and answers

Summary of Contents for Dover Hillphoenix PF-48-SC

Page 1 MULTI-DECK MERCHANDISER INSTALLATION & OPERATIONS MANUAL PF-48-SC/PF-51-SC/ PF-54-SC/PF-72-SC BAKERY/BEVERAGE/CHEESE/DELI Table of Contents Technical References ........2-17 Pre-Power Checklist ..........26 General Information ..........18 Airﬂ ow & Defrost ..........27 Installation ............. 19-21 Case Cleaning ..........28-29 Case Connections .......... 22-23 Parts Ordering ............30 Appendices Lighting &...
Page 3 LIABILITY NOTICE For Cases with Shelf Lighting Systems Hillphoenix does NOT design any of its shelf lighting systems or any of its display cases with shelf lighting systems for direct or indirect exposure to water or other liquids. The use of a misting system or water hose on a display case with a shelf lighting system, resulting in the direct or indirect exposure of the lighting system to water, can lead to a number of serious issues (including, without limitation, electrical failures, ﬁ...
Page 4 Important ® t Hillphoenix , the safety of our customers and employees, as well as the ongo- ing performance of our products, are top priorities. To that end, we include impor- tant warning messages in all Hillphoenix installation and operations handbooks, accompanied by an alert symbol paired with the word "DANGER", "WARNING", or "CAUTION".
Page 5 Revision History • new manual format_07/21 • technical reference sheets_03/22...
Page 6 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-48-SC 4' & 6' (Bakery/Beverage/Cheese/Deli) GENERAL NOTES: • "---" Indicates that the feature is not an option on this case model and/or the data is not yet available at this time. SHIPPING WEIGHT Case Weight PF-48-SC ENGINEERED FOR STORES WITH AMBIENT...
Page 7 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-48-SC 4' & 6' (Bakery/Beverage/Cheese/Deli) SYSTEM REQUIREMENTS Minimum Maximum Case Total Circuit Overcurrent Ampacity Protection Length Volts Phase Amps 20.26 25.3 120/208 13.77 17.2 ELECTRICAL DATA High Efficiency Anti-Condensate Drain Evaporator Auxiliary Fans Fans Pumps Pan Heaters Fans...
Page 8 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-48-SC 4' & 6' (Bakery/Beverage/Cheese/Deli) DEFROST CONTROLS Electric Defrost Timed-Off Defrost Hot Gas Defrost Run-Off Termination Termination Termination Time Temp Temp Temp Defrosts Fail-Safe Fail Safe Fail-Safe Per Day (Min) (Min) (°F) (Min) (°F) (Min) (°F) ENGINEERED FOR STORES WITH AMBIENT...
Page 9 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-48-SC 4' & 6' (Bakery/Beverage/Cheese/Deli) LOAD LIMIT 19 5/16" [49.0 cm] 10" 16" 30" [76.3 cm] COMPRESSOR COMPARTMENT 33" [83.9 cm] (AIRFLOW BACK TO FRONT) 42" [106.8 cm] POWER CORD WITH PLUG TOEKICK FRONT OF CASE 48 1/2"...
Page 10 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-51-SC 4' & 6' (Bakery/Beverage/Cheese/Deli/Meat) GENERAL NOTES: • "---" Indicates that the feature is not an option on this case model and/or the data is not yet available at this time. SHIPPING WEIGHT Case Weight PF-51-SC ENGINEERED FOR STORES WITH AMBIENT...
Page 11 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-51-SC 4' & 6' (Bakery/Beverage/Cheese/Deli/Meat) SYSTEM REQUIREMENTS Minimum Maximum Circuit Overcurrent Case Total Ampacity Protection Length Volts Phase Amps 20.26 25.3 120/208 13.77 17.2 ELECTRICAL DATA High Efficiency Anti-Condensate Drain Evaporator Auxiliary Fans Fans Pumps Pan Heaters Fans...
