SINGLE-DECK MERCHANDISER
INSTALLATION & OPERATIONS MANUAL
Technical References ................................................. 2-7
General Information ........................................................8
Installation ................................................................ 9-15
Case Connections ...................................................16-19
Lighting & Power Supplies ......................................20-22
Pre-Power Checklist .................................................... 23
To ensure proper functionality and optimum performance, it is STRONGLY recommended that Hillphoenix specialty cases be installed/serviced by qualified tech-
nicians who have experience working with commercial refrigerated display merchandisers and storage cabinets. For a list of Hillphoenix-authorized installation/
service contractors, please visit our website at www.hillphoenix.com.
CNZLA/CNEZLA

Table of Contents

Airflow & Defrost .......................................................... 24
Case Cleaning .........................................................25-27
Troubleshooting ......................................................28-29
Safety Devices & Service .......................................30-31
Parts Ordering .............................................................. 32
Appendices
(R-290)
04/22
