Schwinn AirDyne AD6: Noises from the resistance fan assembly
Follow this troubleshooting guide to help resolve noise issues on the Schwinn AirDyne AD6.
Some common complaints may include:
Rubbing noises
Squeaking or creaking noises
Squealing noises
Clicking or clunking noises
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
4mm, 6mm hex/Allen wrench, or the wrench from the
hardware card included with your machine
14mm socket wrench
10mm, 15mm, 17mm open-ended wrenches
Pliers
1.
Refer to the "Replace the Drive Belt/Fan Assembly" section of the
shrouds and accessing the fan assembly. Follow the entire procedure to remove the belts as well, as they will need to
be reset after putting the fan assembly back in place.
2.
Once the fan assembly is removed from your bike, check that the fan is properly aligned inside the fan cover. No part
of the fan should be making contact with the cover [13790.A].
3.
Inspect the fan assembly for debris inside the cover. If debris is found, remove it through the belt opening if possible.
If you cannot access the debris from the opening, use a Phillips head screwdriver to remove the screws along the
seam of the fan cover to open up the fan cover. Reinstall the screws once the debris is removed (reference
1) [13790.B].
about:blank
Schwinn AirDyne AD6:  Noises from the resistance fan assembly
(Reference 1)
service manual for instructions on removing the