Page 12 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-51-SC 4' & 6' (Bakery/Beverage/Cheese/Deli/Meat) DEFROST CONTROLS Electric Defrost Timed-Off Defrost Hot Gas Defrost Run-Off Termination Termination Termination Time Temp Temp Temp Defrosts Fail-Safe Fail Safe Fail-Safe Per Day (Min) (Min) (°F) (Min) (°F) (Min) (°F) ENGINEERED FOR STORES WITH AMBIENT...
Page 13 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-51-SC 4' & 6' (Bakery/Beverage/Cheese/Deli/Meat) LOAD LIMIT 19 5/16" [49.0 cm] 10" 16" 30" [76.3 cm] COMPRESSOR COMPARTMENT 33" [83.9 cm] (AIRFLOW BACK TO FRONT) 42" [106.8 cm] POWER CORD WITH PLUG FRONT OF CASE TOEKICK 48 1/2"...
Page 14 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-54-SC 4' & 6' (Bakery/Beverage/Cheese/Deli/Meat) GENERAL NOTES: • "---" Indicates that the feature is not an option on this case model and/or the data is not yet available at this time. SHIPPING WEIGHT Case Weight PF-54-SC ENGINEERED FOR STORES WITH AMBIENT...
Page 15 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-54-SC 4' & 6' (Bakery/Beverage/Cheese/Deli/Meat) SYSTEM REQUIREMENTS Minimum Maximum Case Total Circuit Overcurrent Ampacity Protection Length Volts Phase Amps 20.26 25.3 120/208 13.77 17.2 ELECTRICAL DATA High Efficiency Anti-Condensate Drain Evaporator Auxiliary Fans Fans Pumps Pan Heaters Fans...
Page 16 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-54-SC 4' & 6' (Bakery/Beverage/Cheese/Deli/Meat) DEFROST CONTROLS Electric Defrost Timed-Off Defrost Hot Gas Defrost Run-Off Termination Termination Termination Time Temp Temp Temp Defrosts Fail-Safe Fail Safe Fail-Safe Per Day (Min) (Min) (°F) (Min) (°F) (Min) (°F) ENGINEERED FOR STORES WITH AMBIENT...
Page 17 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-54-SC 4' & 6' (Bakery/Beverage/Cheese/Deli/Meat) LOAD LIMIT 19 5/16" [49.0 cm] 10" 14" 18" 30" [76.3 cm] COMPRESSOR COMPARTMENT 33" [83.9 cm] (AIRFLOW BACK TO FRONT) 42" [106.8 cm] POWER CORD WITH PLUG FRONT OF CASE TOEKICK 48 1/2"...
Page 18 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-72-SC 4' & 6' (Bakery/Beverage/Cheese/Deli) GENERAL NOTES: • "---" Indicates that the feature is not an option on this case model and/or the data is not yet available at this time. SHIPPING WEIGHT Case Weight PF-72-SC ENGINEERED FOR STORES WITH AMBIENT...
Page 19 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-72-SC 4' & 6' (Bakery/Beverage/Cheese/Deli) SYSTEM REQUIREMENTS Minimum Maximum Case Total Circuit Overcurrent Ampacity Protection Length Volts Phase Amps 20.95 26.18 120/208 15.50 18.81 ELECTRICAL DATA High Efficiency Anti-Condensate Drain Evaporator Auxiliary Fans Fans Pumps Pan Heaters Fans...
Page 20 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-72-SC 4' & 6' (Bakery/Beverage/Cheese/Deli) DEFROST CONTROLS Electric Defrost Timed-Off Defrost Hot Gas Defrost Run-Off Termination Termination Termination Time Temp Temp Temp Defrosts Fail-Safe Fail Safe Fail-Safe Per Day (Min) (Min) (°F) (Min) (°F) (Min) (°F) ENGINEERED FOR STORES WITH AMBIENT...
