Merrytek MSA020 Instructions Manual page 2

1. Features:
2. Parameters
Operating voltage
Input
Operating current
Working mode
Output
Work mode
Interface DALI bus interface
Operating frequency
Transmitting power
Hold time
Work mode
Detection Area
Sensor
Daylight Sensor
parameters
Detection range
(radius)
Mounting height
Detecting Angle
Operating Temperature
Operating
Storage
environment
Temperature/humidity
LVD standards
EMC standards
Certificate
Environmental
Standards
Requirement
Certificate
Wiring
IP Rating
Others
Protection Class
Installation
Add: No.17th Building, Dianda Guyuan Industrial Park, Mashantou, Matian, Guangming District, Shenzhen, China, 518106
Tel: +86 (0)755-2305 7253
All technical information is subject to the physical performance, Merrick reserves the right to final interpretation
LIFEBEING SENSOR
1) Adopt Merrytek patented Lifebeing detected technology, which
can detect movement, slight motion and breathing signal.
2) Built-in daylight sensor for energy saving
3) Built-in DALI interface, which can work with DALI1.0 & DALI2.0
drivers.
4) Work with DALI bus power supply, can be grouping control
5) Support multiple access, multi-point acquisition of sensor data,
transmissing the datas via broadcast mode grouping work
6) 5 years warranty.
9.5-24V DC (DALI BUS power supply ）
40mA Max (@16v DC)
ON/OFF
DALI signal
9.5V-22V DC Bus
5.8 GHz ±75 MHz, ISM wave band.
5mW Max.
5S/30S/1Min/3Min/5Min/10Min/20Min/30Min
Master/ slave
100%/75%/50%/25%
5Lux、Disable
Movement: 3-4m (Speed: 0.3m/s）
Slight motion: 3-4m
Breathing: 2-3m
Recommend 2.5-4m
150°(wall mount), 360°(ceiling mount）
0℃～+50℃
-40℃～+80℃
EN61058-1, EN61058-1-2
EN55015, EN61547, EN61000-3-2, EN61000-3-3
Compliant to RoHS
CE RED
"L N ground" port diameter: 0.75-1.5 mm
Whole: IP20 Exposed part: IP44
Class II
Built-in
Shenzhen Merrytek Technology Co.,Ltd
Fax: +86 (0)755-2786 3012
page 2 of 10
MSA020
operating current: 40mA Max
2
Website: www.merrytek.com
Version: A0
