Sonance UA 2-125 ARC Quick Start Manual

BOX CONTENTS
(1) Quickstart Guide
(1) UA 2-125 ARC Amplifier
(1) Power Cord (Region Dependent)
(1) IR Receiver
(1) Speaker Block Connector
(2) Mounting Brackets
(4) T-Nuts
PREPARING
1. Prepare smartphone and
enable Bluetooth.
2. Use the QR code to download
and install the SonARC App.
INSTALLATION
1. The UA 2-125 ARC chassis comes with brackets,
T-Nuts, and 20mm T-Slot grooves for easy
mounting.
2. Thread a seismic tether through the hole in the
upper left corner of the Audio Connector Panel
when mounting in locations where the amplifier
could fall and damage property or cause injury.
For more mounting information please see the
Operation Manual.
GETTING STARTED
The Sonance UA 2-125 ARC amplifier comes ready to
play audio out-of-the-box. Installers should set up the
amp using the SonARC interface (Bluetooth required)
for optimal performance. Sonance suggests the
following installation sequence:
1. The UA 2-125 ARC amp should be away from
moisture and temperatures exceeding 100°F
(38°C).
2. Mount the UA 2-125 ARC using the included
mounting brackets and T-Nuts.
3. Connect audio inputs: HDMI and/or Analog RCA.
4. Connect speaker outputs.
5. Connect the power cord.
6. Confirm source device (HDMI or Analog RCA).
7. Power the UA 2-125 ARC on.
8. Unmute the source device.
UA 2-125 ARC AMPLIFIER
QUICKSTART GUIDE
STATUS INDICATOR LED
• SOLID GREEN: analog input selected
• SOLID WHITE: digital input selected
• SOLID BLUE: setup mode, Bluetooth, or IR learning
• SOLID YELLOW: standby
• FLASHING RED (1HZ): protection state
• SOLID PURPLE: mixed input mode
SOURCE CONNECTIONS
The UA 2-125 ARC amplifier can
support multiple connections.
In the SonARC App, one
connection can be selected as
the default source, while the
other will be the secondary
source. Normally, audio will play
from the default source. If audio
is detected on the secondary
source the UA 2-125 ARC will automatically switch to
the secondary source. From the factory the default
source for the UA 2-125 ARC is the HDMI connection
while the Analog RCA connections are the secondary
source. If you are using a digital source (HDMI), make
sure that the source device is set up to provide a
2-channel PCM signal.
SETUP BUTTON
Bluetooth on the UA 2-125 ARC should be on by
default. If the phone running the SonARC App cannot
connect with the UA 2-125 ARC unit, press the SETUP
button to initiate the Bluetooth connection.
IR CONTROL
The IR 3.5mm jack can be used to receive IR
commands from a distribution box or provided sensor.
Refer to the UA 2-125 ARC webpage for specific IR
control codes. This feature will turn on automatically
when the IR sensor is plugged in, and does not need
to be enabled in the SonARC App interface.
CLIP INDICATOR LED
When the amp is clipping, audio peaks display as RED
flashes. If this occurs, the amplifier is being overdriven
and the volume control needs to be reduced until the
peaks no longer cause the LED to illuminate.
IN
STATUS
L
HDMI IN
R
eARC
BLE ANTENNA - DO NOT BLOCK
Figure 1: UA 2-125 ARC
Source Connections
4 M
OUT
CLASS
SETUP
IR
CLIP