Page 21 TECHNICAL REFERENCE Self-Service Open Muti-Deck Merchandiser PF-72-SC 4' & 6' (Bakery/Beverage/Cheese/Deli) 19 5/16" [49.0 cm] LOAD LIMIT 10" 12" 14" 18" 30" [76.3 cm] COMPRESSOR COMPARTMENT 33" [83.9 cm] (AIRFLOW BACK TO FRONT) 42" [106.8 cm] POWER CORD WITH PLUG FRONT OF CASE TOEKICK 48 1/2"...
Page 22 GENERAL INFORMATION hank you for choosing Hillphoenix for your food merchandising needs. This handbook contains important technical infor- mation and will assist you with the installation and operation of your new Hillphoenix specialty cases. By closely following the instructions, you can expect peak performance; attractive fit and finish; and long case life. We are always interested in your suggestions for improvements (e.g.
Page 23 CASE INSTALLATION LOCATION the store ﬂ oor to the proper staging area. First remove all crating then all sled runner, caster, and/or power cord This refrigerated display case has been designed for displaying shipping braces. (Dependent on case design.) and storing perishable food product. It is engineered for air- conditioned stores with a maximum ambient of 75°F and 55% relative humidity.
Page 24 CASE INSTALLATION 2. Once the case is properly placed on the shim packs, You can use more than two brackets for anchoring if you want further support this way. check the vertical plumb of the case by placing a bubble level on the rear wall.
Page 25 CASE INSTALLATION tion and case performance. 12. Install toekick back onto the base of case. Fig. 5 Bolt locations (PF-54-SC) WATERSHED END FRAME Fig. 6 Sealing the pipe chase ▲ C A U T I O N Installation of 3rd-party materials may result in diminished case performance.
Page 26 CASE CONNECTIONS PLUMBING When connecting to the power supply on the case, ﬁ eld wiring should exit box from the side furthest away from case wiring to Some self-contained cases require a ﬂ oor drain. If applicable, allow more room inside for wiring connections. The case must the drain outlet or “P”...
Page 27 CASE CONNECTIONS 3. After establishing power the light control switch located based on case design. See technical references on pages 5, 9, 13 and 17 for access locations and page 23 for a compres- next to the power switch on the upper front exterior toe- sor compartment diagram.
Page 28 LIGHTING & POWER SUPPLIES GENERAL LIGHTING INFORMATION should operate without the need for any signiﬁ cant mainte- nance for several years. Should a power supply need to be re- Hillphoenix cases are equipped with LED luminaires and fea- moved and/or replaced, turn off the power to the case before ture specially designed light reflectors in the cornice to improve proceeding.
Page 29 LIGHTING & POWER SUPPLIES ▲ C A U T I O N Too much tension on the inner clamp rings while removing them from an LED light rod may cause CLAMP breakage. Use only enough tension for removal. RING RING & CLAMP Fig.
Page 30 PRE-POWER CHECKLIST Before powering-up the case, be certain that all of the steps listed below have been completed to ensure proper case functionality, safety and compliance with warranty terms. Have you thoroughly examined the case for shipping damage? (see pg. 18) Have you checked the vertical plumb of the case? The horizontal level? (see pg.
Page 31 AIRFLOW & DEFROST AIRFLOW & PRODUCT LOAD Appendix C1). 3. Finally, subtract the converted temperature reading from Hillphoenix cases provide maximum product capacity within the the actual temperature reading for superheat setting. refrigerated air envelope. Please keep products within the ap- propriate load limit.
Page 32 CASE CLEANING CASE CLEANING provided lift handles (Fig. 19). There are hinges shared between the pressure plate and coil covers. Note: It is recommended that more than one person lift the pres- A periodic cleaning schedule should be established to maintain proper sanitation, insure maximum operating efficiency, and sure plate.
Page 33 CASE CLEANING 3. Carefully, without bending the sheet metal cover, with the ▲ W A R N I N G use of the handles provided, gently slide the coil cover with the pressure plate assembly forward to expose the Exercise extreme caution when working in a case evaporator coil.
Page 34 PARTS ORDERING Contact the Service Parts Department at: 1-844-HPX-PART (1-844-479-7278) dfr-ia-parts@doverfoodretail.com Provide the following information about the part you are ordering: • Model number and serial number* of the case for which the part is intended. • Length of the part (if applicable). •...
Page 35 APPENDIX A1 ....................Wiring Information B1-B3 ................Dixell Operating Instructions C1 ..............Sporlan Pressure-Temperature Chart D1-D4 ......................Parts List...
Page 36 A1: WIRING DIAGRAM...
Page 37 B1: DIXELL OPERATING INSTRUCTIONS dIXEL Operating Manual 1592020130 DIGITAL CONTROLLER 6. FRONT PANEL COMMANDS XR03CX – XR04CX To display target set point, in programming mode it selects a parameter confirm operation 1. CONTENTS To start a manual defrost Contents __________________________________________________________________________ 1 General warnings ___________________________________________________________________ 1 programming mode...
Page 38 B2: DIXELL OPERATING INSTRUCTIONS dIXEL Operating Manual 1592020130 Hy Differential: (0,1°C 25°C) Intervention differential for set point. Compressor Cut IN is SET as the external digital input is disabled again. With the door open, the high and low temperature alarms are disabled.
Page 39 B3: DIXELL OPERATING INSTRUCTIONS dIXEL Operating Manual 1592020130 Protection: IP20; Frontal protection: IP65 Start defrost delay 0 ÷ 99 min. Connections: Screw terminal block 2,5 mm wiring. Power supply: according to the model: 12Vac/dc, ±10%; 24Vac/dc, ±10%; 230Vac 10%, 50/60Hz, Display during defrost rt –...
Page 40 C1: SPORLAN PRESSURE-TEMPERATURE CHART...
Page 41 D1: PARTS LIST (PF-48-SC) Cornice Case Top Interior End Panel Die Board Plex Die Board Condenser Air Intake Front Toekick Product Stop Air Return Insulated Drain Pan End Panel Trim End Panel End Toekick Outside Back Bottom Deck Adjustable Shelf Bracket Shelf Standard Price Tag Molding Inside Back...
Page 42 D2: PARTS LIST (PF-51-SC) Cornice Case Top Interior End Panel Die Board Plex Die Board Condenser Air Intake Front Toekick Product Stop Air Return Insulated Drain Pan End Panel Trim End Panel End Toekick Outside Back Bottom Deck Adjustable Shelf Bracket Shelf Standard Price Tag Molding Inside Back...
Page 43 D3: PARTS LIST (PF-54-SC) Cornice Case Top Interior End Panel Die Board Plex Die Board Condenser Air Intake Front Toekick Product Stop Air Return Insulated Drain Pan End Panel Trim End Panel End Toekick Outside Back Bottom Deck Adjustable Shelf Bracket Shelf Standard Price Tag Molding Inside Back...
Page 44 D4: PARTS LIST (PF-72-SC) Cornice Case Top Interior End Panel Die Board Plex Die Board Condenser Air Intake Front Toekick Product Stop Air Return Insulated Drain Pan End Panel Trim End Panel End Toekick Outside Back Bottom Deck Adjustable Shelf Bracket Shelf Standard Inside Back Price Tag Molding...
Page 45 Hill PHOENIX, Inc. Hereinafter Referred To As Manufacturer LIMITED WARRANTY GENERAL WARRANTY Manufacturer’s products are warranted to be free from defects in materials and workmanship under normal use and maintenance for fourteen months from date of shipment from manufacturer (the “Base Warranty Period”). In the event of a qualifying warranty claim, a new or rebuilt part to replace any defective part will be provided without charge.
Page 46 Warning Maintenance & Case Care When cleaning cases the following must be performed PRIOR to cleaning: To avoid electrical shock, be sure all electric power is turned off before cleaning. In some installations, more than one switch may have to be turned off to completely de-energize the case.
